- Page 1 JABRA SPEAK 810 User Manual jabra.com/speak810...
- Page 2 ® © 2015 GN Netcom A/S. All rights reserved. Jabra is a registered trademark of GN Netcom A/S. All other trademarks included herein ® are the property of their respective owners. The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by GN Netcom A/S is under license.
-
Page 3: Table Of Contents
5.1 CONNECT TO USB DEVICE 5.2 CONNECT TO HEADSET PORT ON MOBILE DEVICE 5.3 CONNECT TO BLUETOOTH DEVICE 5.4 CONNECT TO NFC-ENABLED DEVICE 5.5 CONNECT TO JABRA LINK 360 6. HOW TO USE ........13 7. SOFTWARE ........14 7.1 JABRA DIRECT 7.2 UPDATE JABRA SPEAK 810 FIRMWARE... -
Page 4: Welcome
1. WELCOME Thank you for using the Jabra Speak 810. We hope you will enjoy it! JABRA SPEAK 810 FEATURES ƒ Zoom Talk microphone with adaptive directionality 5 m/15 ft. range (15 persons) ƒ Connectivity: USB, BT/NFC & 3.5 jack ƒ... -
Page 5: Speaker Overview
Volume down button Mute button Volume up button NFC zone Answer call button Tablet & mobile phone charging port End/reject call button Bluetooth button Cable slots USB cable Power supply port Power supply 3.5 mm jack cable JABRA SPEAK 810... -
Page 6: How To Position
ƒ Do not cover the speaker with stickers or labels. ƒ Do not balance the Jabra Speak 810 on top of cables. Use the cable slots on the base. ƒ Ensure to adjust the speaker volume to best suit your needs. -
Page 7: Connect To Power
4. CONNECT TO POWER Plug the power supply into the power supply port on the base of the Jabra Speak 810, secure the cable in the cable slot, and then connect to power. Power supply port 4.1 CHARGING YOUR PHONE OR TABLET... -
Page 8: How To Connect
5. HOW TO CONNECT 5.1 CONNECT TO USB DEVICE 1. Ensure the Jabra Speak 810 is connected to power using the power supply. 2. Plug the attached USB cable into any USB port on your PC. JABRA SPEAK 810... -
Page 9: Connect To Headset Port On Mobile Device
5.2 CONNECT TO HEADSET PORT ON MOBILE DEVICE 1. Ensure the Jabra Speak 810 is connected to power using the power supply. 2. Plug the attached 3.5 mm jack cable into the headset port on your mobile device. JABRA SPEAK 810... -
Page 10: Connect To Bluetooth Device
2. Tap the Bluetooth button on the Jabra Speak 810, and follow the voice-guided connection instructions. 3. Select the Jabra Speak 810 from the list of devices on your mobile device Bluetooth list. ® NOTE: To disconnect your Bluetooth device from the Jabra Speak 810, tap the Bluetooth button on the Jabra Speak 810. -
Page 11: Connect To Nfc-Enabled Device
NFC zone on the Jabra Speak 810 until a connection is confirmed on your mobile device. NOTE: To disconnect your NFC-enabled device from the Jabra Speak 810, slide it directly against the NFC zone on the Jabra Speak 810. JABRA SPEAK 810... -
Page 12: Connect To Jabra Link 360
4. You will hear a connection confirmation when the Jabra Link 360 and the Jabra Speak 810 are connected. ® NOTE: To disconnect the Jabra Link 360 from the Jabra Speak 810, tap the Bluetooth button on the Jabra Speak 810. JABRA SPEAK 810... -
Page 13: How To Use
Tap the End/reject button Volume up/ Tap, or press and hold, the + / - down Volume + or Volume - button Mute/unmute Tap the Mute button microphone Enable/disable Press and hold (8 secs) the Mute voice guidance button JABRA SPEAK 810... -
Page 14: Software
Firmware updates improve performance or add new functionality to Jabra devices. TO UPDATE FIRMWARE: 1. Connect the Jabra Speak 810 to a PC using the attached USB cable. 2. Download and install Jabra Direct on your PC. 3. Check for the latest firmware via Jabra Direct.You will receive update notifications whenever there is an update available for your device. -
Page 15: Support
8.2 HOW TO CARE FOR YOUR JABRA SPEAK 810 ƒ Avoid storage at extreme temperatures (above 45°C/113°F or below -5°C/23°F) ƒ Do not expose the Jabra Speak 810 to rain or other liquids ƒ Do not cover the Jabra Speak 810 with stickers or labels... -
Page 16: Technical Specifications
2” high performance full range Buetooth range: 30 m Bluetooth version: 1 active connection. Up to 900 Paired devices: paired connections stored in the Jabra Speak 810 Supported Bluetooth A2DP(v1.2), Hands Free Profile profiles: (v1.6), Headset profile(v1.2) Tablet and mobile phone 2.1A... - Page 17 JABRA SPEAK 810 SPECIFICATION Operating temperature: 5°C to 45°C (41°F to 113°F) Storage temperature: -5° C to 45°C (23°F to 113°F) Pairing passkey or PIN: 0000 JABRA SPEAK 810...
- Page 18 JABRA SPEAK 810...
