Washing Machine
User manual
WD85T4*****
WD85T4046CE_04215R-00_EN.indd 1
2021/5/19 10:22:46

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WD85T4 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Samsung WD85T4 Series

Summary of Contents for Samsung WD85T4 Series

  • Page 1 Washing Machine User manual WD85T4***** WD85T4046CE_04215R-00_EN.indd 1 2021/5/19 10:22:46...

  • Page 2: Table Of Contents

    Contents Safety information What you need to know about the safety instructions Important safety symbols Important safety precautions Critical installation warnings Installation cautions Critical usage warnings Usage cautions Critical cleaning warnings Installation What’s included Installation requirements Step-by-step installation Before you start Initial settings Laundry guidelines Detergent drawer guidelines...
  • Page 3 Troubleshooting Checkpoints Information codes Specifications Fabric care chart Protecting the environment Spare parts guarantee Specification sheet English 3 WD85T4046CE_04215R-00_EN.indd 3 2021/5/19 10:22:47...

  • Page 4: Safety Information

    Safety information Congratulations on your new Samsung washing machine. This manual contains important information on the installation, use and care of your appliance. Please take some time to read this manual to take full advantage of your washing machine’s many benefits and features.

  • Page 5: Important Safety Precautions

    Important safety precautions WARNING To reduce the risk of fire, electric shock, or injury to persons when using your appliance, follow basic precautions, including the following: 1. This appliance is not to be used by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
  • Page 6 Safety information 7. For use in Europe: Children of less than 3 years should be kept away unless continuously supervised. 8. CAUTION: In order to avoid a hazard due to inadvertent resetting of the thermal cut-out, this appliance must not be supplied through an external switching device, such as a timer, or connected to a circuit that is regularly switched on and off by the utility.
  • Page 7 17. The final part of a tumble dryer cycle occurs without heat (cool down cycle) to ensure that the items are left at a temperature that ensures that the items will not be damaged. 18. Remove all objects from pockets such as lighters and matches. 19.
  • Page 8 Safety information To minimize the risk of fire in a tumble dryer, the following should be observed CAUTION Items that have been spotted or soaked with vegetable or cooking oil constitute a fire hazard and should not be placed in a tumble dryer. Oil-affected items can ignit spontaneously, especially when exposed to heat sources such as in a tumble dryer.
  • Page 9 Items such as foam rubber(latex foam), shower caps, waterproof textiles, rubber backed articles and clothes or pillows fitted with foam rubber pads should not be dried in th tumble dryer. Fabric softeners, or similar products, should be used as specified by the fabric softene instructions.

  • Page 10: Critical Installation Warnings

    Safety information Critical installation warnings WARNING The installation of this appliance must be performed by a qualified technician or service company. • Failure to do so may result in electric shock, fire, an explosion, problems with the product, or injury. The appliance is heavy, therefore take care when lifting it.

  • Page 11: Installation Cautions

    Following the repair by a non-authorized service provider, self-repair or non-professional repair of the product, Samsung is not liable for any damage to the product, any injury or any other product safety issue caused by any attempt to repair the product which does not carefully follow these repair and maintenance instructions.

  • Page 12: Critical Usage Warnings

    Safety information Critical usage warnings WARNING If the appliance is flooded, turn off the water & power supplies immediately and contact your nearest service centre. • Do not touch the power plug with wet hands. • Failure to do so may result in electric shock. If the appliance generates a strange noise, a burning smell, or smoke, unplug the power plug immediately and contact your nearest service centre.

  • Page 13: Usage Cautions

    • Failure to do so may result in electric shock or fire. If any foreign substance enters into the appliance, unplug the power plug and contact you nearest Samsung Customer Service. • This may result in electric shock or fire.
  • Page 14 Using the product for business purposes qualifies as a product misuse. In this case, the product will not be covered by the standard warranty provided by Samsung and no responsibility can be attributed to Samsung for malfunctions or damages resulting from such misuse.
  • Page 15 Do not wash, spin, or dry water-proof seats, mats, or clothing (*) unless your appliance has a special cycle for washing these items. (*): Woollen bedding, rain covers, fishing vests, ski pants, sleeping bags, diaper covers, sweat suits, and bicycle, motor cycle and car covers, etc. • Do not wash thick or hard mats even if the washing machine mark is on the care label.
  • Page 16 Safety information Do not use dry cleaning detergent directly and do not wash, rinse, or spin laundry contaminated by dry cleaning detergent. • This may result in spontaneous combustion or ignition due to the heat from the oxidation of the oil. Do not use water from water cooling/heating devices.

  • Page 17: Critical Cleaning Warnings

    Critical cleaning warnings WARNING Do not clean the appliance by spraying water directly onto it. Do not use the a strong acidic cleaning agent. Do not use benzene, thinner or alcohol to clean the appliance. • This may result in discolouration, deformation, damage, electric shock or fire. Before cleaning or performing maintenance, unplug the appliance from the wall socket.

  • Page 18: Installation

    What’s included Make sure all the parts are included in the product package. If you have a problem with the washing machine or the parts, contact a local Samsung customer centre or the retailer. 01 Release lever 02 Detergent drawer...
  • Page 19 Spanner Bolt caps Hose guide Cold water hose Hot water hose Liquid detergent container Cap fixer Accessories (not supplied) • Stacking kit: SKK-DF - Staking kit is required to stack a dryer on a washing machine. NOTE • Spanner: For removing the shipping bolts and levelling the washing machine. • Bolt caps : For covering the holes after removing the shipping bolts.

  • Page 20: Installation Requirements

    Drain • Improperly connected grounding Samsung recommends a standpipe in conductors may cause electric shock. height of 60~90 cm. The drain hose must be connected through the hose clip to the standpipe, and the standpipe must fully cover the drain hose.
  • Page 21 Flooring Alcove or closet installation For best performance, the washing Minimum clearance for stable operation: machine must be installed on a solid floor. Sides 25 mm Wood floors may need to be reinforced 25 mm to minimize vibration and/or unbalanced loads.

  • Page 22: Step-By-Step Installation

    Installation Step-by-step installation STEP 1 Select a location Location requirements: • Solid, level surface without carpeting or flooring that may obstruct ventilation • Away from direct sunlight • Adequate room for ventilation and wiring • The ambient temperature is always higher than the freezing point (0 ˚C) • Away from a heat source STEP 2 Remove the shipping bolts Unpack the product package and remove all shipping bolts.
  • Page 23 1. Locate the shipping bolts (marked with circle in the figure) on the rear side of the washing machine. CAUTION Do not remove the screw (A) that fixes the hose clip. 2. Using the supplied spanner, loosen all the shipping bolts by turning them counterclockwise.
  • Page 24 Installation 3. Insert the bolt caps (B) to the holes (marked with circle in the figure). STEP 3 Adjust the levelling feet 1. Gently slide the washing machine into position. Excessive force may damage the levelling feet. 2. Level the washing machine by manually adjusting the levelling feet.
  • Page 25 3. When levelling is complete, tighten the nuts using the spanner. CAUTION When installing the product make sure the levelling feet is not pressing the power cord. CAUTION Make sure all the levelling feet are seating on the floor surface to avoid the washing machine from moving or generating noise due to vibration Then, check if the washing machine is not rocking.
  • Page 26 If there is a water leak, stop operating the washing machine and disconnect from the electrical supply. Then, contact a local Samsung service centre in case of a leak from the water hose, or contact a plumbing technician in case of a leak from the water tap. Otherwise, this may cause electric shock.
  • Page 27 CAUTION Do not stretch the water hose by force. If the hose is too short, replace the hose with a longer, high-pressure hose. Connecting to a non-threaded water tap 1. Remove the adaptor (A) from the water hose (B). 2. Use a Phillips screwdriver to loosen four screws on the adaptor.
  • Page 28 Installation 4. Insert the adaptor onto the water tap, and then tighten the screws while lifting the adaptor. 5. Turn part (C) in the arrow direction to tighten it. 6. While pulling down part (D) on the water hose, connect the water hose to the adaptor.
  • Page 29 For models with an additional hot water inlet: 1. Connect the red end of the hot water hose to the hot water inlet on the back of the machine. 2. Connect the other end of the hot water hose to the hot water tap. Aqua stop hose (applicable models only) The aqua stop hose alerts users of a risk of water leaks.
  • Page 30 Installation STEP 5 Position the drain hose The drain hose can be positioned in three ways: Over the edge of a wash basin The drain hose must be placed at a height of between 60 cm and 90 cm (*) from the floor.
  • Page 31 In a sink drain pipe branch The drain pipe branch mush be above the sink siphone so that the end of the hose is at least 60 cm above the ground. (*) : 60 cm CAUTION Remove the lid on the sink drain pipe branch before connecting the drain pipe to STEP 6 Turn on the washing machine Plug the power cord into a wall socket that is correctly rated, grounded, and protected by a...

  • Page 32: Before You Start

    Before you start Initial settings Run Calibration (recommended) Calibration ensures accurate weight detection by the washing machine. Make sure the drum is empty before running Calibration. 1. Power off, and then power on the washing machine. 2. Hold down Temp. and Delay End simultaneously for 3 seconds to enter Calibration mode.
  • Page 33 Turn clothing with buttons and embroideries inside out • If pants or jacket zippers are open while washing, the drum may be damaged. Zippers should be closed and fixed with a string. • Clothing with long strings may become entangled with other clothes. Make sure to tie the strings before starting the wash.
  • Page 34 Before you start NOTE • Follow the detergent manufacturer’s recommendations based on the weight of the laundry, the degree of soiling, and the hardness of the water in your local area. If you are not sure about the water hardness, contact a local water authority. • Do not use detergent that tends to be hardened or solidified.

  • Page 35: Detergent Drawer Guidelines

    Detergent drawer guidelines The washing machine provides a three-compartment dispenser: the left compartment for the main wash, the centre compartment for fabric softeners, and the right compartment for the preliminary wash. Prewash compartment: Apply prewash detergent. Main-wash compartment: Apply main-wash detergent, water softener, soaking detergent, bleach, and/or stain removers.
  • Page 36 Before you start 3. Apply fabric softener to the softener compartment. Do not exceed the max line (A). 4. If you want to prewash, apply prewash detergent to the prewash compartment as instructed or recommended by the manufacturer. 5. Close the detergent drawer. CAUTION • Do not apply powder detergent to the liquid container.
  • Page 37 To use liquid detergent (applicable models only) First insert the provided liquid container in the main-wash compartment. Then, apply liquid detergent to the container below the marked max line (A). CAUTION • Do not exceed the max line that is marked inside the container.

  • Page 38: Operations

    Operations Control panel 01 Cycle Selector Turn the dial to select a cycle. The display shows current cycle information and estimated time 02 Display remaining, or an information code when a problem occurs. Press to change the water temperature for the current cycle. Temp.

  • Page 39: Simple Steps To Start

    Start/Pause Press to start or stop operation. Press to turn on/off the washing machine. Power For more information on the options, see the Special features section. *(3 sec) : Press and hold for 3 seconds. Simple steps to start 1. Press Power to turn on the washing machine.

  • Page 40: Drying Only

    Operations Drying Only You can dry your clothes directly or dry the washed clothes according to the following procedures. 1. Press Power button to turn on the washing machine. 2. Turn the Cycle Selector to select COTTON DRY cycle. 3. Press Dry Option button to select the appropriate drying mode.

  • Page 41: Cycle Overview

    Cycle overview Standard cycles Max load Cycle Description (kg) • For cottons, bed linens, table linens, underwear, towels, or shirts. COTTON The washing time and the rinse count are automatically adjusted according to the load. • Optimal performance with lower energy for cotton fabrics, bed linens, table linens, underwear, towels, or shirts.
  • Page 42 Operations Max load Cycle Description (kg) • For lightly soiled items in less than 2.0 kg that you want to wash quickly. • Use less than 20 g of detergent. Using more than 20 g of detergent may leave detergent residue. 15’...
  • Page 43 NOTE • Loading the household washing machine or the household washer-dryer up to the capacity indicated by the manufacturer for the respective cycles will contribute to energy and water savings. • The noise and remaining moisture content are influenced by the spinning speed: the higher the spinning speed in the spinning phase, the higher the noise and the lower the remaining moisture content.
  • Page 44 Operations Delay End You can set the washing machine to finish your wash automatically at a later time, choosing a delay of between 1 to 24 hours (in 1 hour increments). The hour displayed indicates the time the wash will finish. 1.

  • Page 45: Settings

    Settings Child Lock Sound On/Off To prevent children or infants from You can turn on or off the sound from the accidentally starting or setting the washing washing machine. When this function is set machine, Child Lock locks all buttons except to Off, the melody of cycle completion, and for the Power button.

  • Page 46: Maintenance

    Maintenance Keep the washing machine clean to prevent deteriorated performance and to preserve its life cycle. Drum clean Perform this cycle regularly to clean the drum by removing bacteria from it. This cycle heats the water between 60 °C and 70 °C. 1.

  • Page 47: Smart Check

    Smart check To enable this function, you must first download the Samsung Smart Washer app at the Play Store or the Apple Store, and install it on a mobile device featuring a camera function. The Smart Check function has been optimized for Galaxy & iPhone series (applicable models only).

  • Page 48: Emergency Drain

    Maintenance Emergency drain In case of a power failure, drain the water inside the drum before taking out the laundry. 1. Power off and unplug the washing machine from the electrical outlet. 2. Gently press the top area of the filter cover (A) to open.

  • Page 49: Cleaning

    Cleaning Surface of the washing machine Use a soft cloth with a nonabrasive household detergent. Do not spray water onto the washing machine. Mesh filter Clean the mesh filter of the water hose once or twice a year. 1. Turn off the washing machine, and unplug the power cord.
  • Page 50 Maintenance Debris filter Clean the debris filter bi-monthly to prevent clogging. A clogged debris filter may reduce the bubble effect. 1. Turn off the washing machine, and unplug the power cord. 2. Drain the remaining water inside the drum. See the “Emergency drain” section.
  • Page 51 Detergent Drawer 1. While holding down the release lever (A) on the inner of the drawer, slide open the drawer. 2. Clean the drawer components in flowing water using a soft brush. 3. Clean the drawer recess using a bottle brush to remove detergent residues and limescale on the drawer recess.

  • Page 52: Recovery From Freezing

    Maintenance Recovery from freezing The washing machine may freeze when it drops below 0 °C. 1. Turn off the washing machine, and unplug the power cord. 2. Pour warm water over the water tap to loosen the water hose. 3. Disconnect the water hose, and soak it in warm water. 4.

  • Page 53: Troubleshooting

    Troubleshooting If there is any problem, check the information message on the LED screen and follow the on- screen instructions. If the problem persists, please contact the service center. Checkpoints If you encounter a problem with the washing machine, first check the table below and try the suggestions.
  • Page 54 Troubleshooting Problem Action • Make sure the washing machine is installed on a level, solid floor that is not slippery. If the floor is not level, use the levelling feet to adjust the height of the washing machine. • Make sure the shipping bolts are removed. • Make sure the washing machine is not in contact with any other object.
  • Page 55 Problem Action • Press or tap Start/Pause to stop the washing machine. • It may take a few moments for the door lock mechanism to disengage. • The door will not open until 3 minutes after the washing The door does not machine has stopped or the power has been off.
  • Page 56 Troubleshooting Problem Action • Fully open both taps. • Make sure the temperature selection is correct. • Make sure the hoses are connected to the correct taps. Flush water lines. • Make sure the water heater is set to supply a minimum of 49 °C hot water at the tap.

  • Page 57: Information Codes

    Problem Action • You may not be able to see bubbles if there is too much items No bubbles are seen in the drum. (Bubble models only). • Severely contaminated laundry may not generate bubbles. If a problem persists, contact a service center. Information codes If the washing machine fails to operate, you may see an information code on the screen.
  • Page 58 Water has overflowed. • Restart after spinning. • If the information code remains on the display, contact a local Samsung service centre. Check the drain hose. • Make sure the end of the drain hose is not placed on the floor.
  • Page 59 • The machine operates normally without running the DRUM CLEAN cycle. However, it is recommended to run the cycle for hygienic purposes. If any information code keeps appearing on the screen, contact a local Samsung service centre. English 59 WD85T4046CE_04215R-00_EN.indd 59...

  • Page 60: Specifications

    Specifications Fabric care chart The following symbols provide garment care directions. The care labels include four symbols in this order: washing, bleaching, drying and ironing (and dry cleaning when necessary). The use of symbols ensures consistency among garment manufacturers of domestic and imported items.

  • Page 61: Protecting The Environment

    Protecting the environment • This appliance is manufactured from recyclable materials. If you decide to dispose of this appliance, please observe local waste disposal regulations. Cut off the power cord so that the appliance cannot be connected to a power source. Remove the door so that animals and small children cannot get trapped inside the appliance.
  • Page 62 Specifications Type Front loading washing machine Model name WD85T4***** A (Width) 600 mm B (Height) 850 mm Dimensions C (Depth) 650 mm 730 mm 1170 mm Water pressure 50 kPa ~ 800 kPa NET weight 68 kg Wash and spin capacity 8.5 kg Dry capacity 6.0 kg...
  • Page 63 WD85T4046CE_04215R-00_EN.indd 63 2021/5/19 10:23:00...
  • Page 64 QUESTIONS OR COMMENTS? COUNTRY CALL OR VISIT US ONLINE AT 1300 362 603 (Other) AUSTRALIA www.samsung.com/au/support 1300 425 299 (HHP) DC68-04215R-00 WD85T4046CE_04215R-00_EN.indd 64 2021/5/19 10:23:01...
