User Manual
Dock Pro Duo USB-C
Docking Station
GUD3CDHTAA
PART NO. M1653
www.iogear.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GUD3CDHTAA and is the answer not in the manual?

Questions and answers

Summary of Contents for IOGear GUD3CDHTAA

  • Page 1 User Manual Dock Pro Duo USB-C Docking Station ™ GUD3CDHTAA PART NO. M1653 www.iogear.com...
  • Page 2 © 2023 IOGEAR. All rights reserved. IOGEAR and the IOGEAR logo are registered trademarks of Aten Technology, Inc. USB-C is a registered trademark of USB Implementers Forum, Inc. Displaylink and Displaylink logo are trademarks or registered trademarks of Synaptics Incorporated. HDMI and related logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
  • Page 3: Table Of Contents

    Table of Contents Introduction Features Overview Hardware Installation Displaylink Software Installation Displays Configuration Specification Video Resolution Chart Limited Warranty Contact Compliance Information...
  • Page 4: Introduction

    Introduction The IOGEAR Dock Pro Duo USB-C Docking Station merges cutting edge technology and high-quality hardware with innovative design elements. It allows users to connect up to three displays and multiple USB peripherals to two computers simultaneously, making it easy to...
  • Page 5: Features

    Features • Dock 2 USB-C laptops and expand to 11 ports • Share Video and USB peripherals between TWO host computers over USB-C • Hotkey Switching • 1x HDMI up to 4096x2160 @60Hz (DP Alt mode) • 2x Displayports up to 4096x2160 @60Hz (Displaylink mode) •...
  • Page 6 Package Contents • 1x GUD3CDHTAA • 2x USB-C to C cables for Host computers • 1x Power adapter • 1x Quick Start Guide • 1x Warranty Card...
  • Page 7 System Requirements Host Device Requirement: • USB-C (Thunderbolt 3 and 4 compatible) device OS Requirement: • Windows 10,11 • MacOS 12+ • DisplayLink Driver installation (http://www.displaylink.com/ downloads) • Notes for M1/M2 Mac Users: For M1/M2 Mac Users, please check DisplayLink website for latest Mac Displaylink driver: http://www.displaylink.com/downloads/macos...
  • Page 8: Overview

    Overview 1. Host Switch Button: Used to switch between PC1 and PC2 2. USB 2.0 Port (Keyboard) 3. USB 2.0 Port (Mouse) 4. Audio In (Microphone) 5. Audio Out (Headset/Speaker) 6. USB-A 3.2 Gen2 (10Gbps) 7. USB-A 3.2 Gen2 (10Gbps) 8.
  • Page 10: Hardware Installation

    Hardware Installation Connect power adapter to the docking station. STEP 1. Connect a compatible USB-C host device to host STEP 2. connection A. Connect a compatible USB-C host device to host STEP 3. connection B. Connect an HDMI cable to the docking station and then STEP 4.
  • Page 11 * Host computer must support DP-Alt mode ** Requires installation of DisplayLink driver *** 104-Key Keyboard required to be plugged into this port for hotkey access.
  • Page 12: Displaylink Software Installation

    (Windows 10, macOS X) please install Displaylink software. Windows 10,11 Install Download the latest Windows Displaylink software STEP 1. from the IOGEAR product page or directly Displaylink/ Synaptics webpage at https://www.synaptics.com/ products/displaylink-graphics/downloads/windows Open the zip folder and run/open the “install” .exe file.
  • Page 13 Once Displaylink Graphics window appears, click “Install” STEP 3. Click “Finish” and your installation is now complete For Windows 11 users installing “Displaylink Manager” for Windows may be needed.
  • Page 14 macOS Displaylink Manager Install Download latest “Displaylink Manager” from Displaylink/ STEP 1. Synaptics webpage at https://www.synaptics.com/products/ displaylink-graphics/downloads/macos Open the Displaylink Manager “.pkg” file. You may be asked STEP 2. to allow installation from your security and privacy settings. Make sure you allow the file to open through your system preferences.
  • Page 15 Next agree to license agreement by clicking on “continue” STEP 4. Select “Agree”...
  • Page 16 Select “Install” Once you see the “Installation Successful” notice you may close the installer...
  • Page 17 Once you see the displaylink icon below in your toolbar STEP 5. then Displaylink Manager is installed and running properly. If after installation you do not see the icon in your toolbar, you will need to navigate to your “Applications” folder and open displaylink manager by double clicking on the app.
  • Page 18: Displays Configuration

    Displays Configuration The Dock Pro Duo USB-C Docking station allows two USB-C computers to connect to up 3 external displays. Connect your displays with 2x Displayport and 1x HDMI connections. Simply press the Hot Switch Button on the front panel of docking station to switch between modes or press SHIFT twice to activate keyboard hotkey switching.
  • Page 19 • Mode 2: Host A Dual Display (Displayport) & Host B Single Display (HDMI) • Mode 3: Host B Triple Displays (Displayport & HDMI) • Mode 4: Host B Dual Displays (Displayport) & Host A Single Display (HDMI)
  • Page 20: Specification

    Specification Host Input 2x USB-C 3.2 Gen 2 (10 gbps) Video Output 1x HDMI Up to 4096x2160 @60hz (DP Alt Mode) 2x 4096x2160@60Hz (Displaylink) Audio 1 x Mic input 1 x Line output USB Connections 1x USB-C 3.2 Gen 2 (10 Gbps) 2x USB-A 3.2 Gen 2 (10 Gbps) 2x USB-A 2.0 (Keyboard and Mouse) Network...
  • Page 21: Video Resolution Chart

    Video Resolution Chart...
  • Page 22: Limited Warranty

    Product Model _____________ Serial Number _____________ Contact WE’RE HERE TO HELP YOU! NEED ASSISTANCE SETTING UP THIS PRODUCT? Make sure you: 1. Visit www.iogear.com for more product information 2. Visit www.iogear.com/support for live help and product support IOGEAR iogear.custhelp.com support@iogear.com www.iogear.com...
  • Page 23: Compliance Information

    Compliance Information Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital service, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. Any changes or modifications made to this equipment may void the user’s authority to operate this equipment.
