4.6.3.10 LOAD FIRMWARE

This function allows you to upgrade the DLT7 Autoloader's firmware via the SCSI bus.
Whenever new firmware for your DLT7 Autoloader is released, complete instructions on how
to use the LOAD FIRMWARE function to perform the upgrade is included on the firmware
diskette.

4.6.3.11 DISPLAY COUNTS

The DLT Autoloader keeps track of how many times certain events have occurred. The DSP
COUNTS function displays these numbers.
1. After entering the DIAG MENU, press and hold the MODE button until dSP COUNTS
appears on the LCD panel.
2. Press the SELECT button to access the first event. FRT PK (SEL) appears on the LCD
panel.
3. Press the SELECT button again. Your DLT7 Autoloader displays the number of times
that it has picked a cartridge from any of the front slots.
4. Press the NEXT button to access the next event.
Your DLT7 Autoloader keeps track of the following events:
Front Pick Cartridge
Rear Pick Cartridge
Drive Pick Cartridge
Front Place Cartridge
Rear Place Cartridge
Drive Place Cartridge
Drive Door Retries
Front Pick Retries
Rear Pick Retries
Drive Pick Retries
Front Place Retries
Rear Place Retries
Drive Place Retries
Press the SELECT button when dRV dR RE is displayed to return your DLT7 Autoloader to
LdR REAdY. Press the MODE button at any time to return your DLT7 Autoloader to LdR
REAdY.
