Removing and installing components
NOTE: The images in this document may differ from your computer depending on the configuration you ordered.
Topics:
•

Inside view of your computer

• Recommended tools
• Screw list
•
Back cover
• Bottom cover
• Stand
• Hard drive
• System-board shield
• Memory modules
• Heat sink
• Wireless card
• Solid-state drive
• Media-card reader
• Speakers
• Microphones
• Fan
• Antennas
• Camera
• Power-button board
• System board
• Base panel
• Display panel
Inside view of your computer
NOTE: The appearance of heat sink differs depending on the graphics configuration you ordered.
