Getting to Know your Charger

This section of the manual is designed to give you a complete understanding of the features,
functions and operation of your OPTIMA ® D200+.
1
2
5
7
8
9
12
11
Getting to Know your Charger
Feature
1. Charge Status Light Bar
2. Connected LED
3. Power LED
4. Check LED
5. Pre-Charge Status Push Button Prior to charging your battery, you may use this function
3
4
6
6. Pre-Charge Status Fill Gauge
11
10
7. Battery Selector Push Button
®
8. OPTIMA LiFePO4 Profile
9. AGM Profile
13
10. Flooded Profile
11. On Unit Cord Storage
12. Wall Organizer Bracket
13. AC Power Plug
Function
Displays the corresponding color for Analyze, Charge,
Conditioning and Auto Maintain modes.
Analyze: blue pulsing
Charge: solid red
Conditioning: solid amber
Auto Maintain: solid green
Fault: OFF
Turn ON (green) when the charger is connected to a battery.
Turn ON (blue) when AC power is present.
Check warning LED will illuminate red only if there is a
connection or battery problem requiring attention
to view your battery charge level. AC power must be
removed and ENGINE MUST BE OFF to have the charger
identify the state of charge of your battery before charging.
During charging: This push button is disabled.
Illuminated LEDs indicate empty to full pre-charge status,
charge and auto-maintain mode gauge.
During Charging: Gauge displays battery charging (fill) level.
Without AC power (when the Pre-Charge Status push
button is pushed): Gauge display battery State of
Charge (SOC).
Selection of Charge Profiles by battery type
®
(OPTIMA LiFePO4, AGM, Flooded Lead-Acid).
®
For OPTIMA ORANGETOP HYPERCORE ™ lithium
iron phosphate (LiFePO4) battery.
®
For OPTIMA REDTOP, BLUETOP and YELLOWTOP AGM
STARTING batteries or other High Performance
starting AGMs.
For standard 12V motorcycle, power sports, tractor
(small) AGM and flooded batteries. Up to 40 amp hour
rated batteries.
Stores AC and DC cables when not in use.
Convenient wall organizer bracket for storage or location
near vehicle. Mounting screws are included.
®
For powering the OPTIMA D200+.
