Trouble Shooting
Other General Trouble Shooting Steps:
Note 1: To reset the charger at any time, unplug the charger and wait until the BLUE AC power
indicator is completely off. For typical negative chassis ground applications, disconnect the
battery by removing the BLACK NEGATIVE (NEG, N, -) cable clamp followed by the RED POSITIVE
(POS, P, +) cable clamp. Re-connect your battery, apply AC power per the guidelines of this
manual and re-start the function of your choice.
Note 2: For instances where the charger is properly connected and the AC power cord is plugged
into a properly protected 120 VAC GFCI outlet, there are NO LEDs ON, and the status bar is not
on, follow these steps:
1. Confirm the GFCI protected outlet has not tripped due to a ground fault.
2. Confirm there is 120 VAC present by plugging in a table lamp or meter.
3. Reset and apply power to resume using the OPTIMA
4. If power is present and there are still no LEDs ON and the status bar is not ON, then
follow the customer service return steps on page 25 for service.
23
®
D200+.
Storage, Care and Technical Specifications
Store your OPTIMA ® D200+ in a dry safe location, and inspect all cables before use.
Should the AC power cord, plug or the DC cables be damaged in any way, do not attempt
to service. Follow the return instructions in the customer service and warranty section
of this manual.

Technical Specifications:

AC Input: 100 to 120 VAC, 60 Hz, 0.7 Amps
DC Output: Up to 14.75 VDC Digitally & Temperature Controlled
Charge Mode: Up to 2 Amps
®
Battery Types: OPTIMA LiFePO4, AGM and Flooded (Lead Acid) Batteries
- 12V OPTIMA ® Lithium Iron Phosphate (LiFePO4) Batteries
- 12V OPTIMA ® and High Performance AGM Batteries
- 12V Standard Flooded Lead Acid Batteries
Cables: 6' AC and DC Cables
Size: 6" x 5.5" x 2.2"
This device complies with part 15B of the FCC rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause
undesired operation.
Certified to:
UL 1236
CSA C22.2 No. 107.2
FCC Part 15 Class B
BC
OPTIMA Chargers, OPTIMA Batteries, The Ultimate Power Source, SPIRALCELL Technology, REDTOP,
YELLOWTOP, BLUETOP and ORANGETOP are trademarks of Clarios, Inc.
24
