Rondish WCP-11 User Manual

Version: 0.2
Date: 2019-02-11
Page: 1 of 3

1. Power up

a. Apply CR2477 x2
b. Red led will stay ON with a beep sound
c. WCP-11 will transmit battery return signal
d. After transmission finished, led will go OFF
2.

Programming WCP-11

A. Entering programming mode:
1. Apply magnet on WCP-11
2. LED will flash
3. Press and hold the "CALL" button
4. When LED stays ON, release both the button and magnet
5. Now it is in programming mode
B. Programming WCP-11 parameters
1. Enter the password: 36
a Press call key 3 times and apply magnet to confirm the password 3
b Press call key 6 times and apply magnet to confirm the password 6
c If password is wrong, it will exit the programming mode
d If password is correct, it will continue the programming mode
2. Enter:
3. After entering the value, the red led will flash and then exist the programming mode
Remarks:
D1 D2
D3D4D5D6D7
T
C.

Auto-exiting programming mode:

a In programming mode, if WCO-11 is left in-active for about 30 seconds
b The red led will flash 3 times
c WCP-11 exit programming mode automatically
WCP-11 User Manual
D1D2-D3D4D5D6-T
= 2 digits for group number
= 4 digits for ID number
= 1 digit for tracking function ON or OFF (0 = OFF, 1 = ON)
25 – 35 sec
RONDISH PROPERTY and CONFIDENTIA
D1D2 = group number
D3D4D5D6 = ID number
T = tracking function
