  • Page 1 Owner’s Manual & Safety Instructions Save This Manual Keep this manual for the safety warnings and precautions, assembly, operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the back of the manual near the assembly diagram (or month and year of purchase if product has no number). Keep this manual and the receipt in a safe and dry place for future reference.

  • Page 2: Important Safety Information

    IMPORTANT SAFETY INFORMATION 1. Study, understand, and follow all instructions 12. Keep clear of load while lifting and lowering. before operating this device. 13. Lower load slowly. 2. Do not exceed rated capacity. 14. Apply parking brake and chock tires before lifting vehicle.
  • Page 3 WARNING SYMBOLS AND DEFINITIONS This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. Indicates a hazardous situation which, if not avoided, will result in death or serious injury.

  • Page 4: Specifications

    Specifications Weight Capacity 3 Tons Weight Capacity (lb.) 6,000 Maximum Height (in.) 24.25 Minimum Height (in.) 3.25 Handle Length (in.) 50.125 Front Wheel Diameter (in.) 2.58 Front Wheel Width (in.) 1.20 Rear Caster Diameter (in.) 2.83 Rear Caster Width (in.) 2.00 Saddle Pad Size (in.) 3.87 x 3.87 sq.
  • Page 5 Overview Handle Foam Bumper Socket Handle Handle Release Bolt Lift Arm Saddle Foot Pedal Item 56641 For technical questions, please call 1-888-866-5797. Page 5...

  • Page 6: Attaching The Handle

    Set Up Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this manual including all text under subheadings therein before set up or use of this product. Removing Shipping Clip CAUTION! The Handle socket may be held down by a clip under tension. Wear ANSI- approved safety goggles before freeing Handle socket.

  • Page 7: Operation

    Operation Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this manual including all text under subheadings therein before set up or use of this product. Lifting Park vehicle on a flat, level, solid, surface safely away from oncoming traffic. Turn off the vehicle’s engine. Place the vehicle’s transmission in “PARK”...

  • Page 8: Maintenance And Servicing

    Maintenance and Servicing Procedures not specifically explained in this manual must be performed only by a qualified technician. TO PREVENT SERIOUS INJURY FROM TOOL FAILURE: Do not use damaged equipment. If abnormal noise or vibration occurs, have the problem corrected before further use. 1.

  • Page 9: Troubleshooting

    Troubleshooting TO PREVENT SERIOUS INJURY: Use caution when troubleshooting a malfunctioning jack. Stay well clear of the supported load. Completely resolve all problems before use. If the solutions presented in the Troubleshooting guide do not solve the problem, have a qualified technician inspect and repair the jack before use. After the jack is repaired: Test it carefully without a load by raising and lowering it fully, checking for proper operation, BEFORE RETURNING THE JACK TO OPERATION.

  • Page 10: Parts List

    Parts List and Diagram Parts List Part Description Qty. Part Description Qty. Saddle Screw Hydraulic Unit Saddle Lower Handle Foam Bumper Lift Arm Handle Lock Button Retaining Ring 16 Upper Handle Front Wheel U-Joint Front Wheel Washer Roller Retaining Ring 20 Foot Pedal Frame Roller Pin...

  • Page 11: Assembly Diagram

    Assembly Diagram Item 56641 For technical questions, please call 1-888-866-5797. Page 11...

  • Page 12: Limited 90-Day Warranty

    Limited 90 Day Warranty Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase.
