GT Series Installation Manual
Model Numbers
*
GT12V450A-F24
GT12V525A-F24
GT12V600A-F24
GT24V300A-F24
GT48V150A-F24
GT51V150A-F24
GT12V600A-F27
GT24V300A-F27
GT48V150A-F27
GT51V150A-F27
*See Table 1 for model number details
R12 – 12/24/2019
MiniBMS OptoLoop
®
TECHNOLOGY
®
TECHNOLOGY
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GT12V525A-F24 and is the answer not in the manual?

Questions and answers

Summary of Contents for Lithionics Battery GT12V525A-F24

  • Page 1 GT Series Installation Manual Model Numbers GT12V450A-F24 GT12V525A-F24 GT12V600A-F24 GT24V300A-F24 GT48V150A-F24 GT51V150A-F24 GT12V600A-F27 GT24V300A-F27 GT48V150A-F27 GT51V150A-F27 *See Table 1 for model number details MiniBMS OptoLoop ® ® ® TECHNOLOGY TECHNOLOGY R12 – 12/24/2019...
  • Page 2: Important Safety Guidelines

    Important Safety Guidelines This guide contains important safety instructions for the GT Series Battery System that must be followed during installation procedures. Completely read this manual and become familiar with all system components before attempting installation. Save this installation manual for future reference. The following symbols and messages are used to identify potential hazards or to clarify the procedure.
  • Page 3 HAZARD OF ELECTROLYTE VAPOR • The battery module may emit a non-toxic pressurized electrolyte vapor if punctured. • Electrolyte vapor may cause temporary minor breathing congestion. • Electrolyte vapor can decrease visibility in closed compartments. HAZARD OF ELECTRIC SHOCK, EXPLOSION, OR ARC FLASH •...
  • Page 4: System Specifications

    1. System Specifications 1.1 Operating Specifications Table 1 GT12V-450A- GT12V-525A- GT12V-600A- GT24V-300A- GT48V-150A- GT51V-150A- GT12V-600A- GT24V-300A- GT48V-150A- GT51V-150A- System Model: F24-CTRL300 F24-CTRL300 F24-CTRL300 F24-CTRL300 F24-CTRL300 F24-CTRL300 F27-CTRL300 F27-CTRL300 F27-CTRL300 F27-CTRL300 External BMS External BMS External BMS External BMS External BMS External BMS Internal BMS Internal BMS...
  • Page 5 1.2 Arc Flash Energy Specifications • An arc flash is the light and heat produced from an electric arc supplied with sufficient electrical energy to cause substantial damage, harm, fire, or injury. An example of an arc flash event could be a direct short circuit caused by a metallic object such as a tool bridging between the positive and negative of an energized circuit.
  • Page 6: System Installation

    2. System Installation 2.1 Short Circuit Protection • The battery system must be protected by a DC fuse. The models listed in this document were evaluated and tested by Underwriter Laboratories with external fuses as noted. UL Listed (JDDZ) Class J Fuse, rated 300A, 450Vdc or UL Listed (JDDZ) Class T fuse rated 350A, 125Vdc.
  • Page 7 2.7 Pressure Vent • It is recommended to install a ventilation hose onto the pressure vent barb when the Battery Module is in a location with poor ventilation. The hose shall direct the gases to the atmosphere. 2.8 BMS Unit I/O Connector •...
  • Page 8: System Operation

    NOTE - The GT Series Lithium Battery System will disconnect power if the voltage, amperage, or temperature limits are exceeded during charging. Only use a Lithionics Battery approved charging source. Please contact Lithionics Battery for charger approval. 3.4 Initial Charging Cycle •...
  • Page 9 3.6 System Storage Procedure • Storing your battery at the correct specifications is important as it keeps the battery in the healthiest state possible for the fastest deployment when needed. • If the GT Series Lithium Battery System will not be in use for greater than 2 weeks, it is recommended to enable system storage.
  • Page 10 Figure 1: System Example Battery Module Pressure Vent Main Power Temperature Connectors Sensor Connectors NeverDie Disconnect Devices (See section 2.2 - Only applies to GT51V150A system) 300A Fast Acting Fuse GT Series Installation Manual...
