- Page 1 Installation Manual Model Numbers GT12V450A-F24 GT12V600A-F24 GT24V300A-F24 GT48V150A-F24 GT51V150A-F24 GT12V600A-F27 GT24V300A-F27 GT48V150A-F27 GT51V150A-F27 *See Table 1 for model number details MiniBMS OptoLoop ® ® ® TECHNOLOGY TECHNOLOGY R5 – 4/30/2018...
- Page 2 1. Important Safety Guidelines Voltage is present at the connector and output terminals. Always ensure that the 1.1 General BMS output terminals have the insulated • Completely read this manual before attempting protective boots in place. installation. Save this installation manual for Always use crimped connections to connect future use.
- Page 3 2. System Specifications 2.1 System Operating Specifications Table 1 GT12V-450A-F24- GT12V-600A-F24- GT24V-300A-F24- GT48V-150A-F24- GT51V-150A-F24- GT12V-600A-F27- GT24V-300A-F27- GT48V-150A-F27- GT51V-150A-F27- System Model: CTRL300 External CTRL300 External CTRL300 External CTRL300 External CTRL300 External CTRL300 Internal CTRL300 Internal CTRL300 Internal CTRL300 Internal Capacity 450Ah 600Ah 300Ah 150Ah...
- Page 4 • 3. System Installation Use 2 zip ties to bind the connectors together so that they may not separate during use. 3.1 Short Circuit Protection • The battery system must be protected by a 300A fast acting DC fuse, for example: 3.5 NeverDIE BMS Unit Power Terminals Fuse: Eaton DFJ-300...
- Page 5 Only use a Lithionics Battery approved fastest deployment when needed. charging source. Please contact Lithionics • If the GT Series Lithium Battery System will not Battery for charger approval.
- Page 6 that there is 0V at the Power Terminals with a voltmeter. • 4.4 System Storage Procedure (continued) Table 2 Storage < 1 Month -4~95°F (-20~35°C), 45~75%RH Temperature & Humidity Range < 3 Months 14~86°F (-10~30°C), 45~75%RH If the battery needs to be stored for > 3 months the voltage should be 13.2V for a 12V battery (or 3.3V x number of cells in series) (~50%SOC) and stored at the Long Term Storage recommended storage specifications shown above.
- Page 7 Figure 1: System Example Battery Module Pressure Vent Temperature Sensor Connectors Main Power Connectors NeverDIE 300A Fast Acting Fuse...
