H3C WX5002 Access Controller
Installation Guide
Abstract
This document details the installation procedures for the WX5002 access controller.
Hangzhou H3C Technologies Co., Ltd.
http://www.h3c.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WX5002 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for H3C WX5002

Summary of Contents for H3C WX5002

  • Page 1 H3C WX5002 Access Controller Installation Guide Abstract This document details the installation procedures for the WX5002 access controller. Hangzhou H3C Technologies Co., Ltd. http://www.h3c.com...
  • Page 2 However, the statements, information, and recommendations in this document do not constitute a warranty of any kind, express or implied. Hangzhou H3C Technologies Co., Ltd. and its licensors shall not be liable for technical or editorial errors or omissions contained herein.

  • Page 3: Table Of Contents

    Table of Contents 1 Product overview ··············································································································· 6 Physical Properties ························································································································ 6 Front panel······························································································································ 6 Rear panel ······························································································································ 7 2 Installation preparations ······································································································ 9 Unpacking and inspection ·········································································································· 10 Installation site examination ········································································································ 10 Installation tools·························································································································· 10 3 Installation ························································································································11 Installing the access controller onto a 19-Inch rack ·······································································...
  • Page 4 Power-on the access controller······························································································· 31 Software maintenance ··············································································································· 33 5 Support and other resources ······························································································34 Related documentation ············································································································· 34 Contacting H3C ························································································································· 34 Obtaining documentation ····································································································· 34 Technical support ·················································································································· 35 Documentation feedback ····································································································· 35 Document conventions and symbols ··························································································· 35 Conventions ··························································································································...
  • Page 5 Requirements on temperature and humidity ················································································ 50 Requirements on cleanness ········································································································ 50 Anti-static requirements ·············································································································· 51 Generation and damage of static electricity ··········································································· 51 Protection measures ·············································································································· 51 Wearing ESD-preventive wrist strap·························································································· 52 Electromagnetic environment requirements ················································································· 53 Laser safety ································································································································ 53 Index ···························································································································54...

  • Page 6: Product Overview

    Product overview The H3C WX5002V2 access controller is a new-generation wireless access controller product developed by Hangzhou H3C Technologies Co., Ltd. The WX5002V2 provides two groups of combo ports. The WX5002V2 also provides an expansion slot for an additional card. This provides not only strong processing capability but also flexible system configuration schemes.

  • Page 7: Rear Panel

    Figure 1 Front panel of the WX5002V2 (1) (2) (5) (6) (8) (9) (10) (12) (11) (13) (1) Gigabit Ethernet interface 2—SFP optical interface (2) 1000 Mbps LED of gigabit Ethernet interface 2 (3) 10/100 Mbps LED of gigabit Ethernet interface 2 (4) 10/100/1000 Base-T auto-sensing Ethernet electrical interface 2 (5) Gigabit Ethernet interface 1—SFP optical interface (6) 1000 Mbps LED of gigabit Ethernet interface 1...
  • Page 8 OPEN BOOK and CAUTION signs: Refer to related sections when performing the following operations: Table 1 OPEN BOOK sign description Operation Related section Connect the power cord Connecting the AC power cord Ground the device Connecting the ground wire For technical specifications of the WX5002V2, see Appendix C...

  • Page 9: Installation Preparations

    Installation preparations WARNING! Installation and removal of the unit and its accessories must be carried out by qualified personnel. Read all of the Safety Instructions supplied with your device before installation and operation. WARNUNG! Installation und Ausbau der Anlage und ihrer Zubehörteile müssen von qualifiziertem Personal realisiert werden.

  • Page 10: Unpacking And Inspection

    The accessories vary with the models. For the exact contents of the package, refer to the packing list. If the contents do not match the packing list, contact your H3C representative. If the package is found to be rusted or water soaked, stop unpacking and contact your H3C representative immediately.

  • Page 11: Installation

    Installation CAUTION: If you are going to have an H3C agent maintain your access controller, ensure that the dismantlement-preventive seal on a mounting screw of the access controller chassis is intact. If you want to open the chassis, you should contact H3C for permission. Otherwise, you are responsible for consequences resulting from your actions.
  • Page 12 Figure 4 Rear mounting bracket (1) Screw hole for fixing the rear mounting bracket to the rack (use M6 screws) (2) Heat dissipation hole Installation procedure Put on the EAD-preventive wrist strap and check that the rack is sturdy and properly grounded.
  • Page 13 NOTE: There are three screw holes on both the right and left sides of the rear, and upper part of the access controller for installing the bearing screws. Locate the proper hole to install a bearing screw to each side. The rear mounting brackets can support the weight of the access controller. Determine the position for installing the access controller on the rack.
  • Page 14 Figure 8 Installation with front and rear mounting brackets (1) Front mounting bracket (2) Front square-hole rack rail (3) Bearing screw (4) Screw for fixing the rear mounting bracket to the rear square-hole rack rail (5) Rear mounting bracket (6) Rear square-hole rack rail After the access controller is pushed in, make sure that the upper side of the rear mounting brackets and the bearing screws are closely touched (see Figure 9...
  • Page 15 Figure 9 Installation with front and rear mounting brackets (1) Rear square-hole rack rail (2) Bearing screw (3) Rear mounting bracket Use screws and the corresponding cage nuts to fix the front mounting brackets to the front square-hole rack rails, so that the front and rear mounting brackets fix the access controller on the rack horizontally (see Figure 10...

  • Page 16: Installing The Access Controller With Front Mounting Brackets And A Tray

    Figure 10 Installation with front and rear mounting brackets (1) Front square-hole rack rail (2) Front mounting bracket Installing the access controller with front mounting brackets and a tray NOTE: The tray is an optional component and must be separately ordered. Put on the EAD-preventive wrist strap and check that the rack is sturdy and properly grounded.
  • Page 17 Figure 11 Install a tray Place the access controller on the tray horizontally. Gently push the access controller into the rack along the tray, and then use screws and the corresponding cage nuts to fix the front mounting brackets to the front square-hole rack rails of the rack (see Figure 12 Figure 12 Installation with front mounting brackets and a tray...

  • Page 18: Installing The Access Controller With Mounting Brackets And Slide Rails

    Slide rails are optional components, which need to be separately ordered if needed. H3C slide rails are suitable for only the H3C standard racks with a depth of 1000 mm (39.37 in.). If the depth of your rack is different, substitute other supports for the slide rails.
  • Page 19 Figure 14 Install slide rails Hold the two sides of the access controller with both hands and gently slide the access controller into a proper position on the rack (see Figure 15 Make sure that the bottom of the access controller touches the slide rails. Figure 15 Installation with front mounting brackets and slide rails NOTE:...

  • Page 20: Installing The Access Controller On A Workbench

    Figure 16 Installation with front mounting brackets and slide rails Installing the access controller on a workbench If the standard 19-inch rack is not available, you can install the access controller on a clean workbench. When installing the access controller on a workbench: ...
  • Page 21 WARNING! The correct connection of the protection ground (PGND) wire of the access controller is an essential safeguard against lightning strikes and electromagnetic susceptibility (EMS) interference. You must first correctly connect the PGND wire when installing the access controller. The power input end of the access controller is connected with a noise filter; its central ground is directly connected to the chassis, forming the chassis ground (also known as PGND).

  • Page 22: When A Grounding Strip Is Unavailable

    WARNING! The ground wire of the access controller should be connected to the grounding system in the equipment room. The fire main and lightning rod of a building are not good grounding options. When a grounding strip is unavailable If earth is available nearby and the grounding body can be buried, hammer an angle steel or steel pipe longer than 0.5 m (1.64 ft) into the earth.

  • Page 23: Connecting The Power Cord

    Figure 19 Ground the access controller through an AC PE wire (1) Power transformer (2) AC power socket (3) Grounding terminal (4) Three-core AC power cord (5) PE wire Connecting the power cord WARNING! Make sure that the ground wire is properly connected before powering on the access controller. If the device is AC-powered, connect the device with an external AC power system through an AC power cord;...

  • Page 24: Connecting The Dc Power Cord

    Figure 20 Install the AC power cord retainer (3) (4) (1) Rear panel (2) Power cord retainer slot (3) AC power cord retainer (4) AC power cord Check the corresponding PWR LED on the front panel of the access controller. If the LED is solid green, the AC power input is normal.

  • Page 25: Connecting Interface Cables

    Figure 21 Connect the DC power cord Connecting interface cables Connecting the console cable Select a terminal for configuration. The terminal can be a character terminal with a standard RS232 serial port or a PC. A PC is used in this example. Connect the console cable Power off the access controller, connect the DB-9 female connector of the console cable to the serial interface of the PC, and connect the RJ-45 connector of the...

  • Page 26: Connecting The Ethernet Cable To An Ethernet Electrical Interface

    Figure 22 Connect the console cable (1) RJ-45 connector (2) Console port (3) DB-9 (female) connector (4) Serial interface of the configuration terminal (5) Console cable NOTE:  When connecting a PC to the access controller, first connect the DB-9 connector of the console cable to the PC, and then the RJ-45 connector to the console port of the access controller.
  • Page 27  The Tx and Rx connectors are correctly connected.  The fiber ends are clean. To connect a 1000 Mbps optical interface: Align the end without a handle of an SFP module with an SFP interface and carefully insert the SFP module into the SFP interface. Figure 23 Insert an SFP module Distinguish between the Rx and Tx interfaces on the SFP module.

  • Page 28: Checking The Installation

    Figure 24 Plug LC connectors Power on the access controller and check the SFP interface LEDs. For description of SFP LED status, see ―LEDs‖ on page 43. Checking the installation After installation, make sure that:  The correct power supply is used. ...

  • Page 29: Initial Startup

    Initial startup Setting up the configuration environment Connecting a configuration terminal to the access controller For information on how to connect a configuration terminal to the access controller, see ―Connecting interface cables,‖ on page 25. Setting terminal parameters Start the PC and run the terminal emulation program, such as the Terminal of Windows 3.1 or the HyperTerminal of Windows 95/98/NT/2000/XP.
  • Page 30 Figure 26 Select the serial interface used for HyperTerminal connection The system displays the port settings (see Figure 27 Set Bits per second to 9600, Data bits to 8, Parity to None, Stop bits to 1, and Flow control to None. To use the default settings, click Restore Defaults.

  • Page 31: Powering On The Access Controller

    The system displays the HyperTerminal interface. Select File > Properties > Settings in the HyperTerminal to enter the properties setting window (see Figure 28 Select VT100 as the terminal emulation, and click OK. Figure 28 Set terminal emulation Powering on the access controller Check before power-on Before powering on the access controller, verify that: ...
  • Page 32 Done! ************************************************************************** H3C WX5002 BootWare, Version 1.06 ************************************************************************** Copyright (c) 2004-2009 Hangzhou H3C Technologies Co., Ltd. Compiled Date : Nov 9 2009 CPU Type : XLR716 CPU L1 Cache : 32KB CPU Clock Speed : 800MHz Memory Type : DDR2 SDRAM...

  • Page 33: Software Maintenance

    Press Enter. The following prompt is displayed: <H3C> The prompt indicates that the system has entered user view and you can configure the access controller now. Software maintenance For WX5004 software maintenance information, see H3C WX Access Controller Software Maintenance Guide.

  • Page 34: Support And Other Resources

    WX series access controllers. Contacting H3C Obtaining documentation You can access the most up-to-date H3C product documentation on the World Wide Web at http://www.h3c.com. Click the links on the top navigation bar to obtain different categories of product documentation: Technical Support &...

  • Page 35: Technical Support

    Technical support customer_service@h3c.com http://www.h3c.com Documentation feedback You can e-mail your comments about product documentation to info@h3c.com. We appreciate your comments. Document conventions and symbols Conventions Convention Element Blue text: Table 24 Cross-reference links and email addresses Blue underlined text: Website addresses http://www.hp.com...

  • Page 36: Symbols

    Symbols WARNING! Indicates that failure to follow directions could result in bodily harm or death. CAUTION: Indicates that failure to follow directions could result in damage to equipment or data. IMPORTANT: Provides clarifying information or specific instructions. NOTE: Provides additional information. TIP: Provides helpful hints and shortcuts.

  • Page 37: A Installation Of Lightning Arrester For Network Interfaces

    A Installation of lightning arrester for network interfaces  You can install a lightning arrester for each 10/100 Mbps electrical Ethernet interface supporting RJ-45 connectors.  A lightning arrester for network interface is not supplied with the access controller. When an outdoor network cable is attached to the access controller, to prevent possible damages to the access controller due to lightning strike, serially connect the lightning arrester for the network interface before you plug the outdoor cable into the access controller.

  • Page 38: Precautions

    to the arrester while OUT end of the cable is connected to the access controller. After the connection, check whether the LEDs of the interface modules are normal. NOTE: Technical parameters, installation and maintenance methods of an arrester have been provided in the arrester instructions.
  • Page 39 lightning arrester for each of the network interfaces to guard the interfaces against possible damages.

  • Page 40: B Installation Of Lightning Arrester For Ac Power

    B Installation of lightning arrester for AC power NOTE: A lightning arrester (lightning protection grounding strip) is not supplied with the access controller. If an outdoor AC power cable is directly led to the access controller, to prevent possible damages to the access controller due to lightning strike, serially connect the lightning arrester for AC power (lightning protection grounding strip) before you plug AC power cable into the access controller.
  • Page 41 Note the following: Make sure that the PE terminal of the arrester is well grounded before using the lightning arrester for power. Upon plugging the AC power cable connector of the access controller into the receptacle of the lightning arrester, if the green LED is on while the red LED does not alarm, it means that the lightning arrester of power is running and the function of lightning protection has taken effect.

  • Page 42: C Technical Specifications

    C Technical specifications Processor and storage Table 2 Processor and storage of the WX5002V2 Item Description Processor XLR716 (800 MHz) CF card Built in, 256 MB Memory: DDR2 SDRAM Memory type and capacity Capacity: 1024 MB Dimensions and weight Table 3 Dimensions and weight Item Description...

  • Page 43: Power Input

    Power input The WX5002V2 uses two AC/DC PSUs, which provide 1+1 redundancy backup for the WX5002V2 to enhance system reliability. Table 5 AC/DC power input Item Description For AC power input: 100 VAC to 240 VAC, 50 Hz or 60 Hz Rated voltage range For DC power input: –48 VDC to –60 VDC For AC power input: 90 VAC to 264 VAC, 47 Hz to 63 Hz...
  • Page 44 Table 6 Description of LEDs LEDs Silkscreen Status Description PSU 1 supplies power to the system Solid green normally. LED of PSU 1 PWR1 Solid yellow PSU 1 is faulty. (green/yellow) No PSU is installed in the slot. PSU 2 supplies power to the system Solid green normally.

  • Page 45: Fixed Interfaces

    Fixed interfaces Console port The WX5002V2 provides an RS232 asynchronous serial port (console port) that can be connected to a computer for system debugging, configuration, maintenance, management, and host software loading. The console cable is an 8-core cable. One end of the cable is a crimped RJ-45 connector and is connected to the console port of the WX5002V2.
  • Page 46 optical interface form a combo port, which is marked in a white box on the front panel. Only one interface (either electrical or optical) of a combo port can be used at a time.  Ethernet electrical interfaces support 10/100/1000 Mbps autosensing. Table 8 describes the working mode of the interfaces in each speed.
  • Page 47 Full duplex NOTE: An SFP module is not shipped with the WX5002V2. You must purchase SFP modules as needed. It is recommended that you use H3C SFP modules. RJ-45 connector The 10/100/1000 Mbps electrical Ethernet interfaces of the WX5002V2 use RJ-45...
  • Page 48 The Ethernet optical interfaces of the WX5002V2 support LC connectors only. Figure 34 LC connector Before using an optical fiber to connect a network device, make sure that the optical fiber connector matches the optical module. Before connecting the fiber, make sure that the receiving-end optical power does not exceed the upper threshold of the receiving optical power.

  • Page 49: Fans

    When preparing Ethernet cables, follow the chromatogram provided in the table to arrange the wires. Otherwise, communication quality will be affected even if the devices at both ends are connected. Table 10 Straight-through cable pinouts Category-5 RJ-45 Signal Signal direction RJ-45 twisted pair White (Orange)

  • Page 50: Interface Numbering

    Interface numbering The WX5002V2 provides four fixed GE interfaces numbered GigabitEthernet 1/0/1 and GigabitEthernet 1/0/2, with the last part of the port numbers indicated on the front panel. Requirements on temperature and humidity To ensure the normal operation and service lifetime of the access controller, proper temperature and humidity should be maintained in the equipment room.

  • Page 51: Anti-Static Requirements

    Physical active substance Concentration limit (particles/m Note: The dust particle diameter is ≥ 5 μm Besides the dust specifications, the equipment room of the access controller also needs to strictly meet the requirements on the concentration of salt, acid and sulfide. These harmful gases can accelerate the metallic corrosion and the aging process of some parts (see Table 14 Table 14...

  • Page 52: Wearing Esd-Preventive Wrist Strap

     Wear ESD-preventive gloves or an ESD-preventive wrist strap and uniform when handling the circuit board.  Hold the interface module only by its edge when installing, observing or removing it. Do not touch the components on it.  Place the removed interface module on an ESD-preventive workbench with the component-side facing upward or place it in an antistatic bag.

  • Page 53: Electromagnetic Environment Requirements

    Electromagnetic environment requirements The operation of your access controller may be affected by external interferences, such as capacitance coupling, inductance coupling, electromagnetic wave radiation, common impedance (including the grounding system) coupling, and the conducted interference of leads (power cords, signaling cables and output wires). To eliminate the interferences: ...
