QUICK START GUIDE
1000 Series • 115 V / 60 Hz

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UADA24RINT00A and is the answer not in the manual?

Questions and answers

Related Manuals for U-Line UADA24RINT00A

Summary of Contents for U-Line UADA24RINT00A

  • Page 1 QUICK START GUIDE 1000 Series • 115 V / 60 Hz...
  • Page 2 U-Line Customer Care must be contacted immediately at +1.414.354.0300. Service or repairs performed on the unit without prior written approval from U-Line is not permitted. If the unit has been altered or repaired in the field without prior written approval from U-Line, claims will not be eligible.

  • Page 3: Table Of Contents

    9. Integrated Panel Installation 11. Control Operation 13. First Use 14. Warranty 1 year + 1 with registration This product is eligible for an additional one-year warranty at no charge when you register your product on u-line.com. See complete warranty for details.

  • Page 4: Safety And Warning

    QUICK START GUIDE QUICK START GUIDE u-line.com u-line.com Safety and Warning DANGER NOTICE This unit contains R600a (Isobutane) which is a Please read all instructions before installing, flammable hydrocarbon. It is safe for regular operating, or servicing the appliance. use. Do not use sharp objects to expedite defrosting.

  • Page 5: Environmental Requirements

    QUICK START GUIDE QUICK START GUIDE u-line.com u-line.com Environmental Requirements OUTDOOR UNITS This unit is designed to operate between 50°F (10°C) and 115 V UNITS 100°F (38°C). Higher ambient temperatures may reduce This model is intended for indoor/interior applications only the unit’s ability to reach low temperatures and/or reduce...

  • Page 6: Electrical

    QUICK START GUIDE QUICK START GUIDE u-line.com u-line.com Electrical Door Swing WARNING Wall Wall 1/4" Min. 2-1/8" Min. (6 mm) (54 mm) SHOCK HAZARD — Electrical Grounding Required. Never attempt to repair or perform maintenance on the unit until the electricity has been disconnected.

  • Page 7: Door Adjustments

    These general instructions apply to all models. For further details, see user guide for your specific model at u-line.com. Align and adjust the door if it is not level or is not sealing properly. If the door is not sealed, the unit may not cool properly, or excessive frost may form in the interior.
  • Page 8 QUICK START GUIDE QUICK START GUIDE u-line.com u-line.com 3. Remove door by tilting forward and lifting door off 2. Remove magnet assembly from door with T-10 TORX bottom hinge. Retain shoulder washers; they will driver. Be sure to only remove the two screws holding be reused.
  • Page 9 TO ALIGN AND ADJUST THE DOOR 24” Models These general instructions apply to all models. For further details, see user guide for your specific model at u-line.com. Remove grille: Remove the grille (see GRILLE-PLINTH INSTALLATION section of this guide). 1. Loosen (do not remove) top and bottom hinge screws using a Torx T-25 screwdriver.
  • Page 10 QUICK START GUIDE QUICK START GUIDE u-line.com u-line.com 3. Flip hinge plate over and reinstall on opposite side. Prepare door for reinstallation: 1. Remove gasket. This will reveal mounting holes for the magnet assembly 2. Remove plunger bracket from door with T-10 TORX driver.

  • Page 11: General Installation

    QUICK START GUIDE QUICK START GUIDE u-line.com u-line.com General Installation INSTALLATION 1. Plug in the power/electrical cord. 2. Gently push the unit into position. Be careful not to LEVELING INFORMATION entangle the cord. 1. Use a level to confirm the unit is level.

  • Page 12: Integrated Panel Installation

    4. Upon removal, lay gasket using clamps. A down on a flat surface. robust tape may also be used. U-Line recommends the use 5. Partially loosen the 3 screws, securing the top hinge to of bar clamps to the cabinet.
  • Page 13 QUICK START GUIDE QUICK START GUIDE u-line.com u-line.com 13.Be sure the screws force their way past the opening on the gasket channel and sit flush against the bottom of the channel. Integrated Panel Integrated Panel 14.Remove clamps from door/drawer. If panel requires additional adjustment after removing clamps, slightly loosen each screw and adjust panel as necessary.

  • Page 14: Control Operation

    QUICK START GUIDE USER GUIDE u-line.com u-line.com Control Operation CONTROL FUNCTION GUIDE FUNCTION COMMAND NOTES ON/OFF Press and hold down for 5 seconds Unit will turn On or OFF Press and release to leave interior After 3 hours, factory default is restored; light will Leave interior light on light on for 3 hours;...
  • Page 15 QUICK START GUIDE USER GUIDE u-line.com u-line.com Control Operation CONTROL FUNCTION GUIDE FUNCTION COMMAND NOTES ON/OFF Press and release Unit will immediately turn On or OFF Press and release to leave interior After 12 hours, factory default is restored; light will Leave interior light on light on for 12 hours;...

  • Page 16: First Use

    QUICK START GUIDE QUICK START GUIDE u-line.com u-line.com First Use All U-Line controls are preset at the factory. Initial startup requires no adjustments. NOTICE U-Line recommends allowing the unit to run overnight before loading with product. 1200 SERIES When plugged in, the unit will begin operating under the factory default settings.
  • Page 17 For products installed and used for normal residential use, material cosmetic defects are included in this warranty, with coverage limited to 60 days from the date of original purchase. All service provided by U-Line under the above warranty must be performed by a U-Line factory authorized servicer, unless otherwise specified by U-Line.
