Jonsered CS 2258 Workshop Manual

Hide thumbs Also See for CS 2258:
Table of Contents

Advertisement

Quick Links

CS 2258
CS 2260
CS 2260WH
Workshop manual
115 49 43-26

Advertisement

Table of Contents
loading

Related Manuals for Jonsered CS 2258

Summary of Contents for Jonsered CS 2258

  • Page 1 CS 2258 CS 2260 CS 2260WH Workshop manual 115 49 43-26...
  • Page 3 Service data ............14 Safety equipment ..........16 Repair instructions ..........24 Carburettor ............34 Troubleshooting........... 62 Jonsered has a policy of continuous product development and therefore reserves the right to modify the design and appearance of products without prior notice. English -...
  • Page 4 Index Index Muffler 21 Bar bolt 63 Assembling the muffler 21 Replacing the bar bolt 63 Dismantling the muffler 21 Carburettor 34 Assembly 38 Oil pump and screen 33 Cleaning and inspection 38 Assembling the oil pump and screen 34 Design 34 Cleaning and inspection 33 Dismantling the oil pump and screen 33...
  • Page 5 Index Vibration damping system 45 Assembly 45 Cleaning and inspection 45 Dismantling 45 English -...
  • Page 6 Introduction and safety instructions 2 Introduction and safety regulations Contents General ...........................7 Safety ..........................7 Target group ........................7 Modifications........................7 Tools ..........................7 Structure .........................7 Numbering ........................7 General instructions ......................8 Special instructions ......................8 2.10 Symbols on the saw .......................9 2.11 Symbols in the Workshop Manual ..................9 - English...
  • Page 7 Introduction and safety instructions 2 Introduction and safety instructions 2.1 General 2.6 Structure This Workshop Manual describes in detail how This Workshop Manual can be used in two differ- to be troubleshoot, repair and test the chain saw. ent ways: A description of different safety steps that must be taken during repair work is also given.
  • Page 8 Introduction and safety instructions 2.8 General Instructions 2.9 Special Instructions The workshop where the chain saw is to be re- The fuel used in the chain saw has the following paired must be equipped with safety equipment in hazardous properties: accordance with local regulations.
  • Page 9 Introduction and safety instructions 2.10 Symbols on the saw 2.11 Symbols in the Workshop Manual The symbols below are embedded on the chain saw. This symbol warns of personal injury Choke Lever when the instructions are not followed. Use protective gloves. Refuelling Use protective goggles.
  • Page 10 Displacement Cylinder diameter Stroke length Max. output/speed cm3/cubic inch Ø mm/Ø inch mm/inch kW/hp/ rpm CS 2258: 59,8 / 3.65 46 / 1.81 36 / 1.42 3.1 / 4,2 / 9 600 CS 2260: 59,8 / 3.65 46 / 1.81 36 / 1.42...
  • Page 11 Technical data Engage speed Spark plug Type of oil pump CS 2258: 4 300 NGK CMR6H Adjustable CS 2260: 4 300 NGK CMR6H Adjustable CS 2260WH: 4 300 NGK CMR6H Adjustable Volume fuel tank Capacity oil pump at Volume oil tank Litre/US.
  • Page 12 Service tools 4 Service tools 4 mm 4 mm 5 mm - English...
  • Page 13 Service tools Pos Description Used for Order No. Piston stop Locking the crankshaft 575 29 36-01 Hook for fuel filter Suspending the fuel filter 502 50 83-01 Allen key, 4 mm For M5 bolts 502 50 87-01 Allen key, 4 mm For M5 bolts 502 50 18-01 Allen key, 5 mm...
  • Page 14 Service data 5 Service data 18-20Nm 16mm 12-14Nm 13mm 8-10Nm 4mm 1,5-2Nm 4mm 1-2Nm 16-20Nm 5mm 1-2Nm 14-16Nm 5mm 5-6Nm 4mm 4-5Nm 4mm 1-2Nm 11-13Nm 13mm 25Nm 1-3Nm The numbers by the components to be assembled with screws state the tightening torque in Nm.
  • Page 15 Service data 1-2Nm 7-9Nm 4mm 3-4Nm 4mm 9-11Nm 4mm 3-4Nm 4mm 22-25Nm 13mm 3-4Nm 4mm 9-11Nm 4mm 7-9Nm 4mm 3-4Nm 4mm 6-8Nm 4mm 5-6Nm 4mm 3-4Nm 4mm 7-9Nm 4mm 8-10Nm 4mm 3,5-4Nm 4mm 5-6Nm 4mm English -...

  • Page 16: Table Of Contents

    Safety equipment 6 Safety equipment Contents Dismantling the chain brake ...................17 Assembling the chain brake ....................18 Dismantling the muffler ....................19 Assembling the muffler ....................20 Replacing the chain catcher ...................20 Dismantling the start/stop control ...................20 Assembling the start/stop control ..................21 Resistance test - stop function ..................21 Dismantling the throttle control lock, throttle control and spring ........22 6.10 Assembling the throttle control lock, throttle control and spring ........23...

  • Page 17: Dismantling The Chain Brake

    Safety equipment 6 Safety equipment 6.1 Dismantling the chain brake Remove the cylinder cover. Release the brake by moving the front hand guard backward. Loosen the bar nuts and remove the clutch cover, Fig 1 bar and chain, see fig. 1. Alt.

  • Page 18: Assembling The Chain Brake

    Safety equipment 6.2 Assembling the chain brake Screw the knee joint and the brake band together (see figure 5) using a tightening torque of 1-1.5 Nm. Place the knee joint with the fitted chain brake band in the opening in the clutch cover. The space for the spring in the cover must be lubricated with grease.

  • Page 19: Dismantling The Muffler

    Safety equipment NOTE! After repairing, the chain brake must be in- spected in line with the instruction below. Functional inspection: Do not turn on the motor when carrying out this inspection. Bar length Height 38 cm/15” 50 cm/20" • Hold the chain saw over a stable surface. The distance between the bar and the surface is shown in the table above.

  • Page 20: Assembling The Muffler

    Safety equipment 6.4 Assembling the muffler If the saw is fitted with a spark arrestor mesh, put it in place first. When fitting the mesh, make sure that the mesh is inserted in the right position. If necessary, use the combination spanner to insert the mesh.

  • Page 21: Assembling The Start/Stop Control

    Safety equipment 6.7 Assembling the start/stop control Fit the new stop control (A) and tighten screw (B) in place at a torque of 1 Nm. Slide in the stop con- trol in the rubber sleeve C and hook the sleeve on the guide taps.

  • Page 22: Dismantling The Throttle Control Lock, Throttle Control And Spring

    Safety equipment 6.9 Dismantling the throttle control lock, throttle control and spring Loosen the screw on the rear handle. Remove the handle insert (A). See figure 19. Fig 19 Loosen the throttle control lock (B) as shown in the figure using a screwdriver or similar tool. Remove it then from the shaft in the handle.

  • Page 23: Assembling The Throttle Control Lock, Throttle Control And Spring

    Safety equipment 6.10 Assembling the throttle control lock, throttle control and spring Lubricate the pin and joined surfaces with a light oil. Hook on the throttle cable (D). Slide in the throttle control and make sure the spring is fitted as outlined in figure 24.
  • Page 24 Repair Instructions 7 Repair instructions Contents Dismantling the starter ....................25 Replacing a broken or worn starter cord ................26 Tensioning the return spring ...................26 Replacing a broken return spring ...................27 Starter assembly......................27 Dismantling the ignition module and flywheel ..............28 Assembling the ignition module and flywheel ..............29 Dismantling the centrifugal clutch ...................30 Assemby of centrifugal clutch ..................31 7.10...

  • Page 25: Repair Instructions

    Repair Instructions 7 Repair instructions 7.1 Dismantling the starter Loosen the four screws, which hold the starter against the crankcase and remove the starter. Pull the cord out about 30 cm and lift it into the notch on the outside of the starter pulley. Release the tension in the return spring by letting the starter pulley rotate anti-clockwise.

  • Page 26: Replacing A Broken Or Worn Starter Cord

    Repair instructions 7.2 Replacing a broken or worn starter cord When the starter cord is worn and must be replaced, the tension in the return spring must be released. Pull the cord out about 30 cm and lift it into the notch on the outside of the starter pulley.

  • Page 27: Replacing A Broken Return Spring

    Repair Instructions 7.4 Replacing a broken return spring WARNING! Exercise care to ensure the spring does not fly out and cause person- al injury. Wear protective goggles. Loosen the screw at the centre of the starter pulley and loosen the screws on the cassette. Remove the starter pulley with the cassette and spring.

  • Page 28: Dismantling The Ignition Module And Flywheel

    Repair Instructions 7.6 Dismantling the ignition module and flywheel Remove the cylinder cover. Remove the starter. Snap off the ignition cable from the guide rail and remove the guide rail. See figure 1. Fig 1 Knock out a few of the pins in the tool if it does not match up with the flywheel.

  • Page 29: Assembling The Ignition Module And Flywheel

    Repair Instructions 7.7 Assembling the ignition module and flywheel Run the cables through the opening in the crank- case. Screw the earth cable in place. See figure 1. Fit the cabling to the stop button. Position the cable channel as outlined in figure 1. NOTE! Take care that the cable channel is posi- tioned correctly under the ignition module so that the cables are not crushed.

  • Page 30: Dismantling The Centrifugal Clutch

    Repair Instructions 7.8 Dismantling the centrifugal clutch Remove the cylinder cover. Release the brake by moving the kickback guard backwards. Loosen the bar nuts and remove the clutch cover, chain and bar. See figure 1. Loosen the spark plug hat and remove the Fig 1 spark plug, and insert the plastic piston stop (575 29 36-01).

  • Page 31: Assemby Of Centrifugal Clutch

    Repair Instructions 7.9 Assembly of centrifugal clutch Insert the clutch springs on the side of the shoes without text. See figure 1. Screw in the clutch (anti-clockwise) until it stops. Then tighten the clutch using tool 575 25 14-01 Fig 1 and a suitable socket wrench or combination span- ner.

  • Page 32: Assembling The Oil Pump And Screen

    Repair Instructions 7.11 Assembling the oil pump and screen Lower the oil filter in place and replace the oil pump as outlined in figure 19 and tighten the screws. Fit the pump drive wheel, the needle bearing, the drive sprocket, the clutch drum and the clutch, us- ing a tightening torque of 25 Nm.

  • Page 33: Assembling The Intake System

    Repair Instructions Dismantle the air filter, the filter holder, the cable from the intake flange holder and the carburettor and the throttle cable as outlined in “Dismantling the carburettor”. NOTE! The lug on the carburettor sits on the bracket on the partition wall. Fig 24 Hook off the cabling from the holder on the intake system (J).

  • Page 34: Carburettor

    Repair Instructions 7.14 Carburettor WARNING! The fuel used in the chain saw has the following hazardous properties: 1. The fluid and its vapour are poisonous. 2. Can cause skin irritation. 3. Is highly inflammable. Description The figures accompanying this description do not correspond with the carburettor on the chain saw.
  • Page 35 Repair Instructions Function The carburettor operates differently in the following modes: • Cold start mode • Idling mode • Part throttle mode • Full throttle mode In cold start mode the choke valve H is completely shut. This increases the vacuum in the carburettor and fuel is easier to suck from all the diffuser jets D, E, and F.
  • Page 36 Repair Instructions Dismantling the carburettor Dismantle the cylinder cover and the air filter. Loosen the screws, F. Unhook the rubber attach- ment G on both sides. See Figure 35. Loosen the suction hose A, the return hose B, and the tank bleeding hose C. See figure 34. Fig 34 Remove the air filter holder.
  • Page 37 Repair Instructions Dismantle the pump cover H and carefully remove the control diaphragm J and gasket K. Unscrew screw P and remove needle valve M with lever arm Q, shaft L and spring R. Use a needle or similar device and carefully pull up the fuel screen (W).
  • Page 38 Repair Instructions Assembly Cleaning and inspection Observe cleanliness when assembling the car- Clean all units in clean petrol. burettor. The slightest contamination can result in downtime. Use compressed air to dry the petrol on the com- ponents. Direct the air through all channels in the 1.
  • Page 39 Repair Instructions 4. Assemble needle valve M with lever arm Q, shaft L and spring R, and tighten screw P. (Fit the expansion washer). See figure 40. Fig 40 5. Check using a ruler or the like that the lever is level with the assembly plane on the cover.
  • Page 40 Repair Instructions Pressure testing the carburettor Pressure testing should be carried out with the car- burettor fully assembled. Testing should always be carried out after the carburettor has been repaired, but a test can also be made for troubleshooting before dismantling. Option 1 See the figure and carry out the check as follows: Connect pressure tester to the carburettor fuel inlet.
  • Page 41 Repair Instructions Make sure the cabling is fitted to its mounting on the intake flange. Press the fuel hose (D) in place in the collar on the intake bellows. Hook on the throttle cable (E) in its mounting on the intake bellows. See figure 46. Make sure the lug on the carburettor hooks in place on its mounting on the intake system.

  • Page 42: Tank Unit

    Repair Instructions 7.15 Tank unit WARNING! The fuel used in the chain saw has the following hazardous properties: 1. The fluid and its vapour are poisonous. Can cause skin irritation. Is highly inflammable. Dismantling 1. Drain the fuel from the tank. 2.

  • Page 43: Vibration Damping System

    Repair Instructions Assembly 1. Thread the throttle cables in the connection M as outlined in figure 55. NOTE! The figure is shown from underneath. 2. Run the fuel hose D through hole K and hoses B and C in hole L. See figure 55. Pull the hoses so that the collars are on each side of the bottom on the carburettor compartment.

  • Page 44: Replacing The Fuel Filter

    Repair Instructions 7.18 Replacing the fuel filter NOTE! Fluted pliers may not be used with the fuel hose. They can cause material damage resulting in damage to the fuel hose. When replacing the fuel filter, the old fuel filter must be taken out of the tank unit using special tool 502 50 83-01.

  • Page 45: Heated Handles And Carburettor Heating

    Repair Instructions 7.21 Handle heater and carburettor heater (CS2260WH) Certain chain saw models can be fitted with a han- dle heater and a carburettor heater and comprise the following: • Generator • Power switch • Heating element in the rear handle •...
  • Page 46 Repair Instructions Carefully remove the power switch using a flat screwdriver or similar tool. See Figure 4 Fig 4 Check that the contact plate in the power switch is intact and free of dirt and oxidation. See Figure 5. Clean and assemble the power switch. Carry out a resistance test according to step 2.
  • Page 47 Repair Instructions Troubleshooting the heating element, rear handle Connect the multimeter as outlined in Figure 7 and measure the resistance in rear handle’s heating element. The multimeter reading should indicate between 0.5 and 1.2 Ohm. Replace the heating element if you get another reading. 0.5 - 1.2 Fig 7 Troubleshooting the heating element, front...
  • Page 48 Repair Instructions Troubleshooting the carburettor’s heating ele- ment and thermostat Connect the multimeter as outlined in Figure 10. The measurement should be carried out at normal room temperature (20°C/68°F) and should indicate in that case 0 A. Cool the thermostat for instance with a coolant spray or a similar agent.
  • Page 49 Repair Instructions Replacing the generator Dismantle the following parts: • Clutch cover • Bar and chain • Cylinder cover • Starter • Flywheel * * See the chapter “Dismantling the ignition module and flywheel.” Fig 13 Loosen the screws to the generator without remov- ing it.
  • Page 50 Repair Instructions Replacing the carburettor’s heating element and thermostat Remove the cylinder cover and air filter. Loosen the thermostat cable from the air filter holder as well as from the cabling in the front handle. Loosen the two screws holding the thermostat’s attachment bar and remove the thermostat.
  • Page 51 Fit the new heating element and make sure that no cables are pinched. See Figure 19. Connect the cable to the carburettor’s heating element as outlined in Figure 18. Fit the filter holder as outlined in Figure 17 and tighten screws F.

  • Page 52: Dismantling The Piston And Cylinder

    Repair Instructions 7.22 Dismantling the piston and cylinder Dismantle: • The cylinder cover • The carburettor (see “Dismantling the carburettor”) • The muffler • The vibration element • The spark plug cap • The intake system Unscrew the cylinder’s four screws and carefully lift away the cylinder and the gasket.
  • Page 53 Repair Instructions Check the following: • That the cylinder’s surface coating is not worn. Especially the upper part of the cylinder. • That the cylinder does not have any chafe or cutting marks. • That the piston is free of score marks. Minor scratches can be polished off using fine emery paper.

  • Page 54: Assembling The Piston And Cylinder

    Repair Instructions Faults and causes Score marks on the piston (A) 1 Leakage, check not carried out. 2 Too low octane fuel. 3 Too low or incorrect oil in the fuel. Carbon build-up (B) 1 Too much or incorrect oil in the fuel. See Figure 63.

  • Page 55: Pressure Testing The Cylinder

    Repair Instructions 7.24 Pressure testing the cylinder Loosen • The cylinder cover • The carburettor Attach the cover plate 574 71 14-01 and plug 578 02 13-01. See figure 66a. Fig 66a Loosen the screws on the muffler and press the cover plate 575 29 81-01 between the muffler and cylinder.

  • Page 56: Dismantling The Crankshaft And Crankcase

    Repair Instructions 7.25 Dismantling the crankshaft and crankcase Dismantle the following: • The clutch cover • The chain and bar. • The centrifugal clutch * • The cylinder cover • The starter * • The flywheel * • The carburettor * •...
  • Page 57 Repair Instructions If required, remove the crankshaft bearing from the crankcase. Proceed as follows: A. Remove the oil refill cap. B. Heat up the crankcase half in question to 200°C. C. Use protective gloves. Press the bearing out of the crankcase half. Fig 72 If the crankshaft bearings are still attached to the crankshaft when dismantling, pull them off using...
  • Page 58 Repair Instructions Assembly WARNING! Beware of burn injuries as the crankcase halves are hot. Wear protective gloves. Proceed as follows if a bearing must be fitted: A. Heat up the crankcase half in question to 200°C. B. Use protective gloves. Fit the bearing in the Fig 76 flywheel side of the crankcase half.
  • Page 59 Repair Instructions Assemble the following parts: A. Tank unit. B. Piston and cylinder. C. Muffler. D. Carburettor. E. Centrifugal clutch. F. Electrical System. G. Starter. H. Bar and chain. Sealing rings To replace the crankshaft’s sealing rings, first dis- mantle the following parts: On the flywheel side: •...

  • Page 60: Assembling The Complete Crankshaft

    Repair Instructions 7.26 Assembling a complete crankshaft Fit the complete crankshaft in the crankcase. Fit the following parts: • The piston and cylinder * • The fuel unit * • The handle system * • The muffler * • The hand guard * •...

  • Page 61: Replacing The Bar Bolt

    Repair Instructions 7.27 Replacing the bar bolt Replacing a bar bolt with intact crankcase Empty the oil tank. Knock in the old bar bolts from the outside so that they end up in the oil tank. Remove the bolts from the oil tank. Attach a wire to the head of the bar bolt, lower the wire through the oil tank and out through the bolt opening in the crankcase.
  • Page 62 Troubleshooting 8 Troubleshooting Contents Troubleshooting ......................63 Troubleshooting methods ....................64 - English...
