- Page 1 PLVW8M OWNER'S MANUAL TFT MONITOR www.pyleaudio.com...
-
Page 2: Installation
INSTALLATION The monitor (Fig.1) can be installed on the bracket (Fig.2). You can mount the unit according to the following steps. Position Plate Rotation Top 1. Insert the position plate on the bracket into the slot 1 on the mounting bracket. Then slide the position plate upward to the slot 2 and select the proper location. -
Page 3: Electrical Connection
ELECTRICAL CONNECTION To other DVD/VCD system REMOTE To the +12V power terminal Ground wire BLACK DC PLUG S-VIDEO IN VIDEO IN(YELLOW) AUDIO L IN(WHITE) AUDIO R IN(RED) -
Page 4: Location And Function Of Keys
LOCATION AND FUNCTION OF KEYS (Power Button) 2. Power Indicator Light 3. IR (Remote Sensor) 4. MENU 5. MUTE 6. VOLUME+ 7. VOLUME- 8. PICTURE+ 9. PICTURE- 10. 8 inch color TFT LCD 11. Speakers 12. Volume Knob Jacks for Earphone 14. - Page 5 LOCATION AND FUNCTION OF KEYS (Power) Press button (1) to turn on/off the unit. 2. POWER INDICATOR LIGHT When the system is on, the indicator light (2) will be illuminated. 3. REMOTE SENSOR For option, the monitor can be supplied with the remote control according to the user's need.
- Page 6 LOCATION AND FUNCTION OF KEYS 10. TFT LIQUID CRYSTAL DISPLAY The 8 inch TFT color LCD (10) can show the current state of the unit. 11. SPEAKER There are two speaks (11) on the front of the monitor. The sound can be sent from the speakers if the unit isn't connected with earphone.
-
Page 7: Troubleshooting
TROUBLE SHOOTING Before going through the checklist, check wiring connection. If any of the problems persist after checklist has been made, consult your nearest service dealer. NO POWER Check if the power button on the front of the monitor is set to on. Check if the wires of DC power plug are properly connected. - Page 8 BRACKET 3 (BKT3)
-
Page 9: Installation Hardware
INSTALLATION HARDWARE (11) (1) ASSY (Rotate combined bracket with Base A...1 (2) Base B... 1 (3) Plastic tube ( 13mm) ... 2 (4) Screw ( 3x10) ..4 Clip screw ...1 Fastener ...1 Fix bolt ... 2 Washer (a) (3mm thick) ...1 (9) Tray ... - Page 10 INSTALLATION 1. Press the switch under the headrest of the car seat and pull out the headrest. Headrest Switch 2. Combine the base B (2) and the base A with steel ripple pipe (1), then place them on the poles of the removed headrest to select proper hole position to install the base.
- Page 11 INSTALLATION 4. Place the Base on the poles of the removed headrest in good position, and then use four screws (3x10 (4) to fix the base A and base B. ø 5. Install the headrest with the Base to the car seat in proper position, then use the screwdriver to rotate the two screws tightly to fix the base.
- Page 12 INSTALL THE TV MONITOR OR THE CAMERA INSTALL THE TV MONITOR Insert the clip screw (5) into the hole on the tray with the washer (a) (8) between the clip screw (5) and the tray. Then aim the clip screw to the hole on the bottom of the TV monitor and rotate the clip screw to fix the TV monitor to the tray.
- Page 13 ADJUST THE ANGLE OF THE TV UNIT OR THE CAMERA 1. Rotate the clip screw to loosen the TV monitor or the camera, then rotate the TV monitor or the camera left or right to your need for good viewing angle and then rotate the clip screw tightly to fix the TV monitor or the camera.
- Page 14 ADDITIONAL MATERIAL EXPLANATION (1) Position plate ...1 (2) Screw...4 If the TV monitor is supplied with the root plate for the bag installation, when it changes to be installed by the unit BKT3, you must remove the six screws by using the screwdriver to uninstall the root plate on the back of the monitor and use four screws (2) to install the position plate (1) to the bottom of the monitor, as shown below.
- Page 15 www.pyleaudio.com 88-T1325-02...
