Summary of Contents for Smeg FC202PXN
- Page 1 No-Frost Combi Refrigerator Fridge - Freezer User manual No-Frost Kühl-/Gefrierkombination Betriebsanleitung Combine Froid Ventile Réfrigérateur - Congelateur Guide d’utilisation No-Frost Combi Frigorifero Frigo - Congelatore Istruzioni per l'uso FC202PXN...
-
Page 3: Table Of Contents
Index BEFORE USING THE APPLIANCE ......... 4 General warnings..............4 Old and out-of-order fridges............6 Safety warnings ................ 7 Installing and operating your fridge........... 8 Before Using your Fridge ............9 Information about New Generation Cooling Technology ..9 THE PARTS OF THE APPLIANCE AND THE COMPARTMENTS ............ -
Page 4: Before Using The Appliance
BEFORE USING THE APPLIANCE General warnings WARNING: Keep vantilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. WARNING: Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer. WARNING: Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type recommended by the manufacturer. - Page 5 BEFORE USING THE APPLIANCE - farm houses and by clients in hotels, motels and oth- er residential type environments. - bed and breakfast type environments; - catering and similar non-retail applications. • If the socket does not match the refrigerator plug, it must be replaced by the manufacturer, a service agent or similarly qualified persons in order to avoid a hazard.
-
Page 6: Old And Out-Of-Order Fridges
BEFORE USING THE APPLIANCE Old and out-of-order fridges • If your old fridge has a lock, break or remove the lock before discarding it, because children may get trapped inside it and may cause an accident. • Old fridges and freezers may contain isolation material and refrigerant with CFC or HFC. -
Page 7: Safety Warnings
BEFORE USING THE APPLIANCE Safety warnings • Do not connect your Fridge Freezer to the mains electricity supply using an extension lead. • Do not plug in damaged, torn or old plugs. • Do not pull, bend or damage the cord. •... -
Page 8: Installing And Operating Your Fridge
BEFORE USING THE APPLIANCE Installing and operating your fridge Before using your fridge, you should pay attention to the following points: • The operating voltage for your fridge is 220-240 V at 50Hz. • The mains cord of your fridge is fitted with a grounded plug. -
Page 9: Before Using Your Fridge
BEFORE USING THE APPLIANCE Before Using your Fridge • When using your fridge for the first time, or after transportation, keep it in an upright position for at least 3 hours before plugging into the mains. This allows efficient operation and prevents damage to the compressor. •... -
Page 10: The Parts Of The Appliance And The Compartments
THE PARTS OF THE APPLIANCE AND THE COMPARTMENTS This presentation is only for information about the parts of the appliance. Parts may vary according to the appliance model. - Page 11 THE PARTS OF THE APPLIANCE AND THE COMPARTMENTS A) Fridge compartment B) Freezer compartment 1) Fridge shelves 2) Wine rack * 3) Interior display / In room control 4) Chiller * 5) Crisper cover 6) Crisper 7) Freezer top basket 8) Freezer middle basket 9) Freezer bottom basket 10) Leveling feet...
-
Page 12: The Various Function And Possibilities
THE VARIOUS FUNCTION AND POSSIBILITIES Display and control panel Thermostat set level indicator 8 6 5 4 2 It is Economy mode It is Super cool mode indicator. indicator. Set button Button LED Operating your fridge Cooler temperature settings • Initial temperature value for Cooler Setting Indicator is 6 C. • Press set button once, the set value will start to blink. • If you keep pressing set button, lower temperatures will be selected. (8, 6, 5, 4, 2, super and eco) • If no button is pressed for 1 second, your choice will be set, it will blink 3 times. Buzzer will sound beep beep. • The temperature value selected before Super Cool Mode or Economy Mode is activated will remain the same when the mode is over or cancelled. The appliance continues to operate with this temperature value. -
Page 13: Super Cool Mode
THE VARIOUS FUNCTION AND POSSIBILITIES Super cool mode How would it be used? Press set button until super cool symbol will be seen on the screen. Buzzer will sound beep beep. Mode will be set. During this mode: • Economy mode can not be selected. • Super cool mode can be cancelled by the same operation of selecting. -
Page 14: Accessories
THE VARIOUS FUNCTION AND POSSIBILITIES • Your fridge is designed to operate in the ambient temperature intervals stated in the standards, according to the climate class stated in the information label. We do not recommend operating your fridge out of stated temperatures value limits in terms of cooling effectiveness. • This appliance is designed for use at an ambient temperature within the 10°C - 43°C range. Climate Class Ambient Temperature Between 16 and 43 (°C) Between 16 and 38 (°C) Between 16 and 32 (°C) Between 10 and 32 (°C) Accessories Freezer box The freezer box allows foods are maintained more regularly. Removing The freezer box; • Pull the box out as far as possible • Pull the front of box up and out. -
Page 15: Chiller Shelf
THE VARIOUS FUNCTION AND POSSIBILITIES Chiller Shelf (In some models) Keeping food in the Chiller compartment instead of the freezer or refrigerator compartment allows food retain freshness and flavour longer, while preserving its fresh appearance. When chiller tray becomes dirty, remove it and wash it with water. (Water freezes at 0°C, but foods containing salt or sugar freeze at temperature lower than that) Normally people use the chiller compartment for... -
Page 16: Adjustable Door Shelf
THE VARIOUS FUNCTION AND POSSIBILITIES Adjustable Door Shelf (In some models) Six different height adjustments can be made to provide storage areas that you need by adjustable door shelf. To change the position of adjustable door shelf ; Figure -1 Hold the bottom of the shelf and pull the buttons on the side of the door shelf direction of arrow (Fig.1). -
Page 17: Cleaning And Maintenance
CLEANING AND MAINTENANCE • Disconnect the unit from the power supply before cleaning. • Do not clean the appliance by pouring water. • Make sure that no water enters the lamp housing and other electrical components. • The refrigerator should be cleaned periodically using a solution of bicarbonate of soda and lukewarm water. -
Page 18: Defrosting
CLEANING AND MAINTENANCE Defrosting Your refrigerator has fully automatic defrosting. The water formed as a result of defrosting passes through the water collection spout, flows into the vaporisation container below the condenser and evaporates there. Evaporating • Make sure you have disconnected the plug of your tray refrigerator before cleaning the vaporization container. -
Page 19: Arranging Food In The Appliance
ARRANGING FOOD IN THE APPLIANCE Refrigerator compartment • For normal operating conditions, adjusting the temperature value of the cooler partition of the fridge to 4°C will be enough. • To reduce humidity and consequent increase of frost never place liquids in unsealed containers in the refrigerator. Frost tends to concentrate in the coldest parts of the evaporator and in time will require more frequent defrosting. -
Page 20: Freezer Compartment
ARRANGING FOOD IN THE APPLIANCE Freezer compartment • Please use the deep freeze compartment of your refrigerator for storing the frozen food for a long time and for producing ice. • To get maximum capacity for freezer compartment, please just use glass shelves for upper and middle section. For bottom section, please use lower basket. • For optimum appliance performance to reach maximum freezing capacity, Set the refrigerator at 4 C for 24 hours before placing fresh food into the freezer. - Page 21 ARRANGING FOOD IN THE APPLIANCE • During long lasting power failures, please do not open the door of the deep freeze compartment. Your refrigerator shall preserve your frozen food for about 18 hours in ambient temperatures of 25°C and for about 13 hours in ambient temperatures of 32°C. This value will decrease under higher ambient temperatures. During longer power failures, do not refreeze your food and consume them as soon as possible.
- Page 22 ARRANGING FOOD IN THE APPLIANCE Maximum Storing time Meat and fish Preparation (month) Steak Wrapping in a foil 6 - 8 Lamb meat Wrapping in a foil 6 - 8 Veal roast Wrapping in a foil 6 - 8 Veal cubes In small pieces 6 - 8 Lamb cubes In pieces...
- Page 23 ARRANGING FOOD IN THE APPLIANCE Maximum Vegetables and Storing Preparation Fruits time (months) String beans and Wash and cut into small pieces and 10 - 13 beans boil in water Beans Hull and wash and boil in water Cabbage Cleaned and boil in water 6 - 8 Clean and cut to slices and boil in Carrot...
- Page 24 ARRANGING FOOD IN THE APPLIANCE Maximum Dairy Preparation Storing time Storing Conditions Products (months) Packet In its own Pure Milk – In its (Homogenize) 2 - 3 packet own packet Milk Original package may be used for Cheese- short storing period. excluding In slices 6 - 8...
-
Page 25: Transportation And Changing Of Installation Position
TRANSPORTATION AND CHANGING OF INSTALLATION POSITION Transportation and Changing of Installation Position • The original packages and foamed polystyrene (PS) can be retained if required. • During transportation, the appliance should be secured with a wide string or a strong rope. The instructions written on the corrugated box must be followed while transporting. -
Page 26: Before Calling Your After Sales Service
BEFORE CALLING YOUR AFTER SALES SERVICE Check Warnings; Your fridge warns you if there is/are some part(s) out of order. In this case, LED around the button will blink and buzzer will sound beep. ERROR TYPE MEANING WHAT TO DO Call Service for "Failure There is/are some... - Page 27 BEFORE CALLING YOUR AFTER SALES SERVICE to its function. When the required cooling level is reached, noises will be decreased automatically. If the noises persist; • Is your appliance stable? Are the legs adjusted? • Is there anything behind your fridge-freezer? •...
- Page 28 BEFORE CALLING YOUR AFTER SALES SERVICE If the edges of fridge cabinet that the door joint contact are warm; Especially in summer (hot weather), the surfaces that the joint contact may get warmer during the operation of the compressor, this is normal. IMPORTANT NOTES: •...
-
Page 29: Tips For Saving Energy
TIPS FOR SAVING ENERGY 1. Install the appliance in a cool, well ventilated room , but not in direct sunlight and not near a heat source (radiator, cooker.. etc). Otherwise use an insulating plate. 2. Allow warm food and drinks to cool down outside the appliance. 3.
