Wallace Perimeter Security ALPHA Installation And Maintenance Manual

Kinetic operator
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Revision 1 - MAY 2023
115 Lowson Crescent
Winnipeg, Manitoba, Canada R3P 1A6
Phone: 866.300.1110
wallaceperimetersecurity.com
ALPHA
ALPHA/DELTA
KINETIC
OPERATOR
INSTALLATION AND
MAINTENANCE MANUAL
1, 1S, 2, 2S Gate Operators
DELTA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ALPHA and is the answer not in the manual?

Questions and answers

Related Manuals for Wallace Perimeter Security ALPHA

Summary of Contents for Wallace Perimeter Security ALPHA

  • Page 1 Revision 1 - MAY 2023 ALPHA DELTA ALPHA/DELTA KINETIC OPERATOR INSTALLATION AND MAINTENANCE MANUAL 1, 1S, 2, 2S Gate Operators 115 Lowson Crescent Winnipeg, Manitoba, Canada R3P 1A6 Phone: 866.300.1110 wallaceperimetersecurity.com...
  • Page 2 Copyright Notice ©Copyright 2023 all rights reserved. No part of this manual may be reproduced by any means (photocopier, electronic, or mechanical), without the express written permission of Wallace Perimeter Security and Nice | HySecurity Gate Inc. wallaceperimetersecurity.com Phone: 866.300.1110...

  • Page 3: Table Of Contents

    PRODUCT & WARRANTY REGISTRATION ��������������������������������������������������������8 Introducing Kinetic DC ������������������������������������������������������������ 9 Intelligent Features: SmartDC Controller™ �����������������������������������������������������9 Technical Support ���������������������������������������������������������������������������������������� 10 Alpha/Delta (Kinetic Operator) Gate System ������������������������������������������������ 10 Alpha/Delta Installation & Maintenance Checklist ���������������� 12 SAFETY INFORMATION ��������������������������������������������������������� 19 Safety Notices ���������������������������������������������������������������������������������������������� 19 Common Industrial Symbols ������������������������������������������������������������������������...
  • Page 4 TABLE OF CONTENTS Adjusting the Drive Height ��������������������������������������������������������������������������� 59 Adjusting the Spur Gear Alignment �������������������������������������������������������������� 59 Installing the Tooth Rack ������������������������������������������������������������������������������ 60 Connecting the Battery and Turning DC Power ON ���������������������������������������61 Programming the Initial Setup Menu ����������������������������������������������������������� 61 Establishing the OPEN and CLOSE Limits ������������������������������������������������������ 63 Target Sensor Rack Drive Installation Instructions ���������������������������������������64 Installing the Target Magnet ������������������������������������������������������������������������...
  • Page 5 Installing Photoelectric Sensors for External Entrapment Protection Only �� 145 Operation Notes ���������������������������������������������������������������������������������������� 145 Photo Eye Mounting and Alignment ���������������������������������������������������������� 147 Installing Gate Edge Sensors ���������������������������������������������������������������������� 148 Accessory Connections ������������������������������������������������������������������������������ 149 SmartDC Controller Troubleshooting ��������������������������������������������������������� 151 Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...
  • Page 6 TABLE OF CONTENTS TROUBLESHOOTING����������������������������������������������������������������������������������� 152 Vehicle Detector and Loop Fault Diagnostics ���������������������������������������������� 163 Kinetic Schematics ���������������������������������������������������������������� 166 General Maintenance ��������������������������������������������������������� 171 Smart Touch Analyze and Retrieve Tool (S.T.A.R.T.) ������������������������������������� 171 Electrical Controls �������������������������������������������������������������������������������������� 173 Mechanical Maintenance ��������������������������������������������������������������������������� 173 Software Maintenance ������������������������������������������������������������������������������ 174 Drive Belt Tension and Alignment ��������������������������������������������������������������...

  • Page 7: Kinetic Components

    KINETIC COMPONENTS Kinetic Components Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...

  • Page 8: Product & Warranty Registration

    _______________________________________ For technical support call: 866-300-1110 _______________________________________ _______________________________________ Wallace Perimeter Security does not share warranty registration information with parties unless the requested services, transactions, or legal requirements necessitate it. Mark an “X”. Did you visit the Nice | HySecurity website before purchasing your product? How did you hear about HySecurity gate operators? (Check all that apply.)

  • Page 9: Introducing Kinetic Dc

    INTRODUCING KINETIC DC Introducing Kinetic DC Thank you for purchasing our premium Kinetic DC™ slide gate operator. At Wallace Perimeter Security, we pride ourselves on quality. Our new line electromechanical gate operators include a number of unparalleled user benefits: Robust - The components on the SmartDC Controller™ are protected by opto-isolators which shield them from power surges and lightning strikes.

  • Page 10: Technical Support

    866-300-1110. Alpha/Delta (Kinetic Operator) Gate System The Kinetic automatic gate operator is designed to open and close two types of Wallace Perimeter Security modular aluminum gate models: • ALPHA Cantilever Sliding Gate •...
  • Page 11 Airports, Seaports, Commercial Facilities, Water Treatment Facilities, Public Transportation Alpha/Delta models are cantilever gate systems (trackless sliding gates) that use a tooth rack and spur gear mechanism to move the gates. The absence of a ground track allows the gate to accommodate heavy traffic in continuous duty applications.

  • Page 12: Alpha/Delta Installation & Maintenance Checklist

    ALPHA/DELTA INSTALLATION & MAINTENANCE CHECKLIST Alpha/Delta Installation & Maintenance Checklist Review the following list and check off the items as you complete the installation. Make sure gate installation complies with ASTM F2200 Standard Specification for Automated Vehicular Gate Construction. And, install the supplied WARNING sign on both sides of the gate. Check for compliance with local codes, site conditions, and NEC standards.
  • Page 13 4� Bottom Rollers Check bottom beam guide rollers for wear. Rollers should be replaced every 2 to 3 years depending on usage. Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...
  • Page 14 ALPHA/DELTA INSTALLATION & MAINTENANCE CHECKLIST ALPHA/DELTA INSTALLATION AND MAINTENANCE Checked Good Needs CHECKLIST Attention 5� Top Rollers Check top guide rollers for wear. Top rollers should be replaced every 3 to 5 years depending on usage. 6� Leading/Trailing Edge Post Pull on or twist the leading and trailing edge posts by hand to make sure that they do not move –...
  • Page 15 Remove covers from photocells, clean inside of covers and ensure gasket is in place to protect the photocell body from water and dust entering. 15� Sensing Edges If installed, test for proper operation. Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...
  • Page 16 ALPHA/DELTA INSTALLATION & MAINTENANCE CHECKLIST ALPHA/DELTA INSTALLATION AND MAINTENANCE Checked Good Needs CHECKLIST Attention 16� Loop Detector - Test Verify that the ground loops have been occupied and the gate responds correctly. Test the loop occupation with the type of vehicles that will be using the gate.
  • Page 17 28� Wiring All field wiring should run in the provided wiring ducts. Power supply wiring should be secured safely in appropriate clips. Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...
  • Page 18 ALPHA/DELTA INSTALLATION & MAINTENANCE CHECKLIST ALPHA/DELTA INSTALLATION AND MAINTENANCE Checked Good Needs CHECKLIST Attention 29� Conduits All conduits must be finished to the applicable electrical code(s) into the bottom of the operator cabinet only. This will help to prevent water entry into the operator cabinet and will allow for proper installation of thermal cover (if required).

  • Page 19: Safety Information

    DANGER - Keep Away occur if the hazardous situation is not avoided. Indicates damage to equipment is Entrapment Zone probable if the hazardous situation is not avoided. Possible Pinch Point Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...

  • Page 20: Safety Requirements

    Kinetic gate operator. A qualified installer has one of the following: • A minimum of three years’ experience installing similar equipment. • Proof of attending a Wallace Perimeter Security Technical Training seminar within the past three years. • Significant manufacturer endorsements of technical aptitude in gate operator installation and operation.

  • Page 21: Safety Standards - Installer's Responsibility

    - Mounted beyond 6 feet (183cm) of the gate, to prevent users from touching or accessing the gate while operating the controls. People attempting to access the controls by reaching through or around the gate can be seriously injured or killed by the moving gate. Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...
  • Page 22 SAFETY STANDARDS - INSTALLER'S RESPONSIBILITY - Incorporate a security feature to prevent unauthorized use. • The gate operator must be properly grounded and the incoming power voltage must match the voltage label on the junction box. • Install enough external entrapment protection sensors so that pedestrians are protected from entrapment in both directions of the gate travel and all hazard areas and possible pinch points are fully protected.

  • Page 23: Safety Standards - Owner/User Responsibility

    Learn how to turn the power on and off. person make repairs to gate hardware to keep Learn how to manually release the gate. the gate running smoothly. Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...

  • Page 24: Hazardous Materials And Proper Disposal

    Observe the polarity between the batteries and charging circuit. • Never mix battery sizes, types, or brands. The charging circuit on Wallace Perimeter Security DC operators is designed for AGM-type batteries, not lead acid-type batteries. Wallace Perimeter Security strongly recommends that only sealed AGM style batteries be used.

  • Page 25: External Entrapment Protection Sensors

    All sensors must be installed so that they function as intended for the end-use conditions. Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...
  • Page 26 EXTERNAL ENTRAPMENT PROTECTION SENSORS UL 325 LISTING: The edge sensors and photo electric eyes must be tested and labeled as “Recognized Components” under UL 325 in order to be deemed acceptable for use in a gate operator. Study the “Important Safety Instructions” on page 20 and consider your specific installation to determine where the greatest entrapment risks exist.

  • Page 27: Identifying Gate Operator Category And Usage Class

    Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...

  • Page 28: Choosing External Entrapment Protection

    Refer to the following Section for the applications, but it is not recommended operator manufacturer’s list of (non- by Wallace Perimeter Security because contact and contact) tested sensors a buzzer warns, but cannot protect compliant with the UL 325 Standard of against possible entrapment.

  • Page 29: Ul 325 Compliant Sensors

    Edge Sensors Sentir Series ASO Safety 100543 CPT210-2U-#-T2 Miller Edge Edge Sensor Hy2NC (Converts 10K to HySecurity Converters NC Monitoring) Multi-Input Module The Solution – MIM-62 Miller Edge Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...
  • Page 30 UL 325 COMPLIANT SENSORS Recommended External Entrapment Protection Sensors List for the SmartDC Controller – Kinetic Operator Excerpts from UL 325 Standard: The operator shall monitor for the presence of every device at least once during each open and close cycle.

  • Page 31: Stop Button

    “push” the gate, it will push back 2� Flip the DC power switch ON. because the position sensor is active 3� Clear any faults by pressing RESET. and the motor is engaged. Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...

  • Page 32: Alpha/Delta Gate Unloading

    ALPHA/DELTA GATE UNLOADING Alpha/Delta Gate Unloading 1. Check packing slip to ensure all pieces are 4. The pallets are built with openings at the accounted for. bottom to be securely lifted by a forklift. 2. Lift the aluminum beams by hand. Use a cart if available.

  • Page 33: Alpha/Delta Gate Installation

    Both gate models feature a rack and pinion drive, concealed nylon rollers and anti-climb top rail. Kinetic Gate installation should only be carried out by personnel qualified by Wallace Perimeter Security. Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...
  • Page 34 ALPHA/DELTA GATE INSTALLATION Be sure to attach the WARNING signs on both sides of the gate but NOT ON the gate. For your records, take a photograph of the completed installation site. Figure 1. Site Overview wallaceperimetersecurity.com Phone: 866.300.1110...

  • Page 35: Alpha Gate Model Step-By-Step Installation Diagrams

    ALPHA GATE MODEL STEP-BY-STEP INSTALLATION DIAGRAMS ALPHA Gate Model Step-by-Step Installation Diagrams ALPHA Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...
  • Page 36 ALPHA GATE MODEL STEP-BY-STEP INSTALLATION DIAGRAMS ALPHA wallaceperimetersecurity.com Phone: 866.300.1110...
  • Page 37 ALPHA GATE MODEL STEP-BY-STEP INSTALLATION DIAGRAMS ALPHA Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...
  • Page 38 ALPHA GATE MODEL STEP-BY-STEP INSTALLATION DIAGRAMS ALPHA wallaceperimetersecurity.com Phone: 866.300.1110...
  • Page 39 ALPHA GATE MODEL STEP-BY-STEP INSTALLATION DIAGRAMS ALPHA Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...
  • Page 40 ALPHA GATE MODEL STEP-BY-STEP INSTALLATION DIAGRAMS ALPHA wallaceperimetersecurity.com Phone: 866.300.1110...
  • Page 41 ALPHA GATE MODEL STEP-BY-STEP INSTALLATION DIAGRAMS ALPHA Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...
  • Page 42 ALPHA GATE MODEL STEP-BY-STEP INSTALLATION DIAGRAMS ALPHA wallaceperimetersecurity.com Phone: 866.300.1110...
  • Page 43 ALPHA GATE MODEL STEP-BY-STEP INSTALLATION DIAGRAMS ALPHA Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...
  • Page 44 ALPHA GATE MODEL STEP-BY-STEP INSTALLATION DIAGRAMS ALPHA wallaceperimetersecurity.com Phone: 866.300.1110...
  • Page 45 ALPHA GATE MODEL STEP-BY-STEP INSTALLATION DIAGRAMS ALPHA Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...

  • Page 46: Delta Gate Model Step-By-Step Installation Diagrams

    DELTA GATE MODEL STEP-BY-STEP INSTALLATION DIAGRAMS DELTA Gate Model Step-by-Step Installation Diagrams wallaceperimetersecurity.com Phone: 866.300.1110...
  • Page 47 DELTA GATE MODEL STEP-BY-STEP INSTALLATION DIAGRAMS Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...
  • Page 48 DELTA GATE MODEL STEP-BY-STEP INSTALLATION DIAGRAMS wallaceperimetersecurity.com Phone: 866.300.1110...
  • Page 49 DELTA GATE MODEL STEP-BY-STEP INSTALLATION DIAGRAMS Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...
  • Page 50 DELTA GATE MODEL STEP-BY-STEP INSTALLATION DIAGRAMS wallaceperimetersecurity.com Phone: 866.300.1110...
  • Page 51 DELTA GATE MODEL STEP-BY-STEP INSTALLATION DIAGRAMS Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...
  • Page 52 DELTA GATE MODEL STEP-BY-STEP INSTALLATION DIAGRAMS wallaceperimetersecurity.com Phone: 866.300.1110...
  • Page 53 DELTA GATE MODEL STEP-BY-STEP INSTALLATION DIAGRAMS Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...
  • Page 54 DELTA GATE MODEL STEP-BY-STEP INSTALLATION DIAGRAMS wallaceperimetersecurity.com Phone: 866.300.1110...
  • Page 55 DELTA GATE MODEL STEP-BY-STEP INSTALLATION DIAGRAMS Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...
  • Page 56 DELTA GATE MODEL STEP-BY-STEP INSTALLATION DIAGRAMS wallaceperimetersecurity.com Phone: 866.300.1110...

  • Page 57: Operator Installation And Gate Adjustments

    230 volts, 1.5 amps, 50/60 Hertz Motor: ½ hp Motor: ½ hp Gate Speed: 1ft/s Gate Speed: 2ft/s Gate weight: Maximum 1500lbs (675kg) Gate weight: Maximum 1000lbs (450kg) Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...

  • Page 58: Installing The Kinetic Operator On Gate Posts

    INSTALLING THE KINETIC OPERATOR ON GATE POSTS Installing the Kinetic Operator on Gate Posts RH & LH mounting options can be configured by the following steps: 1. Remove the 4 - 10 x1.5 x 20mm button head screws on the side of the operator that will be mounted to the gate post.

  • Page 59: Adjusting The Drive Height

    3. Adjust spur gear so it is centered on the tooth rack. Re-tighten the two (2) - ¼ -20 x 2.0” retaining bolts and lock nuts on spur gear. Figure 5, 6 & 7. Adjusting Spur Gear Alignment Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...

  • Page 60: Installing The Tooth Rack

    INSTALLING THE TOOTH RACK Installing the Tooth Rack Hook tooth racks together and slide them into rail throughout the entire length of gate. See Figure 8. Tooth racks can be .80” (2cm) to 1.18” (3cm) shorter than gate length; tooth rack must not protrude past the end of the gate beam.

  • Page 61: Connecting The Battery And Turning Dc Power

    NOTE: Programming the Setup Menu is usually a one-time occurrence unless factory defaults are reinstated through the Installer Menu. The RESET and MENU buttons do not function during the initial configuration of the Setup Menu. Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...
  • Page 62 OPERATOR INSTALLATION AND GATE ADJUSTMENTS USAGE CLASS SELECTIONS: 0 -No Usage Class set. 1 -Single family residential up to four units. 2 -Multi-family, hotel etc. 3 -Industrial use, not for general public. 4 -Guarded and monitored facility, not for general public. GATE HANDING SELECTIONS: 0 -No handing set.

  • Page 63: Establishing The Open And Close Limits

    Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...

  • Page 64: Target Sensor Rack Drive Installation Instructions

    The following instructions are intended to assist the user in the new Wallace Kinetic gate operators target sensor rack drive kit installation, available from Wallace Perimeter Security. To order, ask for Kit Part No. 951WG-WH). The new rack drive kit provides a fender washer and zinc collar to secure the target sensor past the operator’s outer cover and close distance between sensor and chain magnet, minimizing any...
  • Page 65 TARGET SENSOR RACK DRIVE INSTALLATION INSTRUCTIONS Target Magnet Sensor Installation Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...

  • Page 66: Installing The Target Magnet

    INSTALLING THE TARGET MAGNET Installing the Target Magnet Figure 13. Marking Gate Beam 3. Find the mark on the gate beam and measure about 3” (76mm) toward the operator. 4. Drill a 3/8” (9.5mm) diameter hole in gate beam and tooth rack 7/8” (22mm) deep as shown in Figure 14.
  • Page 67 Note: Repeat steps 6 – 8 if you are still having switches and watch the display go blank. difficulty with the operator learning its limits. Then, turn both switches on. The operator Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...

  • Page 68: Power

    Wallace Perimeter Security recommends grounding the operator with a separate earth ground rod to shield the operator against electromagnetism and other electrical signals that may cause erratic operation with or damage to the SmartDC Controller.
  • Page 69 Properly grounding the gate operator is critical to gate operator performance and the life of its electrical components. Use sufficient wire size during installation. Refer to “Wiring 115VAC Power” on page 71 or “Wiring 230VAC Power” on page 72. Figure 15. Installing Grounding Rod Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...

  • Page 70: Wiring Ac Power

    WIRING AC POWER Wiring AC Power Wiring of gate operators must conform Turn off AC power at the source (circuit to the NEC standards and comply with breaker panel) before accessing the all local codes. If you plan to connect wires in the Kinetic junction box.

  • Page 71: Wiring 115Vac Power

    6� Neatly organize all wire connections and replace the high voltage junction box cover. Secure it with the two Phillips-head screws. Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...

  • Page 72: Wiring 230Vac Power

    WIRING 230VAC POWER Wiring 230VAC Power All Kinetic operators are shipped from the factory as 115VAC units. When connecting to 230VAC power, the voltage selector switch on the AC power board must be moved to the 230V position or damage to the operator will occur and void the Limited Warranty.
  • Page 73 7� Neatly organize all wire connections and secure the junction box cover with the two Phillips-head screws. 8� Place the 230V 1Ø label on the Junction Box Cover over the 115V 1Ø label. Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...

  • Page 74: Using A Solar Powered Operator

    USING A SOLAR POWERED OPERATOR Using a Solar Powered Operator Wallace Perimeter Security offers a solar version of the Kinetic operator in 1ft/s or 2ft/s models. The solar models have different internal wiring Solar panels are NOT included in and include software programmed for solar use.
  • Page 75 USING A SOLAR POWERED OPERATOR Figure 18. Solar Panels and Wiring Connections Figure 19. Kinetic DCS Control Box Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...

  • Page 76: Connecting Peripherals To A Solar Operator

    CONNECTING PERIPHERALS TO A SOLAR OPERATOR Connecting Peripherals to a Solar Operator Photoeyes connected these Photoeyes connected these terminals receive power when the terminals receive power when the motor engages which means the draw motor engages which means the draw on the battery is minimal.

  • Page 77: Understanding Gate Activity Based On Solar Zones

    Wallace Perimeter Security offers a 50Ah battery option which provides six times the storage capacity of the standard 8Ah batteries. Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...
  • Page 78 UNDERSTANDING GATE ACTIVITY BASED ON SOLAR ZONES Figure 21. Solar Insolation Map The chart is based on a 20 Watt (24VDC) solar panel system with Kinetic DC powering a 30 foot (9m), 1000 lbs, 1ft/s [Kinetic 1S] gate with the following peripherals attached: •...

  • Page 79: Important Considerations For Dc-Power Connection

    • Wallace Perimeter Security uses a permanently sealed AGM-type battery which lasts much longer than wet cell batteries and needs no maintenance over its life span. Batteries are protected from over discharge by a low voltage sensing circuit. The charger circuit regulates to allow high charger output when the battery is partially discharged.

  • Page 80: Installing The Extended Battery Backup Kit

    INSTALLING THE EXTENDED BATTERY BACKUP KIT Installing the Extended Battery Backup Kit Wallace Perimeter Security offers an extended DC power back up option with two 50Ah batteries. 7. Using the wires supplied in the 50Ah battery Contact Wallace Perimeter Security...
  • Page 81 OPEN and RESET. Release the buttons. 4. Use the NEXT button to navigate to the menu display. Change the setting using the SELECT and NEXT buttons. Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...

  • Page 82: Display And Menu Options

    DISPLAY AND MENU OPTIONS Display and Menu Options This section of the manual provides information about the display and menu options. It includes how to: • Turn both AC and DC power switches on. • Adjust the Display Contrast • Review How to use the SmartDC Controller •...

  • Page 83: Turning Both Power Switches On

    On a solar-powered operator, the lower power switch connects and disconnects the DC power from the solar panels. Figure 22. AC and DC Power Switches Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...
  • Page 84 TURNING BOTH POWER SWITCHES ON The flashing red indicator light next to the OPEN button on the SmartDC Controller is considered the ‘heart’ beat of the system. It indicates that the electronics board is receiving power. When AC power is lost, the rate of flashing slows down.

  • Page 85: Using The Smartdc Controller Buttons In Menu Mode

    STOP button while more serious faults require the RESET button or cycling power. Faults indicate a need for diagnosis and resolution. Refer to “SmartDC Controller Troubleshooting” on page 151� Figure 24. Function of the SmartDC Controller Buttons in Menu Mode Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...

  • Page 86: Run Mode

    RUN MODE RUN MODE Gate status displays appear when the operator is ready and waiting for a gate operation command. When the menu display is flashing “GATE OPENING” or “GATE CLOSING” a command has been received which starts the motor and drives the gate. The command may come from a variety of sources: a card reader, push-button remote, or recognition of a vehicle passing over a free exit loop detector.

  • Page 87: Using The Smartdc Controller Buttons In Run Mode

    STOP button while more serious faults require the RESET button or cycling power. Faults indicate a need for diagnosis and resolution. Refer to “SmartDC Controller Troubleshooting” on page 151� Figure 26. Function of SmartDC Controller Buttons in RUN Mode Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...

  • Page 88: Viewing Operator Status Displays

    VIEWING OPERATOR STATUS DISPLAYS Viewing Operator Status Displays Press the MENU button once and the operator status displays appear in two second intervals. Pertinent information appears to provide a quick overview of the operator’s status or configurations. Refer to Figure 27 below. Variables Description The software version and revision...

  • Page 89: User Menu

    Setting the AC Power Loss Gate Function • Adjusting the Display Contrast For information on how the menu buttons function, review “Using the SmartDC Controller Buttons in Menu Mode” on page 85. Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...

  • Page 90: Adjusting The Close Timer

    ADJUSTING THE CLOSE TIMER Adjusting the Close Timer The close timer assigns how many seconds will pass before the operator initiates closure of a fully opened gate after all open commands and reversing sensor inputs have ceased. Every gate operator needs to have the close timer set to a specific number of seconds unless a hard-wired closing device is connected to the unit such as a push-button station.

  • Page 91: Setting The Time And Date

    DL 2025, DL 2032 or CR 2025 A gate status appears in the display indicating or CR 2032 battery. Refer to “Clock you have returned to Run Mode. Battery Replacement” on page 178. Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...

  • Page 92: Setting Ac Power Loss Gate Function

    SETTING AC POWER LOSS GATE FUNCTION Setting AC Power Loss Gate Function The setting in the AC LOSS display determines what action the operator performs during an AC power loss. The settings help reduce drain on the battery. You can choose between four settings depending on customer preferences.

  • Page 93: Adjusting The Display Contrast

    Run Mode. 4. To exit the User Menu, press the MENU button. A gate status appears in the display indicating you have returned to Run Mode. Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...

  • Page 94: User Menu Functions

    USER MENU FUNCTIONS USER MENU FUNCTIONS Table 5. SmartDC Controller - User Menu Functions User Menu Setting Options Associated Ref. (Bold = Factory Menu Tasks and Explanations DC Controller Display No� Connections Settings) 0 = Timer disabled Assign how many seconds before the open Not applicable 1 second to 99 seconds gate initiates closure.
  • Page 95 LCD display. The display is adjustable from 0-9 with a factory LD 5 default setting of 5. LCD CONTRAST Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...
  • Page 96 USER MENU FUNCTIONS Table 5. SmartDC Controller - User Menu Functions User Menu Setting Options Associated Ref. (Bold = Factory Menu Tasks and Explanations DC Controller Display No� Settings) Connections 0 = off (standard) Set this item to 1 to record all gate operator USB or 1 = on (detailed) open and close events, in addition to the...
  • Page 97 WARNING: Do NOT cut the wires to the buzzer or unplug it as the operator will not be in compliance with UL 325. Failure to comply may result in serious injury or death. Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...

  • Page 98: Installer Menu

    INSTALLER MENU Installer Menu The Installer Menu consists of several functions which can be modified using the SmartDC Controller buttons or configured through the use of a laptop computer and the S.T.A.R.T. software available from the Nice | HySecurity website. The Installer Menu options provide more advanced configurations for the Kinetic operator.

  • Page 99: Resetting The Open And Close Limits

    8. An ALERT 15 message appears on the display. through 8. To clear the alert, perform a full cycle so the software recognizes the target. Press OPEN, and then CLOSE. The gate will stop Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...

  • Page 100: Adjusting The Gate Speed

    ADJUSTING THE GATE SPEED Adjusting the Gate Speed To adjust gate speed, take the following steps: 1. Start at a gate status display. 1. At a gate status display, press the MENU button twice. This accesses the User Menu and the CLOSE TIMER display appears. 2.

  • Page 101: Adjusting The Ies Sensitivity

    NOTE: When wind load increases, IES software adapts and changes the threshold allowance. The IES threshold automatically increases by 50% when the temperature drops below 32°F (0°C) Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...
  • Page 102 ADJUSTING THE IES SENSITIVITY When changing the IES setting, consider the site design and vehicular gate traffic. It is recommended that you use the most sensitive setting while still allowing for reliable gate operation. Examples of conditions which affect IES sensitivity include: Gate design - For long and/or solid gates in windy environments, large variations in motor current may occur.
  • Page 103 3. To access the Installer Menu, simultaneously press OPEN and RESET. 4. Use NEXT to navigate to the menu display. Change the setting using the SELECT and NEXT buttons. Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...

  • Page 104: Reinstating Factory Defaults

    REINSTATING FACTORY DEFAULTS Reinstating Factory Defaults Thirteen menu configurations are available in the User Menu. Several other items in the Installer Menu let you customize the operator depending on the number of attached accessories and your customer’s needs. When you press SELECT to accept FD Reinstating factory default clears ALL 1, the factory settings are reinstated menu settings stored in the operator...

  • Page 105: Enabling The Fire Department Override

    3. To access the Installer Menu, simultaneously press OPEN and RESET. 4. Use NEXT to navigate to the menu display. Change the setting using the SELECT and NEXT buttons. Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...

  • Page 106: Installer Menu Functions

    INSTALLER MENU FUNCTIONS INSTALLER MENU FUNCTIONS Table 6. SmartDC Controller - Installer Menu Functions Installer Menu Setting Options Associated Ref. (Bold = Factory Settings) Menu Tasks and Explanations DC Controller Display No� Connections 0 = operator type Select the appropriate number for the Not applicable operator.
  • Page 107 FD 0 (OFF) Note: If factory defaults are restored, the FACTORY DEFAULTS UL usage class, handing, gate weight and any other modified menu settings will need to be configured again. Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...
  • Page 108 INSTALLER MENU FUNCTIONS Table 6. SmartDC Controller - Installer Menu Functions Installer Menu Setting Options Associated Ref. (Bold = Factory Settings) Menu Tasks and Explanations DC Controller Display No� Connections 0 = solo operator Configures gate operator as a Primary Shielded 1 = Secondary unit or as a Secondary (or a Sally Port...
  • Page 109 LEAF DELAY OPEN 1 = ½ second activates. Provides up to a 10 second time 10 = 5 seconds delay. 20 = 10 seconds Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...
  • Page 110 INSTALLER MENU FUNCTIONS Table 6. SmartDC Controller - Installer Menu Functions Installer Menu Setting Options Associated Ref. (Bold = Factory Settings) Menu Tasks and Explanations DC Controller Display No� Connections used Kinetic (N/A) operators. RT 0 (80 SECS) MAXIMUM RUN TIMER 0 = OFF Sets the distance (from the closed gate OPEN PARTIAL...
  • Page 111 0 causes the gate to only pause COM or HY5A/ when triggered. Gate closure begins as HY5B/HY5B OR 1 REVERSE soon as the loop is clear again. OUTSIDE OBS LOOP Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...
  • Page 112 INSTALLER MENU FUNCTIONS Table 6. SmartDC Controller - Installer Menu Functions Installer Menu Setting Options Associated Ref. (Bold = Factory Settings) Menu Tasks and Explanations DC Controller Display No� Connections 0 = Pause closing only The default is for full reversal when the INSIDE OBS 1 = Enable reversing to Inside Obstruction Loop is triggered.
  • Page 113 4 = Show Sensitivity ELD 0 (RUN MODE) 5 = Set Sensitivity EXIT LOOP SET 6 = Show Inductance 7 = Show Loop Health 8 = Set Presence Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...
  • Page 114 INSTALLER MENU FUNCTIONS Table 6. SmartDC Controller - Installer Menu Functions Installer Menu Setting Options Associated Ref. (Bold = Factory Settings) Menu Tasks and Explanations DC Controller Display No� Connections 0 = Run mode Controls the HY5A/HY5B/HY5B 2.0 Inside HY5A/HY5B/ 1 = Show frequency Obstruction Loop detector.

  • Page 115: Smartdc Controller

    2� Perform a Preliminary Test of the Components 3� Connect Vehicle Detectors 4� Connect Accessory Devices • Entrapment Sensor Connections • Access Controls • Manual Push-Button Station • User Relays Figure 28. SmartDC Controller Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...

  • Page 116: Overview Of The Smartdc Controller

    OVERVIEW OF THE SMARTDC CONTROLLER Overview of the SmartDC Controller The SmartDC Controller uses LED’s to indicate active inputs when AC power is present. For operators that use only DC power, you can push a button to show the active inputs. This button is at the bottom left corner near the EMERG OPEN input.

  • Page 117: Preliminary Testing

    Installer Menu (7- 32ft). Sensor 2 N.C. input. Connection of a Monitored External entrapment sensors. External Entrapment sensor. Type of sensor used is programmable in Installer Menu (S2). Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...
  • Page 118 PRELIMINARY TESTING Table 7. SmartDC Controller Board Inputs Terminal Label/Input Wire Connection Uses No� Name Sensor 3 N.C. input. Connection of a Monitored External entrapment sensors. External Entrapment sensor. Type of sensor used is programmable in Installer Menu (S3). Free Exit Vehicle N.O.
  • Page 119 ***The Fire Department Open control must be keyed or guarded so that it can only be used by authorized personnel. Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...

  • Page 120: Vehicle Detector Installation Options

    VEHICLE DETECTOR INSTALLATION OPTIONS Vehicle Detector Installation Options The SmartDC Controller provides a feature-rich interface to four different vehicle detector inputs. Standard box type 11 pin (24 Volt DC or 24 Volt AC) vehicle detectors may be connected in the traditional manner as described in Installing Standard 11-Pin Box Type Vehicle Detectors.

  • Page 121: Connecting Hy5B Vehicle Detectors

    7� If the detector module is unplugged after it is enabled, a communications alert (ALERT 10) will be triggered; if the fault continues an error message, ERROR 3 “Detector Failed” is displayed. Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...
  • Page 122 CONNECTING HY5B VEHICLE DETECTORS If there is any detector fault, the gate operator functions as if the detector is triggered. 8� Pressing the RESET button: • Clears any errors • Tunes the detector on connected loops • Un-installs any detectors that have been removed 9�...
  • Page 123 When the OOLD and IOLD loops are cleared, the gate closes immediately.) For additional information, refer to “Vehicle Detector Configuration and Quick Close Mode Selection” on page 126. Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...

  • Page 124: Connecting Standard 11-Pin Box Type Vehicle Detectors

    CONNECTING STANDARD 11-PIN BOX TYPE VEHICLE DETECTORS Connecting Standard 11-Pin Box Type Vehicle Detectors If photo eyes are used to monitor vehicle traffic instead of loop detectors, connect the photo eyes using the same steps. See “Installing Photoelectric Sensors for External Entrapment Protection Only”...
  • Page 125 Refer to “Installing Vehicle Detectors and Loops” on page 142. Figure 31. Standard 11-Pin Box Type Vehicle Detector Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...

  • Page 126: Vehicle Detector Configuration And Quick Close Mode Selection

    VEHICLE DETECTOR CONFIGURATION AND QUICK CLOSE MODE SELECTION Vehicle Detector Configuration and Quick Close Mode Selection The Standard Quick Close modes are selectable in the Installer Menu. Refer to “Table 6. SmartDC Controller - Installer Menu Functions” on page 106. The four selectable modes are described as follows: Mode 1 (Default) An input from either the Free Exit, Outside Obstruction Loop, Inside Obstruction Loop or the Center Loop will hold the gate open, reset the close timer, and block all close inputs.

  • Page 127: Entrapment Sensor Connections

    These external entrapment protection devices are required so the gate installation is in compliance with UL 325 Safety Standards. Figure 32 illustrates how to connect different sensors to the SmartDC Controller: Figure 32. Entrapment Sensor Connections Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...

  • Page 128: Manual Push-Button Station

    MANUAL PUSH-BUTTON STATION Manual Push-Button Station A manual push-button station controls the gate system and opens, stops, and closes the gate. It is most often used by a guard in a 24-hour guard station. An example of the push-button station connections on the Kinetic DC operators shown in Figure 33.

  • Page 129: User Relays - Programming Procedure

    Triggers a sequenced barrier arm gate operator to open. Generates a brief pulsed-output when the open-limit is triggered. An additional pulse is also generated with any new open command even when the gate is already fully-opened. Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...
  • Page 130 USER RELAYS - PROGRAMMING PROCEDURE Table 9. User-Programmable User Relays - Function Options No� Name Description Warn before/during Controls an external warning device. This output operates at operate output the same time as the internal “warn before operate” buzzer. Gate Lock output Controls external solenoid locks or magnetic locks.
  • Page 131 External Latching Gate Not functional in the Kinetic operator. Lock output Gate at Partial Open Active when the partial open position is reached or exceeded. Position Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...
  • Page 132 USER RELAYS - PROGRAMMING PROCEDURE Table 9. User-Programmable User Relays - Function Options No� Name Description DC Power Alert Active when on AC power or the battery voltage is above 21V. When used with User Relay 2, this option can shed electrical loads to conserve battery energy.
  • Page 133 Partial Open Limit, or, the gate is past Partial Open Limit and Partial Open input is activated. Outside Obstruction/ Activated when OOLD/OALD detector input tripped and gate Arming Loop Detector closed. Used for testing purposes. Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...

  • Page 134: Bi-Parting Gate Systems

    BI-PARTING GATE SYSTEMS Bi-parting Gate Systems Configuring two operators to be a Primary and Secondary pair is easy with the SmartDC Controller. There is no need to order a special model or any adapters. The area of the board marked Dual Gate employs a 3-wire RS485 serial port for communication between primary and secondary operators.

  • Page 135: Primary And Secondary Wiring Connections

    2� Attach a ring terminal to the shield wire and connect it to the SmartDC Controller’s convenient ground screw. Refer to Figure 35. Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...

  • Page 136: Primary And Secondary Menu Setup

    PRIMARY AND SECONDARY MENU SETUP Primary and Secondary Menu Setup Determine which unit will be set up as the Primary. The other unit will be set up as the Secondary. It doesn’t matter which unit is which, but you must identify the Primary and Secondary operators by taking the following steps.
  • Page 137 (communication wire severed or the power switch is turned off in one unit), both operators cease to function and an ERROR 4 (Primary/ Secondary Communication Error) appears in the display. Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...

  • Page 138: Reference

    REFERENCE Reference This section of the manual provides information which may be useful when installing Kinetic operators. It includes how to: • Connect a Radio Receiver for Remote Open • Install Gate Edge Sensors • Install a Gate Locking Mechanism •...

  • Page 139: Installing A Maglock Or Solenoid Lock

    4. Set the User Relay function in the Installer Menu to RL1 - 6. Refer to “Setting the User Relay Function in the Installer Menu” on page 141. Figure 37. Lock Installation 12/24 VDC Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...

  • Page 140: Installing A Lock For A High Voltage System

    INSTALLING A LOCK FOR A HIGH VOLTAGE SYSTEM Installing a Lock for a High Voltage System To install a lock on a higher voltage system (115V or 230V), take the following steps: 1. Connect one lead of the power supply to one lead of the lock’s coil.

  • Page 141: Setting The User Relay Function In The Installer Menu

    3. To access the Installer Menu, simultaneously press OPEN and RESET. 4. Use NEXT to navigate to the menu display. Change the setting using the SELECT and NEXT buttons. Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...

  • Page 142: Installing Vehicle Detectors And Loops

    INSTALLING VEHICLE DETECTORS AND LOOPS Installing Vehicle Detectors and Loops A vehicle detector passes a small current flow through the “loop” which then becomes an inductive coil. When a vehicle passes over the loop, the detector senses the resultant drop in the inductance, and actuates the detector output.
  • Page 143 Low resistance indicates broken or moisture-saturated insulation. This is common if inappropriate wire insulation has been used. A schematic for a slide gate loop layout is shown in Figure 41. Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...
  • Page 144 INSTALLING VEHICLE DETECTORS AND LOOPS Figure 41. Installing Vehicle Detectors and Loop Layout wallaceperimetersecurity.com Phone: 866.300.1110...

  • Page 145: Installing Photoelectric Sensors For External Entrapment Protection Only

    UL 325 Standard. There are two common types of photoelectric sensors, thru-beam and retro-reflective, and each has its advantages. Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...
  • Page 146 OPERATION NOTES • A thru-beam sensor is generally more powerful and able to function reliably with dirty optics and in poor weather. • A retro-reflective sensor does not require the installation and extra wiring of a separate emitter and receiver as is required in a thru-beam system, but retro-reflective eyes are generally more problematic in poor weather.

  • Page 147: Photo Eye Mounting And Alignment

    If the photo eye is realigned, be sure to perform the centering test again to verify that the reflector is truly in the center. Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...

  • Page 148: Installing Gate Edge Sensors

    INSTALLING GATE EDGE SENSORS Installing Gate Edge Sensors Figure 44. Gate Edge Sensor Installation Refer to Figure 44 to help plan the most appropriate placement of the edge sensors being installed. For sliding gates, one or more contact sensors (edge sensors) must be located at the leading edge, trailing edge and post-mounted both inside and outside of the sliding gate.

  • Page 149: Accessory Connections

    For UL 325 compliance, all external entrapment protection sensors must have N.C. sensor outputs monitoring and powering purposes. Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...
  • Page 150 ACCESSORY CONNECTIONS Figure 45. EMX-IRB-MON Photo Eye Wiring An Edge Sensor can be either hardwired through an adapter module (HY2NC) or a wireless transmitter/ receiver combo (WEL-200 or iGAZE RE). Figure 46 below shows the wiring and dip switch settings of a WEL-200.

  • Page 151: Smartdc Controller Troubleshooting

    Audio Alert buzzer sounds distinctive chirps. Any alerts, faults or errors are also logged into memory and date/time stamped. For diagnostic purposes these messages can be retrieved with optional S.T.A.R.T. software available from Wallace Perimeter Security. Refer to “Smart Touch Analyze and Retrieve Tool (S.T.A.R.T.)” on page 171.

  • Page 152: Troubleshooting

    TROUBLESHOOTING TROUBLESHOOTING Table 12. SmartDC Controller - Troubleshooting Display Description Ref. Possible Causes Solutions Condition Alert, Error or Fault No� SAFE MODE Safe Mode Alert Occurs when either the 1. Remove the obstruction. edge sensor or Inherent 2. Adjust the IES sensitivity. Entrapment Sensor (IES) 3.
  • Page 153 MENU FUNCTIONS” on SmartDC Controller. page 94. No additional 5. Transformer failure – automatic function is replace Transformer. possible, but limited push- button control is available to 18V. Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...
  • Page 154 TROUBLESHOOTING Table 12. SmartDC Controller - Troubleshooting Display Description Ref. Possible Causes Solutions Condition Alert, Error or Fault No� HYSECURITY Critically low 24V supply DC power is below 14V – 1. No AC Power. See item 3 BAD POWER power. This message can no control functions will be above.
  • Page 155 The HY5B has detected a Caused by inadequate The loop lead in wires and LOOP SHORTED loop shorted to ground. insulation of loop wires. roadway should be checked for problems or replaced. Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...
  • Page 156 TROUBLESHOOTING Table 12. SmartDC Controller - Troubleshooting Display Description Ref. Possible Causes Solutions Condition Alert, Error or Fault No� ALERT 9 The HY5B has detected Caused by broken loop The loop and lead in wires LOOP OPEN a lack of continuity in wire or wire has come should be checked for the loop wire.
  • Page 157 Batteries are not taking a The buzzer will chirp every CHANGE has detected that the charge properly. minute until the UPS batteries BATTERY 24VDC UPS batteries are replaced. need to be replaced. Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...
  • Page 158 TROUBLESHOOTING Table 12. SmartDC Controller - Troubleshooting Display Description Ref. Possible Causes Solutions Condition Alert, Error or Fault No� ALERT 19 Not used in Kinetic FALSE operators. SLOWDOWN ALERT 20 Not used in Kinetic LI BLOCK OPEN operators. FAULT 1 Should not occur in Maximum run timer fault.
  • Page 159 The gate is non- disconnected. 3. Press RESET to clear fault. operational while this fault is triggered. - DC switch off. FAULT 5 Not used in Kinetic LIMIT FAILED operators. Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...
  • Page 160 TROUBLESHOOTING Table 12. SmartDC Controller - Troubleshooting Display Description Ref. Possible Causes Solutions Condition Alert, Error or Fault No� FAULT 14 The SmartDC Controller Caused by broken gate 1. Check and correct gate STUCK GATE has tried 3 times to hardware or ice/snow hardware as required.
  • Page 161 Not used in Kinetic STC-VFD COMM operators. ERROR 7 Software issue exists Corrupt software or data. Call Wallace Perimeter MENU that may require factory Security Technical Support for CHECKSUM reset. assistance. Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...
  • Page 162 TROUBLESHOOTING Table 12. SmartDC Controller - Troubleshooting Display Description Ref. Possible Causes Solutions Condition Alert, Error or Fault No� ERROR 8 RPM sensor Motor Encoder or wires are Check wiring from the motor RPM SENSOR disconnected. damaged or unplugged. to the SmartDC Controller board.

  • Page 163: Vehicle Detector And Loop Fault Diagnostics

    Check that a vehicle is not parked on the loop. Also, determine if the loop is stable. An unstable loop can hold the detector in a triggered state. Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...
  • Page 164 VEHICLE DETECTOR AND LOOP FAULT DIAGNOSTICS Table 13. HY5B Vehicle Loop Detector Faults and Errors Alert or Error LCD Description Advisory Resolution ERROR 3 DETECTOR FAILED HY5B vehicle detector - The alert indicates the detector is Communication failed. The not communicating properly with the SmartDC Controller will SmartDC Controller.
  • Page 165 The strength of a detector call can be displayed in real time, on a scale of 0 to 7. As indicated in the table below, when the Installer Menu setting for a given detector is Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...

  • Page 166: Kinetic Schematics

    KINETIC SCHEMATICS set to 2, and the Menu button is pressed, the LCD display will read Level 0 - 7 Call Level. If the call strength on the display appears as a level 4 or less, consider increasing the sensitivity level by adjusting the rotary switch on the HY5B detector.
  • Page 167 Figure 47. Schematic for Kinetic DC 15 [Kinetic 1] and Kinetic DC 10F [Kinetic 2] Operator(s)
  • Page 169 Figure 48. Schematic for Kinetic DCS 15 [Kinetic 1S] and Kinetic DCS 10F [Kinetic 2S] Solar Operator(s)

  • Page 171: General Maintenance

    Minimum 128MB of RAM. • Minimum 5MB of hard drive disk space. • VGA graphics card (minimum resolution of 800 x 600). Figure 49. SmartDC Controller RS-232 and USB Connection Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...
  • Page 172 SMART TOUCH ANALYZE AND RETRIEVE TOOL (S.T.A.R.T.) Installing the S.T.A.R.T. Software 1� Bring up your web browser and type in https://hysecurity.com/ in the command line. 2� Click Support on the Nice | HySecurity home page. 3� Enter your user name and password. If you do not have a user name, register as an online member.

  • Page 173: Electrical Controls

    100,000 cycles and replaced as needed. • Replace worn-out batteries. Refer to “DC Battery Replacement” on page 176 and “Clock Battery Replacement” on page 178� Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...

  • Page 174: Software Maintenance

    GENERAL MAINTENANCE Software Maintenance The software on the SDC board is constantly being enhanced with new adaptive features that create an easier install and improve the on board diagnostic tools. Be sure to check the Nice | HySecurity website for the latest version of software before heading out for field maintenance. Use S.T.A.R.T.
  • Page 175 Be aware that the gate will cycle open and close (close or open) as it relearns its limits. See “Resetting the OPEN and CLOSE Limits” on page 99. Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...

  • Page 176: Dc Battery Replacement

    DC BATTERY REPLACEMENT DC Battery Replacement Wallace Perimeter Security provides a one-year warranty from the date of shipment for all the batteries supplied with the Kinetic operator. Indicators of a low battery include: • LOW BATTERY or DEAD BATTERY appears on the SmartDC Controller display which may or may not be indicative of normal discharge.
  • Page 177 3� Disconnect the black, blue, and red wires as you slide the batteries through the access window. Figure 51. Battery Removal via Access Window Figure 52. New DC Battery Replacement Figure 53. DC Battery Replacement Cover Removal Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...

  • Page 178: Clock Battery Replacement

    CLOCK BATTERY REPLACEMENT To install the two new batteries, reverse the removal procedure: 1� Connect the red wire to red terminal on the left battery and slide the battery onto the tray. 2� Attach the blue wire to the black terminal. 3�...
  • Page 179 SLIDE GATE (KINETIC) 2 YEAR LIMITED PRODUCT WARRANTY For a period of 2 Years from date of delivery, Wallace Perimeter Security (“WPS”) warrants the product delivered to Buyer as follows: (1) the hardware shall be free from defects in material and workmanship and will conform to the applicable WPS specification and the terms of this proposal, and (2) the software and firmware will conform to the applicable WPS specifications and the terms of use.

  • Page 181: Kinetic Dc Specifications

    (one for each direction) to protect entrapment zones in both the open and close direction of travel. Visit https://support.hysecurity.com/hc/en-us/categories/360003177593-Safety for more information on UL 325 standards and gate safety. Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023...
  • Page 182 115 Lowson Crescent Winnipeg, Manitoba, Canada R3P 1A6 Phone: 866.300.1110 wallaceperimetersecurity.com...
