Portable Tank Extractor
Model E-1200
Ref.
No.
Part No.
Description
1
B703473
Cord Set
2
B703472
Cord Retainer
3
B703471
Switch
4
B703470
Switch Plate
5
B703469
Motor Strap
6A
B703468
Motor A/C
6B
B703522
Motor B/C
7
B703467
Exh. Hose Adapter
Replacement Parts List
Save For Future Reference
Vac Motors Replacement Parts
Qty.
1
1
3
1
2
1
1
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Pullman Holt E1200
Summary of Contents for Pullman Holt E1200
- Page 1 Portable Tank Extractor Model E-1200 Ref. Part No. Description B703473 Cord Set B703472 Cord Retainer B703471 Switch B703470 Switch Plate B703469 Motor Strap B703468 Motor A/C B703522 Motor B/C B703467 Exh. Hose Adapter Replacement Parts List Save For Future Reference Vac Motors Replacement Parts Qty.
- Page 2 Ref. Part No. Description B703496 Lid Hinge B703495 B703494 Lid Gasket B703493 Hose Barb B703492 Gasket B703491 Elbow B960941 Dump Valve B980227 Gasket Body Replacement Parts Ref. Qty. Part No. B980228 B703490 B703489 B703488 B703487 B703486 B703485 Description Float Cage w/Ball Filter Coupler Latch...
- Page 3 Ref. Part No. Description B703484 Handle B703483 Caster B703482 Bumper Guard B703481 Bumper Insert B703480 Filter Screen B703479 Close Nipple B703478 90° Elbow Component Parts Ref. Qty. Part No. B703477 B700144 B700144 B703476 B703475 B703474 B703521 Description Hose Barb Hose Barb Hose Barb Pump Spring...
-
Page 4: Wiring Diagram
WIRING DIAGRAM 2 Vacuum Motors, 1 Pump WARNING Any repairs to the electrical system should be preformed by an Authorized Pullman-Holt Service Center or by a qualified electrician. 10702 N 46th Street • Tampa, FL 33617 (813)971-2223 • toll free (800) 237-7582 fax (813) 971-6090 •...
