SoundPlus Infrared Listening System Specifications
®
Multi–Channel Infrared Emitter, Model TX9
Dimensions, Weight: 11.25" W x 6.25" H x 2.125" D (28.6 cm x 15.9 cm x 5.4 cm), 1.9 lbs (0.9 kg)
Power Supply: Wall Transformer, 24 VAC, 50-60Hz, 35 VA, 3-pin MOLEX Connector
Power Cable: NEC Class 2 wiring, two-conductor, 18 ga, 200' (61m) max. length
Indicators: Green LED power indicator, red LED baseband indicator
Carrier Frequency: 50 kHz to 8 MHz
Emitter IR Power: 3.5 watts
Coverage Area: 28,000 sq. ft. (2600 sq. m) in single channel mode when using the RX22-4 Receiver
Baseband Input: BNC, 100 mV per carrier, 50 Ω, for use with WIR TX9 or MOD 232 only
Baseband Output: BNC, 50 Ω, for use with TX9 only
Baseband Cable: RG 58 Coax, BNC connectors, maximum 1000' (300m) length
Operating Requirements: 0-50º C ambient temperature, non-condensing, non-corrosive atmosphere
Mounting Kits: Wall or Ceiling Mount: BKT 024 Omnidirectional mount, Mic Stand Kit: SS-11 or SS-6
Warranty: 5 years on emitter, 90 days on accessories
Approvals: CE, FCC, RoHS, WEEE
Compatible Receivers: WIR RX22-4 Four-Channel Receiver, RX18 Two-Channel Receiver, RX15-2 Two-Channel Receiver
NOTE: SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE.
Visit our website for the latest specifications and publications: www.williamssound.com
MAN 132H
Color: Black with white legends, red acrylic lens (also available in white)
North America: TFP 010, UL/CSA
Europe: TFP 027-01, 2-pin Schuko plug, CE
UK: TFP 027-02, 3-pin UK plug, CE
Note: Each WIR TX9 requires its own power supply
18,000 sq. ft (1700 sq. m) in two channel mode when using the RX22-4 Receiver
11,000 sq. ft (1000 sq. m) in four channel mode when using the RX22-4 Receiver
3,500 sq. ft (325 sq. m) in single channel mode when using the RX15-2 Receiver
3,063 sq. ft (285 sq. m) in single channel mode when using the RX18 Receiver
(See coverage area diagrams)
