Infrared Receivers - Williams Sound SoundPlus MOD 232 Installation Manual And User's Manual

EARPHONE
JACK
"ON"
INDICATOR
SoundPlus Infrared Listening System
®

Infrared Receivers

Figure 13: Four Channel Receiver, Model WIR RX22-4
CHANNEL
EARPHONE SELECTOR
JACK
"ON"
INDICATOR
Figure 14: WIR RX15-2 Headset Receiver
Figure 15: WIR RX18 Under-the-chin Receiver
14
CHANNEL
SELECTOR
OFF
ON/OFF
VOLUME SWITCH
A162
OFF
ON/OFF
VOLUME SWITCH
LEFT
BATTERY
COVER
INFRARED
SENSOR
POWER/CHANNEL
SWITCH
VOLUME
KNOB
MONITOR/MUTE
BUTTON
AUDIO INPUT JACK
VOLUME
CONTROL
BATTERY
(BAT AP07D)
A162
RIGHT
POWER/
CHANNEL
INDICATOR
A169
A235
Channel Frequency
1 2.3 MHz
2 2.8 MHz
3 3.3 MHz
4 3.8 MHz
MAN 132H
