Wash options
Once you have selected your wash cycle you may wish to change the default wash options.
Water level
Auto water level (not available on QuickSmart™ washer)
Your washer has the ability to automatically select the most efficient water level
for the load.
1. Place your clothes in the washer.
2. Select the wash cycle (and select 'Auto' water level if not automatically
selected).
3. Touch
. The washer will automatically fill to the correct water level for the load,
for both phases of the wash.
• When washing an unusual load, eg large bulky garments, items or
pillows, we recommend you select the 'Delicate' cycle.
• If there is already water in the bowl, it is best to manually select the
water level.
Manual water level selection
The agitator has five levels marked on its stem that can be used to help
you select the correct water level. Select the correct water level by using
the mark nearest to the top of the load.
• The levels marked on the agitator do not correspond exactly to the level
of the water. They indicate the level of dry clothes suitable for the water
level.
• Your washer may occasionally add water during agitation. This is to
https://producthelp.fisherpaykel.com/au/Wash/Top_Loaders/WashSmart/WA7060G2/User_Guide_WA7060G2/18_Wash_opti...
Selecting 'Auto' water level
Updated: Thu, 16 Feb 2023 00:31:39 GMT
Powered by
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Fisher & Paykel WashSmart Eco
Summary of Contents for Fisher & Paykel WashSmart Eco
- Page 1 Wash options Once you have selected your wash cycle you may wish to change the default wash options. Water level Auto water level (not available on QuickSmart™ washer) Your washer has the ability to automatically select the most efficient water level for the load.
- Page 2 maintain the water level due to the release of air trapped in the garments. • Out of balance loads, tangling or splash-over can be caused by selecting a water level that is too high. Water level guide on agitator Wash Temp WashSmart™...
- Page 3 Spin Speed Your washer offers 3 spin speeds: WashSmart™ Eco washer has 1100 rpm, 700 rpm and 300 rpm, and WashSmart™ washer and QuickSmart™ washer have 1000 rpm, 700 rpm and 300 rpm, plus the additional ‘No Spin’ option. Simply increase or decrease your spin speed by touching the ‘Spin Speed’ button. Some spin speeds are not available on some cycles for best clothes care (eg ‘Delicate’...
- Page 4 Soak (WashSmart™ Eco washer and WashSmart™ washer only) Use the ‘Soak’ option to soak clothes during the agitation wash phase. Ensure items are colourfast before using ‘Soak’. When you select ‘Soak’ your washer will soak for a period of 2 hours before completing ‘Rinse’...
- Page 5 washer panel is shown) The ‘Eco Rinse’ option has not been designed to be used with fabric softener, as it does not have a deep rinse to dispense the softener correctly. Fabric softener should not be used if this option is selected. ‘Eco Rinse’...
- Page 6 example, you cannot select a ‘Hot’ wash on the ‘Delicate’ and ‘Wool’ cycles. Washing bulky items Forcing large items into the washer may result in them being damaged during washing. Make sure there is enough room in the washer for items to move when being washed.
- Page 7 Some wool underlays and sheepskin products can be washed in a washing machine but could produce excessive amounts of lint that may cause pump blockages. https://producthelp.fisherpaykel.com/au/Wash/Top_Loaders/WashSmart/WA7060G2/User_Guide_WA7060G2/18_Wash_opti… Updated: Thu, 16 Feb 2023 00:31:39 GMT Powered by...
