- Page 1 LAWNAIRE WITH EASY STEER TECHNOLOGY MODELS: 554910A LAWNAIRE V with EST - HONDA 554913A LAWNAIRE IV with EST - HONDA 554914B LAWNAIRE IV with EST - B&S 554916B LAWNAIRE V with EST - B&S...
- Page 2 CALIFORNIA Proposition 65 Warning WARNING Diesel engine exhaust and some The engine exhaust from this product of its constituents are known to the contains chemicals known to the State State of California to cause cancer, of California to cause cancer, birth birth defects and other reproductive defects or other reproductive harm.
-
Page 3: Table Of Contents
Lawnaire IV & V with EST IMPORTANT MESSAGE Thank you for purchasing this Schiller Grounds Care, Inc. product. You have purchased a world class product, one of the best designed and built anywhere. This machine comes with a Technical Manual containing safety, operation, parts, maintenance and service information. -
Page 4: Safety
Lawnaire SAFETY IV & V with EST NOTICE !!! This symbol means: ATTENTION! Unauthorized modifications may present extreme BECOME ALERT! safety hazards to operators and bystanders and could also result in product damage. Your safety and the safety of others is involved. Schiller Grounds Care, Inc. - Page 5 Lawnaire SAFETY IV & V with EST PREPARING FOR SAFE OPERATION Site preparation and circumstances Evaluate the terrain to determine what Operator preparation and training accessories and attachments are needed to Read the Operation & Safety properly and safely perform the job. Only use Manual accessories and attachments approved by the If an operator or mechanic...
- Page 6 Lawnaire SAFETY IV & V with EST OPERATING SAFELY Interrupting operation In general Before leaving the operator's position: Use extra care when loading or unloading the - Park on level ground. machine into a trailer or truck. - Disengage the traction clutch. Slow down and use caution when making turns - Shut off the engine.
- Page 7 Lawnaire SAFETY IV & V with EST MANEUVERING SAFELY MAINTENANCE AND STORAGE SAFETY In general In general Slow down before turning. Maintain machine according to manufacturer's Be aware when approaching blind corners, schedule and instructions for maximum safety shrubs, trees, tall grass or other objects that may and best results.
- Page 8 Lawnaire SAFETY IV & V with EST Tines Storage WARNING Tines are sharp and can Stop the engine and allow to cool before storing cut. Use extra caution when Drain the fuel tank outdoors only. handling. Wear appropriate Store fuel in an approved container in a cool, dry personal protective equip- place ment.
-
Page 9: Safety And Operation Decals
Lawnaire SAFETY AND OPERATION DECALS IV & V with EST Danger Hands And Feet Operating Instructions This decal is located on the main frame and informs the This decal can be found on top of the handlebar assembly. operator of areas which are capable of serious injury. It tells the operator the steps involved;... -
Page 10: Assembly/Set-Up Instructions
Lawnaire ASSEMBLY/SET-UP INSTRUCTIONS IV & V with EST GENERAL NOTE: FRONT, REAR, RIGHT HAND AND LEFT HAND REFERENCES BELOW ARE WITH RESPECT TO AN OPERATOR AT THE CONTROLS. UNPACKING 1. Cut the banding securing the aerator to the pallet. 2. Grab handle A and pull handle over to other side of unit. - Page 11 Lawnaire ASSEMBLY/SET-UP INSTRUCTIONS IV & V with EST CHECKING THE CLUTCH CABLE The clutch cable is adjusted prior to shipping; however, it should be checked before the unit is put into service. 1. Pull the clutch control handle D back and down and make sure the idler engages the belt.
-
Page 12: Controls
Lawnaire CONTROLS IV & V with EST HANDLE CONTROLS Transport Lift Handle C - Pushing down on the handle lowers the tines for aerating. Pulling the handle up raises the tines so the aerator can be moved or transported without incurring damage to the unit or the turf. - Page 13 Lawnaire CONTROLS IV & V with EST PRE-OPERATION CHECK LIST (OPERATOR’S RESPONSIBILITY) ___ Review and follow all safety rules and safety ___ Inspect area and remove stones, branches or decal instructions. other hard objects that might be thrown, ___ Check that all safety decals are installed and in causing injury or damage.
-
Page 14: Operation
Lawnaire OPERATION IV & V with EST AERATING NOTE: For best performance and maximum tine penetration, the lawn should be thoroughly watered the day before aeration. 1. Rotate the water drum on the front of the unit until the filler plug F is positioned at the top. Remove the plug, fill the drum with water and replace the plug. -
Page 15: Maintenance/Adjustments
Lawnaire MAINTENANCE & ADJUSTMENTS IV & V with EST MAINTENANCE Lubrication: Grease the idler pivot and wheel bearings at the start of the season and every 25 hours. Tines: Replace damaged or broken tines. Keep roller chain clean and in proper running Do not weld or straighten tines. -
Page 16: Transporting
Lawnaire TRANSPORTING IV & V with EST TRANSPORTING If a tote trailer will be used to transport the unit, the two cast weights must be removed from the aerator frame and a locking shaft installed in their place. Removing the cast weights and draining the water drum will decrease the weight for easier loading on a vehicle or trailer. -
Page 17: Storage
Lawnaire STORAGE IV & V with EST STORAGE INSTRUCTIONS To prevent possible explosion or ignition of vaporized fuel, do not store equipment with fuel in tank or To put the equipment into service after an carburetor in an enclosure with open flame (for extended period of storage: example, a furnace or water heater pilot light). -
Page 18: Specifications
Up to 2692 m² / hour ....Up to 3753 m² / hour Engines: Model 554910A & 544913A Model........HONDA GX120K1HX 4 cycle..7.2 cu.in. (118 cc)..*3.5 HP (2.6 KW) Starter.........Recoil, on/off switch Governor........3200 RPM, no load Idle Speed........1400 + 100 RPM Fuel Tank........ -
Page 19: Parts Section
Lawnaire PARTS SECTION IV & V with EST PARTS SECTION... -
Page 20: Frame Group
Lawnaire FRAME GROUP IV & V with EST FIGURE 1... - Page 21 Lawnaire FRAME GROUP IV & V with EST FIGURE 1 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 64140-9 COTTER PIN, 12 x 1.12 YS 64262-018 BLT-FLG HD 3/8-16X1-3/4 4137227 SPRING-TORSION 64163-61 WASHER 841261 SPROCKET, 16T, 1/2P 2703341.7 BELLCRANK AY, IDLER 2703519 BUSHING, SH .33X.75X.88 2703756.7...
-
Page 22: Main Group-Lawnaire Iv
Lawnaire MAIN GROUP-LAWNAIRE IV IV & V with EST FIGURE 2... - Page 23 Lawnaire MAIN GROUP LAWNAIRE IV IV & V with EST FIGURE 2 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 64163-29 WASHER-21/64 X 1 X 11GA 5 64140-9 COTTER PIN, 12 x 1.12 4124192 WHEEL, 8X2.5 SEMI-PNEUM 2 2703148 WEIGHT, LAWNAIRE 4117195 CABLE, CLUTCH 2703444...
-
Page 24: Main Group-Lawnaire V
Lawnaire MAIN GROUP-LAWNAIRE V IV & V with EST FIGURE 3... - Page 25 Lawnaire MAIN GROUP-LAWNAIRE V IV & V with EST FIGURE 3 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 64163-29 WASHER-21/64 X 1 X 11GA 6 64140-9 COTTER PIN, 12 x 1.12 4124192 WHEEL, 8X2.5 SEMI-PNEUM 2 2703026 AXLE, TRANSPORT WHEEL 2 2703148 WEIGHT, LAWNAIRE 4117195...
-
Page 26: Handle Group
Lawnaire HANDLE GROUP IV & V with EST FIGURE 4... - Page 27 Lawnaire HANDLE GROUP IV & V with EST FIGURE 4 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 64163-95 WSHR,.31.69.06 YS FLT 4138395 S-LA5 HANDLE W/DECALS 1 (USED ON LA V MODELS) 4138395 S-LA4 HANDLE W/DECALS (USED ON LA IV MODELS) 2703060.7 HANDLE, HEIGHT ADJ.
-
Page 28: Tine Wheel Group
Lawnaire TINE WHEEL GROUP IV & V with EST FIGURE 5 LA V LA IV... - Page 29 Lawnaire TINE WHEEL GROUP IV & V with EST FIGURE 5 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 4168461 WLDMT-TINE,CENTER 4167899 SEAL-1.0 X 1.312 X 0.125 (INCLUDES ITEMS 3,7,8 & 12) (QTY 5 ON LA V) (QTY 3 ON LA IV) 4167887 SHAFT-TINE,29.5 (USED ON LA V MODEL ONLY)
-
Page 30: Drum Group
Lawnaire DRUM GROUP IV & V with EST FIGURE 6... - Page 31 Lawnaire DRUM GROUP IV & V with EST FIGURE 6 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 2702741.7 PLATE, FLANGE 2703108.7 DRIVE AY, LA5 DRUM (USED ON LA V MODELS) 2703102.7 DRIVE AY, LA4 DRUM (USED ON LA IV MODELS) 2703157 SPROCKET, 30T .50P 2703508...
-
Page 32: Decal Group
Lawnaire DECAL GROUP IV & V with EST FIGURE 7 MADE WITH PRIDE IN THE U.S.A. JOHNSON CREEK, WISCONSIN ENGINE TO BE LEVEL WHEN FILLING OR ADDING OIL... - Page 33 521787 DECAL,OIL ENGINE LEVEL 1 835892 DECAL,DANGER HNDS&FT 2 840697 DECAL,WARNING BELT 4169357 LABEL-RYAN EST HANDLE 1 (USED ON LA V MODELS) 4169358 LABEL-LA IV EST HANDLE (USED ON LA IV MODELS) 4168234 LABEL-LA V EST (USED ON LA V MODELS)
- Page 34 SCHILLER GROUNDS CARE, INC. ONE BOB-CAT LANE P.O. BOX 469 JOHNSON CREEK, WI 53038 920-699-2000 www.schillergc.com ©Schiller Grounds Care, Inc. 2010...
