SELF-PROPELLED WALK BEHIND DRUM
TYPE AERATOR
MODELS:
744908B
LAWNAIRE IV 4HP HONDA
744909C
LAWNAIRE IV 6HP BRIGGS & STRATTON
744910B
LAWNAIRE V 4HP HONDA
744911C
LAWNAIRE V 6HP BRIGGS & STRATTON

Advertisement

loading
Need help?

Need help?

Do you have a question about the LAWNAIRE IV and is the answer not in the manual?

Questions and answers

Summary of Contents for ryan LAWNAIRE IV

  • Page 1 SELF-PROPELLED WALK BEHIND DRUM TYPE AERATOR MODELS: 744908B LAWNAIRE IV 4HP HONDA 744909C LAWNAIRE IV 6HP BRIGGS & STRATTON 744910B LAWNAIRE V 4HP HONDA 744911C LAWNAIRE V 6HP BRIGGS & STRATTON...
  • Page 2 CALIFORNIA Proposition 65 Warning WARNING Diesel engine exhaust and some the engine exhaust from this product of its constituents are known to the contains chemicals known to the State State of California to cause cancer, of California to cause cancer, birth birth defects and other reproductive defects or other reproductive harm.
  • Page 3: Table Of Contents

    Lawnaire IV & V IMPORTANT MESSAGE thank you for purchasing this Schiller Grounds Care, inc.product. You have purchased a world class product, one of the best designed and built anywhere. this machine comes with Operator's and Parts Manuals containing safety, operation, parts, maintenance and service information.
  • Page 4: Safety

    SAFETY Lawnaire IV & V NOTICE !!! this symbol means: ATTENTION! Unauthorized modifications may present extreme BECOME ALERT! safety hazards to operators and bystanders and could also result in product damage. Your safety and the safety of others is involved. Schiller Grounds Care, inc.
  • Page 5 SAFETY Lawnaire IV & V PREPARING FOR SAFE OPERATION Site preparation and circumstances Evaluate the terrain to determine what Operator preparation and training accessories and attachments are needed to Read the Operation & Safety properly and safely perform the job. Only use Manual accessories and attachments approved by the if an operator or mechanic...
  • Page 6 SAFETY Lawnaire IV & V OPERATING SAFELY Interrupting operation In general Before leaving the operator's position: Use extra care when loading or unloading the - Park on level ground. machine into a trailer or truck. - Disengage the traction clutch. Slow down and use caution when making turns - Shut off the engine.
  • Page 7 Lawnaire SAFETY IV & V MANEUVERING SAFELY MAINTENANCE AND STORAGE SAFETY In general In general Slow down before turning. Maintain machine according to manufacturer's Be aware when approaching blind corners, schedule and instructions for maximum safety shrubs, trees, tall grass or other objects that may and best results.
  • Page 8 SAFETY Lawnaire IV & V Tines Storage WARNING tines are shap and can cut. Use extra caution when Stop the engine and allow to cool before storing handling. Wear appropriate Drain the fuel tank outdoors only. personal protective equip- Store fuel in an approved container in a cool, dry ment.
  • Page 9: Safety And Operation Labels

    SAFETY AND OPERATION LABELS Lawnaire IV & V EC Conformity - Conforms to all EC Directives applicable. Throttle Control -Move the throttle lever forward for increased engine speed. -Pull the throttle lever backwards for slower engine speeds. -Keep feet clear of tines. -tines can pierce or crush.
  • Page 10 SAFETY AND OPERATION LABELS Lawnaire IV & V - rotating parts can entandle, cut and crush. read and understand Operator Manual. - Keep hands, away from moving parts. - replace if lost or damaged. - Do not operate without guards and shields in place. -tines can pierce or crush.
  • Page 11: Controls

    CONTROLS Lawnaire IV & V HANDLE CONTROLS Transport Lift Handle C - Pushing down on the handle lowers the tines for aerating. Pulling the handle up raises the tines so the aerator can be moved or transported without incurring damage to the unit or the turf.
  • Page 12 CONTROLS Lawnaire IV & V ENGINE CONTROLS the Lawnaire iv & v are available with either a Briggs & Stratton engine or a Honda engine. Briggs & Stratton Engine Controls the engine is equipped with an On/Off control A, a choke control B and fuel shut-off valve C.
  • Page 13 PRE-OPERATION CHECK LIST Lawnaire IV & V PRE-OPERATION CHECK LIST (OPERATOR’S RESPONSIBILITY) ___ review and follow all safety rules and safety ___ inspect area and remove stones, branches or decal instructions. other hard objects that might be thrown, ___ Check that all safety decals are installed and in causing injury or damage.
  • Page 14: Operation

    OPERATION Lawnaire IV & V AERATING NOTE: For best performance and maximum tine penetration, the lawn should be thoroughly watered the day before aeration. 1. rotate the water drum on the front of the unit until the filler plug F is positioned at the top. Remove the plug, fill the drum with water and replace the plug.
  • Page 15: Maintenance And Adjustments

    MAINTENANCE & ADJUSTMENTS Lawnaire IV & V MAINTENANCE Tines: replace damaged or broken tines. Do not weld or straighten tines. Clean tines after use, inside and out. Apply a light coat of oil to tines to prevent rust. Engine: With the engine in a level position check oil levels in the engine and gear reduction case.
  • Page 16: Transporting

    place.
  • Page 17: Storage

    STORAGE Lawnaire IV & V STORAGE INSTRUCTIONS to prevent possible explosion or ignition of vaporized fuel, do not store equipment with fuel in tank or To put the equipment into service after an carburetor in an enclosure with open flame (for extended period of storage: example, a furnace or water heater pilot light).
  • Page 18: Specifications

    SPECIFICATIONS Lawnaire IV & V LAWNAIRE IV LAWNAIRE V Dimensions: Dimensions: Width.......... 28" (711 mm) Width.......... 35.5" (902 mm) Length......... 51" (1295 mm) Length......... 52.5" (1334 mm) Length (handle folded)....46" (1168 mm) Length (handle folded)....46" (1168 mm) Height (transport).......
  • Page 19 Wombwell, Barnsley, South Yorkshire S73 OBS UK Jim White Declare that the machine(s) described below: Managing Director Make & type: ........Ryan, Lawnaire IV, V Date: February 23, 2010 Category: ..........Aerator Series: ..........744909C, 744911C Engine: ..........Briggs & Stratton type:............
  • Page 20 Wombwell, Barnsley, South Yorkshire S73 OBS UK Jim White Managing Director Date: February 23, 2010 Declare that the machine(s) described below: Make & type: ........Ryan, Lawnaire IV, V Category: ..........Aerator Series: ..........744908B, 744910B Engine: ..........Honda type:............ GX120UT1 Speed: ..........
