Loading Media And Ribbon
Ribbon
Printhead
Media
4. Thread the end of the ribbon under the rear ribbon guide roller,
22
Rear Ribbon Guide Roller
then between the platen and the printhead.
You can also refer to the arrows on the printer frame or to the
upper-right corner of the label inside the media cover for ribbon
loading instructions.
