- Page 1 SL100, SL200, SL100Plus & SL200Plus Electric Metered Water Softeners Installation Procedures & Operating Manual NOTE: These instructions apply to all 4 of the above water softeners. PLEASE READ FULLY BEFORE INSTALLATION...
- Page 2 Before installing your Scalemaster Water Softener please make a note here of the water hardness. This can be done with the Water Hardness Test Strips supplied with your softener.
- Page 3 Thank you for choosing a Scalemaster Water Softener Please take the time to read this installation guide. It will tell you in simple terms how to install and commission your new Scalemaster Water Softener to begin enjoying the benefits of softened water.
- Page 4 • Your Scalemaster Water Softener is designed to operate effectively with an incoming water pressure of between 1.0 bar and 6 bar. If your water supply is likely to fall outside these parameters we recommend that a booster pump or pressure reducing valve should be fitted accordingly.
- Page 5 Electrical Connection • For added safety Scalemaster Electric Water Softeners operate on low voltage via a plug in transformer. Use only the transformer supplied with the softener. ANY ELECTRICAL WORK REQUIRED TO INSTALL A MAINS POWER SUPPLY FOR THE WATER SOFTENER SHOULD ONLY BE CARRIED OUT BY A FULLY QUALIFIED ELECTRICIAN.
- Page 6 Controls: Layout & Operation. • Large LED Display: A 2 digit LED readout is highly visible for easy reading. • Easy 3 - Step Programming: Only 3 buttons are required to fully control the softener. • Camshaft Indicator: A column of windows located on the left of the LED readout display provides a visual indicator of the camshaft operation.
- Page 7 Valve Layout (Back) Drain (Discharge) 1/2” BSPT Outlet 3/4” BSPT Inlet 3/4” BSPT Meter Cable Brine Pickup 3/8” Low Voltage Power BSPT Supply Connection Point Fig. 2 Brine Pickup 3/8” BSPT (Alternative SL100Plus & SL200Plus Configuration). Typical Softener Installation Inlet / Outlet Layout drawing Bypass Loop Drain (Discharge)
- Page 8 Simple 3 - Step Programming STEP 1 Time of Day: Press the Time Set button (see Fig.1)until desired hour appears (see fig.4*). Time should be set to the nearest hour to the present time. For example, if you are set- ting up the water softener at 10.15am the timer would be set to 10.
- Page 9 SL100 & SL100Plus Metered Local Area Hardness Cu Meters Capacity SL200 & SL200Plus Metered Local Area Hardness Cu Meters Capacity NOTE: During programming, if a button is not pushed for 5 seconds, the control returns to the normal operation mode and displays the time of Day.
- Page 10 Congratulations your Water Softener is now fully operational. Technical Information - Approximate Cycle Times CYCLE ACTION SALT USED TIME BACK WASH MINUTES BRINE DRAW 1.5kg SL100 & SL100Plus MINUTES BRINE DRAW 2.2kg SL200 & SL200Plus MINUTES SLOW RINSE MINUTES REPRESSURIZE MINUTES...
- Page 11 Up to 5 person Up to 5 person Up to 7 person Up to 7 person Carbon Neutral Scalemaster product code 900216 900247 900230 900254 * Based on standard household use assuming average domestic use of 150 litres of water per person per day.
- Page 12 Scalemaster Limited Emerald way, Stone Business Park, Stone Staffordshire, ST15 0SR, England. TELEPHONE 01785 811636 FACSIMILE 01785 811511 TECHNICAL HELPLINE: 07990 064096 WWW.SCALEMASTER.CO.UK...
