Scalemaster SOFTLINE 100 Installation Procedures & Operating Manual

Electric metered water softeners

Advertisement

Quick Links

SOFTLINE 100 & 200
ELECTRIC METERED WATER SOFTENERS
Installation Procedures & Operating Manual
PLEASE READ FULLY BEFORE INSTALLATION

Advertisement

loading
Need help?

Need help?

Do you have a question about the SOFTLINE 100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Scalemaster SOFTLINE 100

  • Page 1 SOFTLINE 100 & 200 ELECTRIC METERED WATER SOFTENERS Installation Procedures & Operating Manual PLEASE READ FULLY BEFORE INSTALLATION...
  • Page 2 Before installing your Scalemaster Water Softener please make a note here of the water hardness. This can be done with the Water Hardness Test Strips supplied with your softener. If you are unsure you can contact your local Water Authority or contact the Scalemaster Sales office with your postcode.
  • Page 3 Thank you for choosing a Scalemaster Water Softener Please take the time to read this installation guide. It will tell you in simple terms how to install and commission your new Scalemaster Water Softener to begin enjoying the benefits of softened water.
  • Page 4 Water Line & Bypass Connections  A bypass loop should be installed on all Scalemaster 100 & 200 Water Softeners. The bypass valve loop isolates the Water Softener from the water system and provides unsoftened water to the water system during routine maintenance and servicing procedures.
  • Page 5 Electrical Connection  For added safety the Scalemaster 100/200 series control operates on low voltage via a plug in transformer. Use only the transformer supplied with the softener. ANY ELECTRICAL WORK REQUIRED TO INSTALL A MAINS POWER SUPPLY FOR THE WATER SOFTENER SHOULD ONLY BE CARRIED OUT BY A FULLY QUALIFIED ELECTRICIAN.
  • Page 6 Controls: Layout & Operation.  Large LED Display: A 2 digit LED readout is highly visible for easy reading.  Easy 3 - Step Programming: Only 3 buttons are required to fully control the softener.  Camshaft Indicator: A column of windows located on the left of the LED readout display provides a visual indicator of the camshaft operation.
  • Page 7 Valve Layout (Back) Drain (Discharge) Outlet 3/4” BSPT 1/2” BSPT Inlet 3/4” BSPT Meter Brine Cable Pickup 3/8” BSPT Voltage Power Supply Connection Fig. 2 Typical Softener Installation Inlet / Outlet Layout drawing Bypass Loop Drain (Discharge) Overflow Fig. 3...
  • Page 8 (see Fig. 5). If you have a 10 litre unit (Softline 100) the setting will be 1.5 (see Fig. 5) if you have a 15 litre unit (Softline 200) the setting will be 2.2. (If the setting is not correct, press the button until the correct setting is shown.
  • Page 9 TABLE A (SOFTLINE 100) Softline 100 Meter Hardness Cu Meters Capacity TABLE A (SOFTLINE 200) Softline 200 Meter Hardness Cu Meters Capacity NOTE: During programming, if a button is not pushed for 5 seconds, the control returns to the normal operation mode and displays the time of Day.
  • Page 10 Congratulations your Water Softener is now fully operational. Technical Information - Approximate Cycle Times SALT CYCLE ACTION TIME USED BACK WASH MINUTES BRINE DRAW 1.5kg SOFTLINE 100 MINUTES BRINE DRAW 2.2kg SOFTLINE 200 MINUTES SLOW RINSE MINUTES REPRESSURIZE MINUTES FAST RINSE...
  • Page 11 Technical Information - Product Specification SPECIFICATION SOFTLINE 100 SOFTLINE 200 Height 445mm 600mm Depth 460mm 460mm Depth Incl Connector 460mm 460mm Width 275mm 270mm Resin Volume 10 litre 15 litre Salt used per regen cycle 1500 grams 2200 grams Water used per regen cycle...
  • Page 12 Scalemaster Limited Emerald way, Stone Business Park, Stone Staffordshire, ST15 0SR, England. TELEPHONE 01785 811636 FACSIMILE 01785 811811 TECHNICAL HELPLINE: 07990 064096 WWW.SCALEMASTER.CO.UK...

This manual is also suitable for:

Softline 200
