Primera Bravo II Operator's Manual

Thank you for purchasing the Kiosk Kit for the Bravo™ Disc
Publisher. This will enable your Bravo to use both the right and left
bins as input, doubling the capacity of your Bravo. This sheet
describes the installation and use of the Kiosk Kit.
SECTION I: SETUP
1. Check to make sure the following items are enclosed:
Output Bin Holder
•
Output Bin
•
Teflon Tape Strips
•
Operators Manual and
•
other information
2. Attaching the Output Bin
After the software has
•
been updated, you will
need to attach the
Output Bin Holder
and Output Bin to the
Bravo to collect the
finished discs. Attach
the Output Bin Holder
as shown, aligning the
Locating Tabs on the
Output Bin Holder with
the Slots located on the
underside of the Bravo
allowing the holder to
hang off the edge of the
table. Notice the slots
do allow for adjusting
the position of the out-
put bin. If your discs
are not falling into the
bin, you will be able to
move the bin slightly to
align it.
Place the Output Bin on
•
the Output Bin Holder
as shown.
Output Chute
Output Bin
Holder
Output Bin
Slots
Locating Tabs
Output Holder
Output Bin
Your kit comes with
•
Teflon coated tape strips.
These may be necessary
if the discs you use do
not slide freely down
the Output Chute into
the Output Bin. Apply
the strips to the ribs of
the Chute as shown,
starting at the top of the
chute, and continuing
on down to the lower lip of the Chute to reduce friction and
cause the discs to eject properly.
SECTION II: ENABLING KIOSK MODE
Kiosk mode is available both in PrimoDVD and in the driver as a
printing option. This allows you to use the Kiosk Mode for full CD
production as well as print-only jobs.
Using Kiosk Mode in PrimoDVD
In PrimoDVD, click Robotics then Options. You will see the
following window:
Using Kiosk Mode in the Print Driver
If you are using the Bravo AutoPrinter,
or just want to print discs and have
them eject out the front of the unit, you
can enable Kiosk Mode in the driver as
well. In the Driver Settings you will see
a new option, Disc Output Location.
Simply set this to Kiosk Mode. If you
Start Tape Here
Ribs
Output Chute Lower Lip of Chute
Click the Enable Kiosk
Mode Check Box to use
this feature.
