Polycom MGC-100 Technical Bulletin page 2

•
Old AC 300W power supply (PWR0549E)
•
New AC 450W power supply (PWR2013B)
•
Old DC 300W power supply (PWR1130A)
•
New DC 450W power supply (PWR2012A-LO)
•
Old NEBS DC 300W power supply (PWR2011-A)
•
New NEBS DC 450W power supply (PWR2011B-LO)
What is the maximum number of cards that can be installed in the
older MGC-100 chassis with 300 watt power supplies (
Total Number of Cards
Supported in chassis:
16
15
14
13
12
11
10
9
Table A: MGC-100 with three 300 Watt Power Supplies and 10-amp Fuse in
110 Volt AC installations. Japan may be less.
What is the maximum number of cards that can be installed in the
new MGC-100 chassis with 450 watt power supplies (
Total Number of Cards
Supported in chassis:
16
15
14
Table B: MGC-100/MGC+100 with three 450 watt PS and 15-amp Circuit
breaker in 110 Volt AC Installations. Japan may be less.
Note: Video+8 modules require the most power (75 Watts each). The above
maximum configuration is based on the "worst case" power consumption. Please
use the Power Configurator for accurate analysis of your configuration.
MGC Product Bulletin
Version: 09082006
Number of other cards - old
and plus, excluding Video
(Worst Case):
16
14
12
10
8
6
4
2
Number of other cards - old
and plus, excluding Video
(Worst Case):
8
6
4
2 of 6
)?
110 volts AC
Number of
Video+8 Cards:
0
1
2
3
4
5
6
7
)?
110 Volts AC
Number of
Video+8 Cards:
8
9
10
