Warranty
Registration
P F
RODUCT EATURES
Product
AEC
Inputs and Outputs
Remote Control
© Polycom, Inc.
improves the sound quality of an automixer, for example, by preventing it from bring-
ing the noise level up and down when microphones are gated on and off. By cancel-
ling the noise picked up by each microphone, the overall signal to noise ratio (SNR) is
preserved. The result is crystal clear speech over a greater decibel range than any
other echo canceller. That means reduced listener fatigue and a higher quality audio
conference.
Please take a moment to fill out and return your warranty registration card. This
information will help us to provide you with better customer support and will allow us
to notify you with updated product features and software.
• Front panel LCD for controlling and configuring the product without a computer
• 5-band equalizer on all Inputs and Outputs (Parametric, High/Low Pass, High/
Low Shelf)
• Echo cancellation on Inputs 1-8
• Noise cancellation up to 15 dB
• Two internal automatic microphone mixers for Inputs 1-8
• 25 x 18 full cross point matrix mixer with expansion bus
• Internal signal generator for calibration mode and noise masking applications
• 2 year warranty
• 24 bit resolution
• 48 kHz sampling rate, >20 kHz bandwidth
• 270 ms AEC tail length
• 40 dB/sec convergence rate
• Can function in rooms with more than 10 dB of room gain
• 8 microphone/line level inputs with phantom power on each input
• 24 VDC Phantom Power
• 4 line level auxiliary inputs with nominal level of 0 dBu
• 12 digitally controlled analog trimpots for the 12 input signals
• 12 line level outputs with default nominal level of 0 dBu
• Automatic Gain Control (AGC) on Inputs 1-8.
• Phoenix connectors for audio input and output
• RS-232 port for remote control
• Reconfigurable parallel logic input/output
• ASPI bus for controlling multiple EF devices from a single controller
• EF bus for linking multiple EF2280s.
• Digital bus with 4 audio busses, 48 kHz sampling rate
• Up to 8 devices can be linked, each device providing 4 audio signals on the bus
3 V
ORTEX
I
NTRODUCTION
EF2280 Reference Manual
