What's Included
Phoenix
Connectors (24)
External
Power Supply
Figure 1. What's Included with your Vortex EF2280.
What's Not Included
Tools Needed for
Installation
V EF2280 Reference Manual
ORTEX
The Vortex EF2280 product package includes the following items:
• Vortex EF2280 Reference Manual
• Vortex EF2280
• External power supply
• Cat 5 cable for EF Bus or ASPI Bus
• EF Bus terminator
• Rack mount screws (4)
• Phoenix connectors (24)
• Cable clamp and screw
• CDROM containing other manuals and Conference Composer software
• Warranty Registration Card
Rackmount
Screws (4)
x
x
EF Bus
Terminator
1-Cat 5 cable (6 inches)
for EF Bus
or ASPI Bus
The following equipment is not included with the EF2280 product package, but may
be necessary to create a completely functional system:
• Microphones
• Loudspeakers
• Audio amplifier (or amplified loudspeaker)
• EF200 Phone Add
• Audio cables
• Videoconferencing codec or other four-wire interface (optional)
• RS-232 remote control device (optional)
• Screwdriver to mount the EF2280 in your rack.
• Phoenix connector screwdriver
Vortex ® EF2280
CDROM with
control software and manuals
Vortex EF2280 Reference Manual
