- Page 1 Waterproof Industrial Touch Panel WP-9L Series User Manual...
-
Page 2: Table Of Contents
Features …………………………………………………………………………………………………...…. • Motherboard Specification ……………………………………...………………………………………….. • System Specification …………...…………………………………………………………………………… • Connector Location …………………………………………………………………………………………. • Mounting Installation ………………………………………………………………………………………… • Bios setup ………………………………………………………………………………...……………….…. • Driver Installation …………………………………………………………………..…………………….…. • Contact Information ……………………………………………………………………..……………….…. Copyright © 2013 Kingdy Technology Inc. All Rights Reserved. WP-9L Series... -
Page 3: Package Contents
• 1 x CD • 4 x screws (M3 x 4) for 2.5” HDD or SSD (If customers order 2.5” HDD or SSD from our side, we don’t offer 4 screws) Copyright © 2013 Kingdy Technology Inc. All Rights Reserved. WP-9L Series... -
Page 4: Safety Instructions
Never spill liquid of any kind on the equipment. Copyright © 2013 Kingdy Technology Inc. All Rights Reserved. WP-9L Series... -
Page 5: Fcc & Ce Statement
The product(s) described in this manual complies with all applicable European Union (CE) directives if it has a CE marking. For computer systems to remain CE compliant, only CE-compliant parts may be used. Maintaining CE compliance also requires proper cable and cabling techniques. Copyright © 2013 Kingdy Technology Inc. All Rights Reserved. WP-9L Series... -
Page 6: Introduction
Introduction WP-9L series is a fanless AMD T40N 1.0Ghz fully IP65 Industrial stainless steel touch Panel PC. With its fanless, robust, waterproof and stainless steel feature, it is an ideal solution for noise-free operating environment. Size selection is from 15”, 17" to 19" for your choice. -
Page 7: Features
All IP65 waterproof stainless steel connectors including power switch with green LED indication Up to 2 x GLAN Up to 3 x RS232 Up to 2 x USB 1024 x 768 dpi (15”) 1280 x 1024 dpi (17” and 19”) Copyright © 2013 Kingdy Technology Inc. All Rights Reserved. WP-9L Series... -
Page 8: Motherboard Specification
- 1 x 12V DC-in Power DC 12V input Watchdog Timer Output System reset, Programmable 1 ~ 255 sec/min Operating temperature: 0°C ~ 60°C Environment Storage temperature: -20°C ~ 85°C Copyright © 2013 Kingdy Technology Inc. All Rights Reserved. WP-9L Series... -
Page 9: System Specification
0°C ~ 45°C Storage Temperature -10°C ~ 70°C Relative Humidity 0% - 95% non-condensing Windows 7 Pro, Embedded 7 Optional Items No touch screen, Memory, Storage devices, WIFI, OS Copyright © 2013 Kingdy Technology Inc. All Rights Reserved. WP-9L Series... -
Page 10: Connector Location
Connector Location 15” 17” or 19” Power Switch DC-in GLAN 5 RS232 Copyright © 2013 Kingdy Technology Inc. All Rights Reserved. WP-9L Series... -
Page 11: Mounting Installation
Step2: screw the VESA mounting bracket to the front of a wall or the front / back of an object dependingly ······ Step3: slide the VESA mounting plate onto the VESA mounting bracket Copyright © 2013 Kingdy Technology Inc. All Rights Reserved. WP-9L Series... -
Page 12: Bios Setup
23. Minute displays minutes from 00 to 59. Second Enables or disables the boot option for legacy mass displays seconds from 00 to 59. storage devices with option ROM. Copyright © 2013 Kingdy Technology Inc. All Rights Reserved. WP-9L Series... - Page 13 Enable this field to use the PME signal to wake up the system. Wake system with fixed time Enable or disable system wake on alarm event. When enabled, system will wake on the hr::min::sec specified. Copyright © 2013 Kingdy Technology Inc. All Rights Reserved. WP-9L Series...
- Page 14 If you are using an operating system other than Windows, this problem may occur. To avoid this problem, enable this field to limit the return value to 3 or less than 3. Copyright © 2013 Kingdy Technology Inc. All Rights Reserved. WP-9L Series...
- Page 15 EHCI driver. Legacy IDE This option configures the Serial A TA drives Device reset time-out as Legacy IDE storage devices. Selects the USB mass storage device start unit command timeout. Copyright © 2013 Kingdy Technology Inc. All Rights Reserved. WP-9L Series...
- Page 16 Set this field to Enabled to allow the system to alert you returns of a chassis intrusion event. Watchdog This field is used to enable or disable the Watchdog Timer function. Copyright © 2013 Kingdy Technology Inc. All Rights Reserved. WP-9L Series...
- Page 17 PC Health Status Configuration This section displays the SIO hardware health monitor. Serial Port Enables or disables the serial port. Change Settings Selects the IO/IRQ setting of the I/O device. Copyright © 2013 Kingdy Technology Inc. All Rights Reserved. WP-9L Series...
- Page 18 BIOS Setup JMB36X ATA Controller Configuration Chipset Configures relevant chipset functions. Copyright © 2013 Kingdy Technology Inc. All Rights Reserved. WP-9L Series...
- Page 19 BIOS Setup North Bridge Configuration GFX Configuration NB GPP Core Config Selects the NB GPP Core configuration. Copyright © 2013 Kingdy Technology Inc. All Rights Reserved. WP-9L Series...
- Page 20 BIOS Setup Memory Configuration Node 0 Information Copyright © 2013 Kingdy Technology Inc. All Rights Reserved. WP-9L Series...
- Page 21 BIOS Setup North Bridge LVDS Config Select South Bridge LVDS This field is used to enable or disable the LVDS Panel Copyright © 2013 Kingdy Technology Inc. All Rights Reserved. WP-9L Series...
- Page 22 BIOS Setup SB USB configuration SB HD Azalia configuration Copyright © 2013 Kingdy Technology Inc. All Rights Reserved. WP-9L Series...
- Page 23 NumLock on wherein the function of the numeric keypad is the number keys. When set to Off, the function of the numeric keypad is the arrow keys. Quiet Boot Enables or disables the quiet boot function. Copyright © 2013 Kingdy Technology Inc. All Rights Reserved. WP-9L Series...
- Page 24 Save Changes Save the changes done so far to any of the setup options. Discard Changes Discard the changes done so far to any of the setup options. Copyright © 2013 Kingdy Technology Inc. All Rights Reserved. WP-9L Series...
- Page 25 To restore user default to all the setup options, select then press <Enter>. this field and then press <Enter>. A dialog box will appear. Select Yes to restore user default. Copyright © 2013 Kingdy Technology Inc. All Rights Reserved. WP-9L Series...
-
Page 26: Driver Installation
Driver Installation The WP-9L Series comes with an AutoRun CD-ROM Step 3 –Install LAN Driver that contains all drivers and utilities that can help you to 1. Click on the STEP3-LAN folder and select the OS install the driver automatically. -
Page 27: Contact Information
Any questions, please contact your local dealer or contact us via the following means: Add: 10F, No. 2, Jian 8th Rd., Zhonghe Dist., New Taipei City 23511, Taiwan Tel: +886-2-6621-8811 Fax: +886-2-8226-1518 Sales Email: sales@kingdy.com.tw Technical Support Email: tech@kingdy.com.tw Website: www.kingdy.biz Copyright © 2013 Kingdy Technology Inc. All Rights Reserved. WP-9L Series... - Page 28 Inspiring a reliable solution...
