- Page 1 Manual and safety instructions | English Revision 2.00 The LPS II range...
-
Page 2: Safety Instructions - Un3480
– UN3480 AFETY INSTRUCTIONS The Lithium Power Supply (LPS) is classified as Class 9 dangerous goods according to UN3480, a power source with high energy density and hazardous materials in a sealed metal cabinet. Installation must follow national safety regulations in accordance with the requirements for enclosure, installation, creepage, clearance, marking and segregation requirements for the end-use application. -
Page 3: Table Of Contents
ONTENT SAFETY INSTRUCTIONS – UN3480 CONTENT GETTING STARTED 1.1 P RODUCT ONTENTS 1.2 P RODUCT ETAILS PRODUCT USAGE 2.1 230V AC O UTPUT 2.2 230V AC C HARGING 2.3 12V DC O UTPUT 2.4 12V/24V DC I NPUT 2.5 S OLAR HARGING TIPS AND TRICKS... -
Page 4: Getting Started
1. G ETTING TARTED 1.1 Product Box Contents QUANTITY DESCRIPTION AC charging cable (Neutrik – NAC3 FCA) AC output (Neutrik – NAC3 FCB) Cap for M8 bolt M8 bolt M4 bolt Rubber foot Installation guide 1.2 Product Details LPS II - OVERVIEW FRONT VIEW REAR VIEW DESCRIPTION... - Page 5 M12 - IO Pinout FUNCTION FRONT VIEW Single Wire (Communication) I/O Signal CAN High (Communication) CAN Low (Communication) NOTE: PIN 2 in the M12 connector labeled "REMOTE" is designed to supply power to the LPS Remote. The LPS Remote is not included and can be purchased separately. The display features two home screens - a simple view and an advanced view.
-
Page 6: Product Usage
2. P RODUCT SAGE It is recommended to perform a full battery cycle prior to the initial use. This can be done by fully discharging the battery and then charging it overnight using the 230V input. The LPS II is a compact power supply designed to provide power for a variety of 230V AC and 12V DC applications. -
Page 7: Dc Output
2.3 12V DC Output The LPS II has a 12V DC port for providing power to DC applications. To activate the 12V DC output, press the "12V" button. A green LED will light up, indicating that the functionality is active. WARNING: Using the wrong cable size or a cable connection... -
Page 8: Tips And Tricks
3. T RICKS 3.1 Limit AC/DC charging power If the power source has limited output, the AC and DC charging can be limited. The below setting will also limit the AC output in the LPS while connected to the mains. Limiting AC charging power using display Menu Path Description... -
Page 9: Troubleshooting
4. T ROUBLESHOOTING 4.1 Error list If the solutions provided below are unable to resolve the error or if the error code is not listed, contact your retailer. ERROR DESCRIPTION SOLUTION PRODUCT TEMPERATURE 4, 5, Unit temperature too low Let the device warm up or move it to a place with a 56, 57, higher ambient temperature 6, 7,... -
Page 10: Specifications
5. S PECIFICATIONS PARAMETER LPS II 1500 W LPS II 2000 LPS II 2500 LPS II 3000 1 kWh SE 1 kWh 1 kWh 2 kWh GENERAL SPECIFICATION Model no. CL2204/CL2214 CL2205/CL2215 CL2102/CL2112 CL2103/CL2113 Cooling Forced air Forced air Forced air Forced air Operating temperature... - Page 11 PARAMETER LPS II 1500 SE LPS II 2000 LPS II 2500 LPS II 3000 DC OUTPUT Voltage 10 - 14.4 V DC 10 - 14.4 V DC 10 - 14.4 V DC 10 - 14.4 V DC Discharge current - 180 A 180 A 180 A...
-
Page 12: Certifications And Complience
6. C ERTIFICATIONS AND OMPLIANCE Low Voltage Directive 2014/35/EU RoHS Directive 2011/65/EU EN62368-1, EN62133 EN 63000 EMC 2014/30/EU E-Marking EN61000-6-2, EN61000-6-3 UN-ECE Regulation 10, E5 10R – 06 0488... -
Page 13: Safety And Fuses
7. S AFETY AND USES These measures ensure the safe and secure operation of the electrical system: 230V AC input protected with 16A fuse. • 230V AC output protected by a Residual Current Circuit Breaker with Overload protection • (RCBO) 30mA/13A. •... -
Page 14: Storage
8. S TORAGE The battery can be stored at temperatures between -20⁰C and 45⁰C. For long term storage (>1 month), the battery should be fully charged and stored at temperatures between 0⁰C and 35⁰C. The battery needs to be charged every 6 months if not used. Do not store the battery upside down. 9. -
Page 15: Warranty
Obtain an authorisation number from the Clayton Power dealer before shipping the • device. Carefully pack the device and ship it (freight paid) to the Clayton Power dealer. Note that the device contains lithium batteries and must be shipped as... - Page 16 Sales: sales@claytonpower.com Service: service@claytonpower.com Phone: +45 4698 5760...
