Polycom SoundStation 2W EX Specifications page 2

Polycom SoundStation2W
®
Console
Size (L x W x H)
• 14.5 x 12.25 x 2.5 in
• (36.8 x 31.1 x 6.4 cm)
Weight
• 1.90 lb. (0.86 kg) (without battery)
Power
• 12VDC nominal; supplied by battery or portable
• AC charger
Portable charger power supply size & weight
• 2.2 x 2.85 x 1.85"
• Weight 1.0 lbs (0.45 kg)
Wireless Capability
• Wireless protocol – 2.4 GHz WDCT or 1.9 GHz
DECT
• Digital Spread Spectrum with Frequency Hopping
• Signal range – 150 feet from base station
• Dual diversity antennas
• Battery – Rechargeable Lithium-Ion battery pack
• Talk time – 12 hrs. (Basic Version), 24 hrs. (EX
Version)
• Standby time – Up to 80 hrs. (Basic Version), 160
hrs.
• (EX Version)
• Charge time –4 hrs. (Basic Version), 8 hrs. (EX
version)
• Signal strength and battery status continuously
displayed on LCD
• Portable console charger – 1 Amp standard 110V
power supply
Security
• 64 bit voice encryption between console and base
station
• Aux out record feature activated via console
keypad
Applications Port
• Four-foot mobile phone cable with standard 2.5mm
headset plugs
• Four-foot computer calling cable to connect to line-
out and line-in ports on computer*
Display
• High resolution backlit graphical LCD
Caller ID and phone book
• Support for multiple Caller ID standards
- Bellcore type 1 (requires a telephone company
subscription for activation)
- ETSI
- DTMF
- British Telecom
• Phone book/speed dial list – up to 25 entries
Keypad
• 12-key telephone keypad
• On-hook/off-hook, conference, mute, volume up/
down keys, menu, navigation keys
• 3 context sensitive soft keys including redial, hold,
programmable conference key
Polycom Worldwide Headquarters
4750 Willow Road, Pleasanton, CA 94588
1.800.POLYCOM or +1.925.924.6000
www.polycom.com
© 2009, Polycom, Inc. All rights reserved. POLYCOM®, the Polycom "Triangles" logo and the names and marks associated with Polycom's products are trademarks and/or service marks of Polycom, Inc. and are
registered and/or common law marks in the United States and various other countries. All other trademarks are property of their respective owners. No portion hereof may be reproduced or transmitted in any form
or by any means, for any purpose other than the recipient's personal use, without the express written permission of Polycom.
Features and Specifications
®
Console loudspeaker
• Frequency response: 300 to 3300 Hz
• Volume: adjustable to 94 dBA SPL (peak) volume
at 1.0 meters
Console microphones
• 3 cardioid microphones 300 to 3500 Hz
Audio
• Polycom Acoustic Clarity full duplex – IEEE 1329
• Type 1 @ -2dB idle limit
• Up to 10 ft. microphone pick-up range
• Gated microphones with intelligent microphone
mixing
• Dynamic noise reduction
Console interfaces
• 2.4 GHz WDCT or 1.9 GHz DECT radio interface
to base station
• 2.5 mm headset jack for cell phone connection
(cable included) 2
• Interface to charger
• Mini-USB port for software upgrades
• 2 EX microphone connections (EX version only)
• Console locking grommet (compatible with
standard laptop/PC security cables)
• Wall mounting fastening holes
Base Station
Size (L x W x H)
• 5.9" x 5.9 x 1.6 in (15.07 x 15.07 x 4.1 cm)
• Wall mountable
Weight
• 0.7 lb. (0.32kg)
User interface
• Power LED
• Call in progress LED
• Console Locating Button with audible console
feedback
Power
• Power: 110V, 50/60 Hz (power supply included)
Base station power supply size & weight
• 1.9 x 2.4 x 1.65"
• Weight – 0.55 lbs (0.25 kg)
Base station audio auxiliary output
• Style: RCA jack
• Output activated from console menu to ensure
privacy
Base station telco interface
• Network connection: 2-wire RJ-11 analog PBX or
PSTN interface
• Speech mode
• Bandwidth 300 Hz to 3.3 kHz
• Network requirements: compatible with standard
PSTN and PBX networks, analog or
• G.711 encoded
Accessories
• 2 cardioid extension microphones 300 – 3500 Hz
(for EX version only, wired mics)
• 4-Cell battery pack with 24 hour talk time
• 2-Cell battery pack with 12 hour talk time
• Replacement portable console charger
• Replacement cell phone connector cable
Regulatory compliance
• UL/C-UL
• ICES-003
• FCC Part 15.247
• FCC Part 68
• CE Mark (R and TTE Directive)
• A-Tick and C-Tick Marks
Environmental requirements
• Operating temperature: 40° - 104°F (5° - 40°C)
• Relative humidity: 20% - 85% (noncondensing)
• Storage temperature: -22° - 131°F (-30° - 55°C)
Recommended room conditions
• Reverberation time: <0.54 seconds
• Noise level: <48 dBa
• Approx room size: 10x20
SoundStation2W ships with:
• Tabletop phone console with integrated display and
keypad
• Compact base station
• Rechargeable Li-Ion battery pack
• Portable console charger
• 4 ft. cell phone connection link
• 4 ft. computer calling cable
3
• Base station power cable
• 1 7-ft. (2.1m) base station telco cable
• User documentation (user guide CD, quick
installation guide, registration card)
Warranty
• 1 year
1. Not all mobile phone models support the
SoundStation2W mobile phone connector.
Conferences using some mobile phone models
may experience diminished audio quality or other
functionality. For a list of mobile phones that are
know to work well with the SoundStation2W,
please consult www.polycom.com.
2. SoundStation2W uses a cable that connects
to a standard 2.5mm headset connector. If your
mobile phone model does not support this type of
connection you will need an adapter (not included).
3. Computer calling cable included with
SoundStation2W EX model, optional on other
models
Part No. 3726-07998-001 Rev 082409
