Specification - Fractal Define 7 Mini User Manual

Specification

Technische Daten / Spécifications / Especificaciones / Specifikationer / Технические характеристики / 仕様 / 规格 / 規格
Case dimensions (LxWxH)
3.5"/2.5" Universal drive positions
Dedicated 2.5" drive positions
Motherboard compatibility
Power supply type
Front ports
Front radiator
Top radiator
Rear radiator
Bottom radiator
PSU max length
GPU max length
CPU cooler max height
3
399 x 205 x 406 mm
2 (included) + fan slots (via optional Multibracket(s), sold separately)
4 (2 included, 8 mm max height for drives mounted behind motherboard tray)
mATX, Mini-DTX, Mini-ITX
ATX
USB Type-C, 2 x USB 3.0, 2 x USB 2.0, Audio & Mic
280 mm max
240 mm max (RAM max 35 mm or lower needed)
120 mm max
120 mm max
165 mm (HDD cage + 25 mm front fan installed)
306 mm with front fan, 331 mm without front fan
167 mm
