Polycom CX500 Specifications page 2

Polycom CX500
Audio and Acoustic Performance
Audio—General
• Polycom HD Voice technology (Polycom
Acoustic Clarity™ technology, mechanical
design and wideband codec support)
• Individual volume settings with visual
feedback for each audio path
• Voice activity detection
• Comfort noise fill
• DTMF tone generation/DTMF
event RTP payload
• Low-delay audio packet transmission
• Adaptive jitter buffers
• Packet loss concealment
• Background noise suppression
• Cellular Phone Immunity
• Automatic gain control
• Dynamic noise reduction
• Acoustic echo cancellation
Audio—Handset
• Handset Frequency response: 150 – 7kHz
• Compliant with ADA Section 508
Recommendations: Subpart B 1194.23
(all)
• Hearing aid compatible (HAC) for magnetic
coupling to approved HAC hearing aids
Audio—Speaker
• Monitor Only Speaker
• Speaker frequency response, 300 – 7kHz
• Speaker volume, maximum at 1/2 meter
peak volume: ≤ 81dB
CODEC support.
• Microsoft RTAudio technology
• G.722.1
• G.711 (narrowband)(A-law and μ-law)
Power
• Built-in, auto-sensing IEEE 802.3af-2003
Power over Ethernet Class 2
• Optional AC power kit
User Interface
• Display, 3.5" QVGA TFT 24-bit color
graphical display, 320 x 240 pixels, with
Unicode character capability
• LED backlight with adjustable brightness
• Backlight auto-dim when not in use
Accessibility
• High contrast UI graphic screen option
(software)
• Compatible with commercially-available
TTY adapter equipment
• TTY compatible handset port
Buttons/keys
• 12-button dial pad, 0 - 9, *, #
• Volume Up & Volume Down
Polycom Worldwide Headquarters
4750 Willow Road, Pleasanton, CA 94588
1.800.POLYCOM or +1.925.924.6000
www.polycom.com
© 2010 Polycom, Inc. All rights reserved. POLYCOM
and/or common law marks in the United States and various other countries. All other trademarks are property of their respective owners. No portion hereof may be reproduced or transmitted in any form or by any means,
for any purpose other than the recipient's personal use, without the express written permission of Polycom.
Specifications
• 2-way navigation: Up, Down, Select
• Home, Previous
• 2 soft keys + Menu
• Hookswitch for handset
• Mute/unmute
• Speakerphone
Indicators, LED
• Ringing/In Call/Hold
• Speaker
• Mute
Connectivity
• Single Ethernet 10/100 Base-T with RJ45
connector port
• IEEE 802.3af class single PoE Ethernet
10/100 Base-T
• Handset port, RJ-9
Included Accessories
• Ethernet cable, 7 ft (2m)
• Fixed position stand
Accessories available separately
• AC Power Kit, 5-pack, with 24V PSU and
2m line cord with local plug
• Wall Mount Kit: bracket with ~100mm
Ethernet patch cord
Physical
• Weight: phone with handset & cord: 722g;
packaged, with all included accessories:
1.264 kg
• Dimensions, maximum (d x w x h): phone:
195 x 181 x 179mm; packaged: 297 x
268 x 99 mm
• Security cable lock slot
Operating Conditions:
• Temperature: 0 to +40 degrees C (+32 to
104 degrees F)
• Relative Humidity: +10% to 90%,
non-condensing
Storage Temperature:
• -40 to +85 degrees C (-40 to +185
degrees F)
Regulatory Certifications
• Electrical Safety
-UL60950-1 (USA / Canada)
-IEC / EN60950-1 (EU)
-GOST(Russia)
-KCC(Korea)
• EMC – General
-CISPR22
• EMC – USA (Class B)
- FCC Part 15
• EMC - Canada (Class B)
-ICES00.3: 1998
• EMC – EU (Class B)
-EN 55022
-EN 55024
® , the Polycom "Triangles" logo and the names and marks associated with Polycom's products are trademarks and/or service marks of Polycom, Inc. and are registered
• EMC – ROW (Class B)
-C & A Tick (Australia)
-VCCI (Japan)
-GOST (Russia)
-KCC (Korea)
-TRA (UAE)
-Telepermit PTC220 (New Zealand)
User Interface Languages
• English
Following languages will be supported in
December 2010
• French
• Spanish
• German
• Italian
• Dutch
• Russian
• Brazilian Portuguese
• Japanese
• Korean
• Simplified Chinese
• Traditional Chinese
• Finnish
• Swedish
• Norwegian
• Danish
Software Features:
• Pre-requisites:
-Microsoft Lync Server 2010
-Microsoft Lync 2010
• Basic Mode
-Contacts
-Photos
-Message waiting indicator
- Standard Enterprise IP-PBX features, CAC,
Survivability, E911 (US only), call park, etc.
-Teleworker support
-Conference leader experience
• Enhanced Mode functionality not supported
for CX500
Part Number
• 2200-44300-025
Warranty
• 12 Months
Polycom CX500 Ships With:
• CX500 Desktop Phone Base
• Handset
• Stand
• 6 ft. handset curly cord
• Captive USB cable
• Quickstart Guide
• Warranty Card
2211_1010
