Specifications - Polycom 2200-11331-001 Specifications

Polycom SoundPoint IP 301*
Size
• 8.25 in x 6 in x 7.5 in x 1.25 in
(21 cm x 15 cm x 19 cm x 3 cm) (W x H x D x T)
Weight
• Shipping: 2.0 lb (0.90 kg)
Power
• External wall adapter with power provided directly to the phone
• Optional inline power cables for IEEE802.3af or
Cisco® Inline Powering
Headset Capability
• Individual modular jack compatible with Plantronics®
and GN Netcom® business headsets, amplified headsets
are recommended
Handset
• Hearing aid compatible
Display
• 4 line x 20 character wide LCD
• Customizable animated indicators
• Message alert indicator
Feature Keys
• 10 dedicated feature keys
- 2 line keys
- 5 configurable feature keys
- Mute key
- Headset key
- Predefined Hold key
• 3 context-sensitive soft keys
Audio
• Individual volume settings for each audio path with
visual feedback
• Customizable audio sound effects
• Hands-free Headset mode
• Built-in monitor speaker
• Support for G.711 m/A and G.729A (Annex B) codecs
• Adaptive jitter buffers and Packet Loss Concealment to
improve speech quality
• Voice Activity Detection and Comfort noise fill
• 3 Party Conferencing
• Telephony Tone Signaling (RFC2833)
• Record and Playback for diagnostic purposes
Network and Provisioning
• Dual 10/100 Mbit/s switched Ethernet ports
• Manual or dynamic host configuration protocol
(DHCP) setup
• Time and date synchronization using SNTP
• Server provisioned XML-based configuration files
• Web provisioning using built-in HTTP server
• Support for IEEE802.1p/Q tagging (VLAN), Layer 3 TOS
• Network Address Translation (NAT) support
• RTCP support (RFC1889)
• Event logging
• User-selectable hardware diagnostics
(Network/CPU/Memory monitor)
Polycom Headquarters:
Polycom EMEA:
Polycom Asia Pacific:

Specifications

Protocol and Feature Support
• Flexible software architecture allowing drop-in
signaling protocol stacks
• IETF Media Gateway Control Protocol (MGCP) v1.0
- RFC3435 (was 2705)
- RFC3149
- Configurable up to 2 lines -- - varies by IP PBX or
Softswitch solution
- NCSIO2
- Call agent controlled
- Manual call agent address
- Feature phone extensions for feature key and
display support
• IETF Session Initiation Protocol (SIP) -- - Basic/ Extension support
- RFC2387, RFC3261, RFC3262, RFC3263, RFC3264,
RFC3265, RFC3515
- RFC3325
- SIP Call Control -- - Transfer (RFC: TBD)
- SIP ''Replace'' Header (RFC: TBD)
Advanced Features:
- Flexible line appearance**
- Multiple call appearance**
- Simplified conference call initiation / splitting**
- Instant messaging
Security:
- Digest authentication
- HTTPS secure provisioning**
- URL syntax for Boot Server address*** (RFC 1738)
- Support for ''signed'' software executables***
SoundPoint IP 301 includes:
• SoundPoint IP 301 console
• Handset and headset cord
• Reversible desk-mount and wall-mount stand
• Network cable
• Power adapter
• Quick Start Guide
• Warranty registration card
Approvals
• EMI
- FCC Part 15 Class B
- ICES-003 Class B
- VCCI
- EN55022B
Safety
• UL 1950
• CE Mark
• CSA C22.2 No.950
• EN60950
Warranty
• 1 year
______
* - The SoundPoint IP 301 is currently offered in North America, Australia, and
New Zealand only
** - Requires SIP version 1.5.x or higher
*** - Requires BootRom 3.0.x or higher
