  • Page 1 Gaggenau User manual DF481500F Dishwasher...

  • Page 2: Table Of Contents

    Table of contents 1 Safety ..........   4 9 Features........   23 1.1 General information.... 4 9.1 Top basket ....... 23 1.2 Intended use....... 4 9.2 Bottom basket ...... 25 1.3 Restriction on user group... 4 9.3 Cutlery basket ...... 26 1.4 Safe installation ...... 4 9.4 Cutlery drawer ...... 26 1.5 Safe use ........ 6 9.5 Etagere ........ 28 1.6 Damaged appliance .... 8...
  • Page 3 21 Technical specifications..   67 14.6 Starting the programme .. 40 21.1 Information regarding Free 14.7 Interrupting programme .. 40 and Open Source Software.. 67 14.8 Terminate programme.... 40 14.9 Display programme inform- 22 Declaration of Conformity ..   67 ation........ 40 14.10 Switching off appliance .. 41 15 Basic settings......

  • Page 4: Safety

    aus Safety 1 Safety Observe the following safety instructions. 1.1 General information Read this instruction manual carefully. ¡ Keep the instruction manual and the product information safe ¡ for future reference or for the next owner. Do not connect the appliance if it has been damaged in transit. ¡...
  • Page 5 Safety aus WARNING ‒ Risk of electric shock! Incorrect installation is dangerous. Connect and operate the appliance only in accordance with the ▶ specifications on the rating plate. Always use the supplied power cable for the new appliance. ▶ Connect the appliance to a power supply with alternating cur- ▶...

  • Page 6: Safe Use

    aus Safety WARNING ‒ Risk of injury! Hinges move when opening and closing the appliance door and can cause injury. If built-under or integrable appliances are not in a cavity so that ▶ one side is accessible, the hinge area must be covered at the side.
  • Page 7 Safety aus WARNING ‒ Risk of injury! Leaving the appliance door open may result in injury. Only open the appliance door to load or unload tableware in or- ▶ der to prevent accidents, e.g. through tripping. Do not sit or stand on the appliance door when open. ▶...

  • Page 8: Damaged Appliance

    aus Safety 1.6 Damaged appliance WARNING ‒ Risk of electric shock! If the appliance or the power cord is damaged, this is dangerous. Never operate a damaged appliance. ▶ Never operate an appliance with a cracked or fractured surface. ▶ Never pull on the power cord to unplug the appliance. Always ▶...

  • Page 9: Safety Systems

    Safety aus WARNING ‒ Risk of harm to health! Children can lock themselves in the appliance, thereby putting their lives at risk. With redundant appliances, unplug the power cord. Then cut ▶ through the cord and damage the lock on the appliance door beyond repair so that the appliance door will no longer close.

  • Page 10: Preventing Material Damage

    aus Preventing If the water pressure is too high or Preventing 2 Preventing material too low, the appliance may not be able to operate properly. damage Make sure that the water pressure ▶ in the water supply system is min. Preventing 2.1 Safe installation 50 kPa (0.5 bar) and max.

  • Page 11: Electric Childproof Lock

    Environmental protection and saving energy aus 3.1 Electric childproof lock Change the sensor setting to the de- fault. The electric childproof lock makes it a Consumption is reduced. more difficult to open the appliance → "Sensors", Page 12 door. You can activate or deactivate the Zeolith drying automatically helps to electric childproof lock in the Basic save energy.

  • Page 12: Aquasensor

    aus Installation and connection 4.4 AquaSensor Sensor set- Description ting The AquaSensor is an optical meas- Very sensitive Adjusts the pro- uring device (light barrier) which gramme strength for measures the turbidity of the rinsing difficult conditions of water. You can save water with the use, e.g.

  • Page 13: Installing And Connecting The Appliance

    Installation and connection aus Installation material Connect the wastewater hose to ¡ the outlet connection of the siphon Steam guard plate ¡ using the enclosed parts. Mains cable ¡ When doing so, check that the 5.2 Installing and connecting wastewater hose is not kinked, crushed or twisted.
  • Page 14 aus Installation and connection Insert the non-heating appliance plug of the power cable into the appliance. Insert the mains plug of the appli- ance into a nearby socket. The connection data for the appli- ance can be found on the rating plate.

  • Page 15: Familiarising Yourself With Your Appliance

    Familiarising yourself with your appliance aus 6 Familiarising yourself with your appliance 6.1 Appliance You can find an overview of the parts of your appliance here. Rating plate Rating plate with E number and FD num- ber → Page 66. The data you need for Customer Service → Page 66.
  • Page 16 aus Familiarising yourself with your appliance Detergent dispenser Detergent → Page 34 is added to the de- tergent dispenser. Bottom basket Bottom basket → Page 25 Filter system Filter system → Page 48 Lower spray arm The lower spray arm washes the table- ware in the bottom basket. If the tableware has not been washed properly, clean the spray arms.

  • Page 17: Controls

    Familiarising yourself with your appliance aus 6.2 Controls You can use the control panel to configure all functions of your appliance and to obtain information about the operating status. With some buttons you can perform different functions. 5 6 7 8 ON/OFF button and reset Switching on the appliance button...
  • Page 18 aus Familiarising yourself with your appliance WLAN display Home Connect → Page 44 Timer programming Setting timer programming → Page 40 Remote Start → "Remote Start ", Page 45 Programme buttons and addi- Programmes tional functions Additional functions → Page 22 Start button Starting the programme → Page 40   buttons You can use these buttons to scroll between the basic settings.
  • Page 19 Programmes aus 7 Programmes You can find an overview of the pro- ditional function → Page 22 selec- grammes that can be selected here. ted. The running time will change if Different programmes, which can be the rinse aid system is switched off found on the control panel of your or rinse aid needs to be added.
  • Page 20 aus Programmes Programme Consumption val- Programme se- quence 1) Duration in hrs:mins 2) Energy con- sumption in kWh 3) Water con- sumption in litres 1) 1:40 - 1:55 Tableware: Sensor-controlled: ¡ Delicate table- Optimised by 2) 0,780 - ¡ ¡ ¡ Auto 35-45°C ware, cutlery, sensors de-  0,850 temperature-...
  • Page 21 Programmes aus Programme Consumption val- Programme se- quence 1) Duration in hrs:mins 2) Energy con- sumption in kWh 3) Water con- sumption in litres 1) 3:10 Tableware: Most economical ¡ Mixed table- programme: 2) 0,580 ¡ ¡ Eco 45° ware and cut- Pre-Rinse 3) 11,5 ¡...

  • Page 22: Information For Test Institute

    aus Additional functions Press the button for the relevant 7.1 Information for test insti- additional function. tute → "Additional functions", Page 22 Test institutes can request the condi- Press for 3 seconds. tions for comparison tests, e.g. ac- The selected programme and the cording to AS/NZS2007, by sending additional function will flash.

  • Page 23: Additional Functions

    Features aus Additional Additional function function To ensure a is increased and ¡ higher hygiene the drying phase Hygiene status for the ap- extended. pliance and table- Especially suitable ¡ ware, the temper- for drying plastic ature is raised and parts. maintained for an There is a slight ¡...
  • Page 24 aus Features To prevent the basket from sud- Lift the basket forwards out of the denly dropping down, hold the catches ⁠ . side of the basket by the top edge. Press in the levers on the right and left on the outside of the basket. Lower the basket and pull out.

  • Page 25: Bottom Basket

    Features aus Lift the basket slightly and guide the rear detent pins into the rear locking hooks of the guide rails ⁠ . Lower the basket and press the front detent pins into the notches ⁠ . The basket clicks into position. Slide the basket back into the ap- pliance ⁠...

  • Page 26: Cutlery Basket

    aus Features Lift the basket out of the rear hold- 9.4 Cutlery drawer ers. Arrange cutlery in the cutlery drawer. Slide the guide rails into the appli- ance. Installing the bottom basket Pull the guide rails of the bottom basket out of the appliance. Insert the bottom basket into the rear holders and slide back slightly ⁠...
  • Page 27 Features aus To fold down the front prongs, Lift the cutlery drawer forwards out push the lever forwards and fold of the catches ⁠ . down the prongs ⁠ . Lower the cutlery drawer and pull out. If you want to return the cutlery drawer to the original position, fold the side shelf back up until it clicks into position.

  • Page 28: Etagere

    aus Features Insert the cutlery drawer ⁠ . 9.5 Etagere Use the cutlery shelf and space un- derneath for small cups and glasses or for large items of cutlery, e.g. cooking spoons or serving cutlery. Observe the position of the detent pins. Lift the cutlery drawer slightly and guide the lower detent pins into the lower locking hooks of the...

  • Page 29: Baking Sheet Spray Head

    Features aus Push the lever forwards and fold Remove top basket. → Page 24 down the prongs ⁠ . Insert the baking sheet spray head in the holder and turn to the right ⁠ . To use the prongs again, fold them back up. The baking sheet spray head The prongs audibly click into posi- clicks into position.

  • Page 30: Stemware Basket

    aus Features Clean under running water. Selecting Optional extra cleaning Place the Optional extra cleaning area area in the top basket and lock in Note: If you operate your appliance position ⁠ . with the Optional extra cleaning area switched on, consumption will in- crease.
  • Page 31 Features aus Turn the rotating fixing arm clock- Requirements The top basket is set to setting 1. wise and push down ⁠ . ¡ The prongs in the bottom basket ¡ are folded down. → "Folding down prongs", Page 28 Pull up the rotating fixing arms and turn anticlockwise The fixing arm clicks into position.

  • Page 32: Gastronorm Container Insert

    aus first time 9.10 Gastronorm container insert Use the standardised Gastronorm container insert to position large flat items securely, e.g. Gastronorm con- tainers or dishes. 9.11 Basket heights Set the baskets at the right height. Appliance height 86.5 cm with cutlery basket Level Top basket Bottom basket 1 max.

  • Page 33: Rinse Aid System

    Rinse aid system aus Tip: If you select Initial start-up Press the catch on the lid of the Home Connect here, make further dispenser for rinse aid and lift settings using the Home Connect ⁠ . app on your mobile device. You can change the settings for initial start-up and other Basic set- tings → Page 42 on the appliance at any time or use the Home Con-...

  • Page 34: Switching The Rinse Aid System Off

    aus Detergent Press repeatedly until the display 12 Detergent shows "Rinse aid dispenser". Press repeatedly until the right amount of rinse aid has been 12.1 Suitable detergents set. Only use detergents that are suitable – A low setting adds less rinse aid for dishwashers. Both separate and during the wash cycle and re- combined detergents are suitable.

  • Page 35: Unsuitable Detergents

    Detergent aus Combined detergents Detergent Description Besides conventional separate deter- Liquid detergent Liquid detergent gents, a number of products are works faster and available with additional functions. is recommended These products not only contain de- for shorter Pro- tergent, but also rinse aid and salt re- grammes placement substances (3in1) and, → Page 19...

  • Page 36: Adding Detergent

    aus Detergent Set the rinse aid system to the Add the detergent to the dry deter- ¡ separate or combined detergent in gent dispenser. use. Follow the manufacturer's instruc- ¡ 50 ml tions for each detergent. 25 ml To prevent sticking, only touch de- ¡...

  • Page 37: Tableware

    Tableware aus Close the lid of the detergent dis- 13.1 Damage to glass and penser. tableware Only put glasses and china in the dishwasher if it is marked as dish- washer-safe by the manufacturer. Avoid damage to glass and table- ware. Cause Recommenda- tion The following...

  • Page 38: Arrange Tableware

    aus Tableware For better washing and drying res- ¡ Cause Recommenda- ults, position items with curves or tion recesses at an angle so water can Highly caustic al- If you are using run off. kaline or highly highly caustic al- acidic cleaning kaline or highly solutions, in par- acidic cleaning...

  • Page 39: Removing Tableware

    operation aus If the electric childproof lock is ac- tivated, press on the upper middle section of the appliance door twice with a short interval in between. The appliance door will open auto- matically. 14.2 Switching on the appli- ance Press ⁠ . ▶...

  • Page 40: Setting Timer Programming

    aus operation Tip: To assist the drying, we recom- 14.5 Setting timer program- mend that the door will be partially ming opened after the cycle. You can delay the start of the pro- 14.7 Interrupting programme gramme by up to 24 hours. Press ⁠ . Note: When you open the appliance Press repeatedly until the...

  • Page 41: Switching Off Appliance

    operation aus Press the programme button or an additional function. 14.10 Switching off appliance Please note the information on Safe use → Page 10. Press Tip: If you press during the wash cycle, the programme currently run- ning will be interrupted. When you switch the appliance back on, the programme continues automatically.

  • Page 42: Basic Settings

    aus Basic settings 15 Basic settings You can configure the basic settings for your appliance to meet your needs. 15.1 Overview of basic settings The basic settings depend on the features of your appliance. Basic setting Selection Description Time setting 00:00 - 24:00 Set the current time.
  • Page 43 Basic settings aus Basic setting Selection Description Water connection Cold water Set cold water or hot water connec- Hot water tion. Only set the appliance to hot water if this can be prepared with little energy and a suitable installation is available, e.g.

  • Page 44: Changing Basic Settings

    aus Home Connect Basic setting Selection Description Remote Start Activate or deactivate Manual → "Remote Start ", Page 45. Permanent This basic setting is not available until after you have connected the device with the Home Connect app. → "Home Connect ", Page 44 Greeting Switch display of the brand name logo on or off when the appliance is switched on.

  • Page 45: Home Connect

    Home Connect aus With the help of the Home Connect Tips Please consult the documents sup- App scan the QR code. ¡ plied by Home Connect. Please also follow the instructions ¡ in the Home Connect app. Note: Please note the safety precau- tions in this instruction manual and make sure that they are also ob- served when operating the appliance via the Home Connect app.

  • Page 46: Remote Diagnostics

    aus Cleaning and servicing Press ⁠ . Security certificate of the Wi-Fi ¡ ▶ communication module (to ensure If you open the appliance door, the a secure data connection). function is automatically deactiv- The current software and hardware ¡ ated. version of your appliance. button lights up.

  • Page 47: Cleaning Products

    Dishwasher Care and Ma- ance to malfunction. To avoid such chine Cleaner for Dishwashers online faults and reduce odours, we recom- at https://www.gaggenau.com/ mend cleaning your appliance at reg- global/store or from customer ser- ular intervals. vice.

  • Page 48: Filter System

    aus Cleaning and servicing not have a reminder function, we re- Once the programme has ended, commend performing Machine Care the indicator for Machine Care every 2 months. goes out. Running Machine Care 17.5 Filter system Notes The filter system removes coarse Run the Machine Care programme ¡...

  • Page 49: Cleaning Spray Arms

    Cleaning and servicing aus Pull down the micro filter to re- Insert the filter system into the ap- move. pliance and turn the coarse filter clockwise. Make sure that the arrow mark- ‒ ings match up. Press the locking catches gether and lift the coarse filter out ⁠...
  • Page 50 aus Cleaning and servicing Pull up the lower spray arm to re- move. Check the outlet nozzles on the spray arms for blockages under running water and remove any for- eign bodies. Insert the lower spray arm. The spray arm clicks into position. Insert the upper spray arm and screw it firmly in place.

  • Page 51: Troubleshooting

    Troubleshooting aus 18 Troubleshooting You can rectify minor faults on your appliance yourself. Read the troubleshoot- ing information before contacting after-sales service. This will avoid unneces- sary costs. WARNING Risk of electric shock! Incorrect repairs are dangerous. Repairs to the appliance should only be carried out by trained specialist ▶...
  • Page 52 aus Troubleshooting Fault Cause and troubleshooting Appliance door does Automatic door opening is not in home position. not open. Wait one second after closing the appliance door. ▶ Appliance door opens Door is not correctly adjusted. too wide when activ- Adjust the appliance door as described in the in- ▶...
  • Page 53 Troubleshooting aus Fault Cause and troubleshooting E:3200 or indicator Remove the filter from the supply hose for water supply lights Clean the filter. Re-insert the filter in the supply hose. Screw the water connection back on. Check the water connection for leaks. Restore the power supply.
  • Page 54 aus Troubleshooting Fault Cause and troubleshooting E:9240 lights up. Filters are soiled or blocked. Clean the filters. ▶ → "Cleaning filters", Page 48 A different error code A technical fault is present. appears in the display Press window. Unplug the appliance or switch off the fuse. Wait at least 2 minutes.
  • Page 55 Troubleshooting aus Fault Cause and troubleshooting Tableware is not dry. Use rinse aid to improve drying performance. Use a different combined detergent with a better drying performance. Extra Dry not activated to improve drying perform- ance. Activate Extra Dry → Page 42. ▶ Tableware removed too early or drying process not yet ended.
  • Page 56 aus Troubleshooting Fault Cause and troubleshooting Remnants of food on Clean the filters. ▶ tableware. → "Cleaning filters", Page 48 Filters are inserted incorrectly and/or not engaged. Insert the filters properly. → "Filter system", Page 48 Engage the filters. Washing programme selected too weak. Select a more intensive washing programme. ▶...
  • Page 57 Troubleshooting aus Fault Cause and troubleshooting Detergent residue in Select a more intensive Programme or use Powder ▶ the appliance detergent. Washing effect and dissolving performance are re- duced after a prolonged storage time or detergent is very lumpy. Change your detergent → Page 34. ▶...
  • Page 58 aus Troubleshooting Fault Cause and troubleshooting Tea residue or lipstick Only remove large remnants of food and do not ▶ marks on tableware. prerinse tableware. Adjust the sensitivity of the sensors. ▶ → "Sensors", Page 12 Coloured coatings The formation of films is due to substances contained (blue, yellow, brown) in vegetables (cabbage, celery, potatoes, noodles, that are difficult or im-...
  • Page 59 Troubleshooting aus Fault Cause and troubleshooting Removable streaks Arrange tableware in the top basket tableware so are present on the tab collecting tray is not obstructed by table- glasses, glassware ware. with a metallic appear- → "Arrange tableware", Page 38 ance and cutlery. Items of tableware are blocking the dispenser lid.
  • Page 60 aus Troubleshooting Fault Cause and troubleshooting Excessive formation of Hand washing-up liquid is present in dispenser for foam occurs. rinse aid. Immediately add rinse aid to the dispenser. ▶ → "Adding rinse aid", Page 33 Rinse aid has been spilled. Remove the rinse aid with a cloth. ▶...
  • Page 61 Troubleshooting aus Fault Cause and troubleshooting Water is left in the ap- → "Terminate programme", Page 40 ▶ pliance at the end of the programme. Appliance cannot be Software update is taking place. switched on or oper- Wait until the software update has finished. ▶...
  • Page 62 aus Troubleshooting Fault Cause and troubleshooting All LEDs lit up or Electronics have detected a fault. flashing. Press the main switch button for approx. 4 seconds. → "Controls", Page 17 The appliance is reset and restarted. If the problem occurs again: Switch off the appliance. ‒...
  • Page 63 Troubleshooting aus Fault Cause and troubleshooting Knocking or rattling With a small load the water jets directly strike against noise. the tub. Distribute the tableware evenly. ▶ Load the appliance with more tableware. ▶ Light items of tableware move about during the wash cycle.

  • Page 64: Clean Wastewater Pump

    aus Transportation, storage and disposal Insert the pump cover and press 18.1 Clean wastewater pump down ⁠ . Large remnants of food or foreign bodies can block the waste water pump. As soon as the rinsing water no longer drains properly, the waste water pump must be cleaned.

  • Page 65: Protect Appliance From Frost

    Transportation, storage and disposal aus 19.2 Protect appliance from 19.4 Disposing of old appli- frost ance If there is a risk of frost where the ap- Valuable raw materials can be re- pliance will be standing, e.g. in a holi- used by recycling. day home, empty the appliance com- pletely.

  • Page 66: Customer Service

    aus Customer Service from water damage, the appliance 20 Customer Service must be connected to the power supply. If you have any queries, are unable to The liability guarantee is valid for ¡ rectify faults on the appliance your- the service life of the appliance. self or if your appliance needs to be A claim can only be made under ¡...
  • Page 67 A detailed RED Declaration of Con- Munich, Germany. formity can be found online at The source code will be made avail- www.gaggenau.com among the addi- able to you on request. tional documents on the product page for your appliance. Depending on the appliance specifications...
  • Page 68 aus Declaration of Conformity 2.4 GHz band (2400–2483.5 MHz): Max. 100 mW 5 GHz band (5150–5350 MHz + 5470–5725 MHz): Max. 100 mW UK (NI) 5 GHz WLAN (Wi-Fi): For indoor use only. 5 GHz WLAN (Wi-Fi): For indoor use only.
  • Page 72 BSH Hausgeräte GmbH Carl-Wery-Straße 34 81739 München, GERMANY www.gaggenau.com...
