PCB Piezotronics IMI SENSORS EX607A61 Installation And Operating Manual page 16

Model Number
607A61
Performance
Sensitivity (±15 %)
Measurement Range
Frequency Range (±3 dB)
Resonant Frequency
Broadband Resolution (1 to 10000 Hz)
Non-Linearity
Transverse Sensitivity
Environmental
Overload Limit (Shock)
Temperature Range
Enclosure Rating
Electrical
Settling Time (within 1% of bias)
Discharge Time Constant
Excitation Voltage
Constant Current Excitation
Output Impedance
Output Bias Voltage
Spectral Noise (10 Hz)
Spectral Noise (100 Hz)
Spectral Noise (1 kHz)
Electrical Isolation (Case)
Physical
Size (Hex x Height)
Weight (without cable)
Mounting
Mounting Thread
Mounting Torque (stud)
Mounting Torque (hex nut)
Sensing Element
Sensing Geometry
Housing Material
Sealing
Electrical Connector
Electrical Connection Position
Cable Length
Cable Type
[9]
®
SPINDLER INDUSTRIAL ICP® ACCELEROMETER
ENGLISH SI
100 mV/g 10.2 mV/(m/s²)
2
±50 g ±490 m/s
30 to 600000 cpm 0.5 to 10000 Hz
1500 kcpm 25 kHz
2
350 µg 3434 µm/sec
±1 % ±1 %
≤7 % ≤7 %
5000 g pk 49050 m/s² pk
-65 to +250 °F -54 to +121 °C
IP67 IP67
≤2 sec ≤2 sec
≥0.3 sec ≥0.3 sec
18 to 28 VDC 18 to 28 VDC
2 to 20 mA 2 to 20 mA
<150 Ohm <150 Ohm
8 to 12 VDC 8 to 12 VDC
2
8 µg/√Hz 78.5 (µm/sec /√Hz
2
5 µg/√Hz 49.1 (µm/sec /√Hz
2
4 µg/√Hz 39.2 (µm/sec /√Hz
8 8
>10 Ohm >10 Ohm
9/16 in x 1.0 in 14 mm x 25.4 mm
1.1 oz 31 gm
Stud Stud
1/4-28 Male Not Applicable
7 to 8 ft-lb 9.5 to 10.8 Nm
2 to 5 ft-lb 2.7 to 6.8 Nm
Ceramic Ceramic
Shear Shear
Stainless Steel Stainless Steel
Welded Hermetic Welded Hermetic
Integral Armored Integral Armored
Cable Cable
Side Side
10 ft 3.0 m
Polyurethane Polyurethane
Optional Versions (Optional versions have identical specifications and accessories as listed
[2] for standard model except where noted below. More than one option maybe used.)
EX - Hazardous Area Approval- contact factory for specific approvals
Hazardous Area Approval
[1]
[1]
[3]
Hazardous Area Approval
Hazardous Area Approval
Hazardous Area Approval
Hazardous Area Approval
M - Metric Mount
[1]
Supplied Accessory: Model M080A159 Mounting stud, 1/2-20 to M6x1 (for Models
[1]
M607A11and M607A61) replaces Model 080A156
[1]
TO - Temperature Output
Temperature Output Range
Temperature Scale Factor
Electrical Connector
[4]
Electrical Connections (Red)
[5]
[6][7]
Electrical Connections (Black)
Electrical Connections (White)
Notes
[1] Typical.
[2] Conversion Factor 1g = 9.81 m/s².
[3] Zero-based, least-squares, straight line method.
[4] Measured with mounting stud.
[5] 1/4-28 has no equivalent in S.I. units.
[8]
[6] Stud torque must exceed sensor hex nut torque to ensure proper dismantling.
[7] 1/8" hex Allen key required for English version, 4 mm hex Allen key required for
Metric version.
[8] Stainless steel armor jacket over twisted shielded pair.
[9] See PCB Declaration of Conformance PS023 or PS060 for details.
Supplied Accessories
080A156 Mounting Base (1)
ICS-2 NIST-traceable single-axis single-point amplitude response calibration at 6000 cpm
(100 Hz) ()
Entered: LLH Engineer: JEC
Date: Date:
03/20/2007 03/21/2007
Revision F
ECN #: 26068
Cl I, Div 2, Groups Cl I, Div 2, Groups
A, B, C, D; ExnL A, B, C, D; ExnL
IIC T4, AExnA IIC IIC T4, AExnA IIC
T4 T4
EEx nL IIC T4, - EEx nL IIC T4, -
40°C≤Ta≤121°C, II 40°C≤Ta≤121°C, II
3 G 3 G
EEx nL IIC T4, - EEx nL IIC T4, -
40°C≤Ta≤121°C, II 40°C≤Ta≤121°C, II
1 G 1 G
Cl I, Div I, Groups Cl I, Div I, Groups
A, B, C, D; Cl II, A, B, C, D; Cl II,
Div I, Groups E, F, Div I, Groups E, F,
G; Cl III, Div I G; Cl III, Div I
Exia IIC T4, AExia Exia IIC T4, AExia
IIC, T4 IIC, T4
+36 to +250 °F +2 to +121 °C
5.56 mV/°F + 32 (+10 mV/°C)
Integral Armored Integral Armored
Cable Cable
Acceleration Acceleration
Output Output
Ground Ground
Temperature Temperature
Output Output
Sales: EGY Approved: NJF Spec Number:
Date: Date: 13704
03/21/2007 03/21/2007
