8-3. Starting and Finishing Test

Be sure to carry out "11 Pre-Start Checkup" prior to proceeding with a test
Start the test after completing the checkups and various settings.
・ Start
Keep pressing the START Button for 1 second or more. A beep sounds, "Warning
Lamp M" begins to blink and the Unit will enter START (run) mode.
・ Finish
The test finishes in 1 second after the value shown in "TEST TIME Display" changes
from 1 to 0.
・ Stop
A test can be stopped by pressing STOP Button during START mode, and the Unit
goes back to STOP mode.
Do not START/STOP intentionally.
Turn the Unit power OFF after the test has been finished (or stopped), and the displays
become ready to enter (one of the monitors will blink).
The recommended procedure for turning the Unit power OFF is as follows;
1. Put the Unit in STOP mode
2. Turn DUT OFF, or make ready to turn it OFF.
3. Reduce out put of DC source to 0V.
4. Turn DC LINE OFF.
5. Turn the Unit power OFF.
6. Remove the accessory "Output Cable" plugs from "Output Terminals ⑤ , ⑥ . " At the
moment of the power OFF, the plugs are locked. Unlock the plugs by pushing them
deeper. Then unplug,
- - 25
