User Instructions
CMOD 70 Spreader Frame
The CMOD Spreader Frame is modular in span and every frame consists of 4 Corner Units,
with intermediate Struts that can be bolted into the assembly to achieve different spans.
CMOD 70 has an assembled span ranging from 4ft by 4ft to 40ft by 40ft in 1ft increments.
Assembled
Frame
α
P1
Strut

CMOD 70 Frame Specification

Rated at a maximum of 80 tonnes SWL.
Please see Table 2 for SWL at specific spans.
'Base to Sling' angle,
Corner Units are rated at 20 tonnes each
(80 tonnes combined capacity).
Bolt tightening torque: 110 Pound-Foot. Spanner size required: 30mm.
Recommended additional equipment: Torque Wrench, Podger Spanner and Ring Spanner.

WARNING!

Personnel using this system should be suitably trained, competent and have a clear
understanding of Safe Slinging procedures.
The use of Modulift equipment must be in accordance with the procedures laid down in 'ASME B30.20 - 2013' .
Never exceed stated SWL
The top sling length is critical to the safe use of the spreader
Modulift UK Ltd tel: 011 44 1202 621511 email: sales@modulift.com www.modulift.com
Fig. 1 – Typical CMOD Spreader Frame Assembly
= Base to sling angle (BSA)
α
Span
Corner Unit
, no less than 45 degrees.
α
– Adhere to SWL in Table 2 for particular sling angle used.
P2–P6
Table 1 – Component List
Part Ref.
Description
P1
Corner Unit
P2
12ft Strut
P3
6ft Strut
P4
3ft Strut
P5
2ft Strut
P6
1ft Strut
P7
42.5t Shackle
P8
35t Shackle
P9
M20 x 65, Grade 8.8, HT Bolts, Nuts & Washers
– Ensure you refer to the correct table.
P9
P8
Weight/item
418 lbs
(length 2ft each)
487 lbs
279 lbs
209 lbs
140 lbs
105 lbs
62 lbs
44 lbs
P7
