Leigh Country TX 94104 Quick Start Manual

Figure 1
E
E
D
D
C
RIGHT
1. (SEE FIGURE 1) Take the Seat Panel (B) and align the holes to the holes of the Arm Frame (C) and secure by inserting Bolts (D) through the Arm Frame then
Seat Panel. Secure the Bolts (D) with the Hex Nuts (F) on the inside of the Seat Panel. Repeat for the other the Arm Frame (C).
Do not fully tighten the Nuts and Bolts.
2. Slide the Back Panel (A) between the Arm Frames (C) and align the holes. Secure by inserting Bolts (E) through the Arm Frame then Back Panel (A). Secure
the Bolts (E) with the Hex Nuts (F) on the inside of the Back Panel. Repeat for the other the Arm Frame (C).
3. Once all Hex Nuts and Bolts are secured, tighten all Bolts (D&E) with the Wrench (H).
4. Slide Plastic Nut Covers (G) over all exposed bolt ends.
METAL BENCH FLEUR DE LIS
ITEM # TX 94104
PART#
A
B
C
D
E
F
G
H
G
F
G
F
F G
PARTS & HARDWARE LIST
BACK PANEL
SEAT PANEL
ARM FRAME
BOLT M6 x 2"
BOLT M6 x 2.7"
HEX NUT
PLASTIC NUT COVER
WRENCH
G F
A
G
B

IMPORTANT: READ CAREFULLY BEFORE BEGINNING!

Make sure that all parts and hardware are present
before assembly.
Assemble on an a non-marring and level surface
Do not completely tighten all nuts and bolts until
the bench is fully assembled.
DESCRIPTION
F
F
G
Congratulations
on your assembly!
QUANTITY
1
1
2
4
4
8
8
2
E
E
D
D
C
LEFT
