Bestway 51004E Owner's Manual

OWNER'S MANUAL
IMPORTANT SAFETY INSTRUCTIONS
Read and Follow All Safety Information and
Instructions. Keep for future reference.
Failure to follow these warnings and
instructions can result in serious injury or
death to users, especially children.
WARNING
Prevent Drowning
Children under 5, especially toddlers are at Keep all electrical lines, radios, speakers,
highest risk of drowning. and other electrical devices away from
Closely watch children who are in or near this pool. pool. Do not place pool near or under
Empty pool or prevent access when not in use. overhead electrical lines.
Prevent Young Children From Drowning:
• Install fencing or approved barrier around all sides of pool.
• State or local laws or codes may require fencing or other approved
barriers.
• Check state or local laws and codes before setting up pool.
• Drowning occurs silently and quickly. Assign an adult to supervise
pool and wear provided water watcher tag.
• Keep children in your direct sight when they are in or near pool and
when you are filling and emptying pool.
• When searching for a missing child, check pool first, even if you think
your child is in the house.
• Pool presents a drowning hazard even during filling and draining of
the pool.
• Maintain constant supervision of children and do not remove any
safety barriers until the pool is completely empty and stowed away.
• Refer to the list of barrier recommendations and guidelines as
described in CPSC Publication No.362.
• Assign an adult to be responsible for watching children in the pool.
Give this person a "water watcher" tag and ask that they wear it the
entire time they are in charge of supervising children in the pool. If
they need to leave for any reason, ask this person to pass the "water
watcher" tag and the supervision responsibility to another adult.
Prevent Young Children From Gaining Access to Pool:
• Remove pool ladders before leaving pool. Toddlers can climb ladder
and get into pool.
• Position furniture away from pool so that children cannot climb and
gain access to pool.
• When leaving pool, remove floats and toys from pool that might attract
a child.
Be Prepared to Respond to an Emergency:
• Keep a working phone and list of emergency numbers near pool.
• Become certified in cardiopulmonary resuscitation (CPR) so you can
respond to an emergency.
Diving Risk:
• Do not dive into the pool. Diving into shallow water can result in a
broken neck, paralysis, or death.
Electrocution Risk:
• Keep all electrical lines, radios, speakers and other electrical
appliances away from the pool.
• Do not place pool near or under overhead electrical lines.
Safety Barrier Guidelines for Residential Swimming Pool
Section I: Outdoor swimming pool
An outdoor swimming pool, including an in-ground, above ground, or
on-ground pool, hot tub, or spa, should be provided with a barrier which
complies with the following:
1. The top of the barrier should be at least 48 inches above grade
measured on the side of the barrier which faces away from the
swimming pool. The maximum vertical clearance between grade
and the bottom of the barrier should be 4 inches measured on the
side of the barrier which faces away from the swimming pool.
Where the top of the pool structure is above grade, such as an
WARNING WARNING
Electrocution Risk No Diving
You can break your neck
and be paralyzed!
above ground pool, the barrier may be at ground level, such as the
pool structure, or mounted on top of the pool structure. Where the
barrier is mounted on top of the pool structure, the maximum
vertical clearance between the top of the pool structure and the
bottom of the barrier should be 4 inches.
2. Openings in the barrier should not allow passage of a 4-inch
diameter sphere.
3. Solid barriers, which do not have openings, such as a masonry or
stone wall, should not contain indentations or protrusions except for
normal construction tolerances and tooled masonry joints.
4. Where the barrier is composed of horizontal and vertical members
and the distance between the tops of the horizontal members is
less than 45 inches, the horizontal members should be located on
the swimming pool side of the fence. Spacing between vertical
members should not exceed 1-3/4 inches in width. Where there are
decorative cutouts, spacing within the cutouts should not exceed
1-3/4 inches in width.
5. Where the barrier is composed of horizontal and vertical members
and the distance between the tops of the horizontal members is 45
inches or more, spacing between vertical members should not
exceed 4 inches. Where there are decorative cutouts, spacing
within the cutouts should not exceed 1-3/4 inches in width.
6. Maximum mesh size for chain link fences should not exceed 1-3/4
inch square unless the fence is provided with slats fastened at the
top or the bottom which reduce the openings to no more than 1-3/4
inches.
7. Where the barrier is composed of diagonal members, such as a
lattice fence, the maximum opening formed by the diagonal
members should be no more than 1-3/4 inches.
8. Access gates to the pool should comply with Section I, Paragraphs
1 through 7, and should be equipped to accommodate a locking
device. Pedestrian access gates should open outward, away from
the pool, and should be self-closing and have a self-latching
device. Gates other than pedestrian access gates should have a
self-latching device. Where the release mechanism of the
self-latching device is located less than 54 inches from the bottom
of the gate, (a) the release mechanism should be located on the
pool side of the gate at least 3 inches below the top of the gate and
(b) the gate and barrier should have no opening greater than 1/2
inch within18 inches of the release mechanism.
9. Where a wall of a dwelling serves as part of the barrier, one of the
following should apply:
(a) All doors with direct access to the pool through that wall should
be equipped with an alarm which produces an audible warning
when the door and its screen, if present, are opened. The alarm
should sound continuously for a minimum of 30 seconds within
7 seconds after the door is opened. Alarms should meet the
requirements of UL2017 General-Purpose Signaling Devices
and Systems, Section 77. The alarm should have a minimum
sound pressure rating of 85 dBA at 10 feet and the sound of the
alarm should be distinctive from other household sounds, such
as smoke alarms, telephones, and door bells. The alarm should
automatically reset under all conditions. The alarm should be
equipped with manual means, such as touchpads or switches,
to temporarily deactivate the alarm for a single opening of the
door from either direction. Such deactivation should last for no
more than 15 seconds. The deactivation touchpads or switches
should be located at least 54 inches above the threshold of the
door.
(b) The pool should be equipped with a power safety cover which
complies with ASTM F1346-91 listed below.
(c) Other means of protection, such as self-closing doors with
self-latching devices, are acceptable so long as the degree of
protection afforded is not less than the protection afforded by
(a) or (b) described above.
10. Where an above ground pool structure is used as a barrier or
where the barrier is mounted on top of the pool structure, and the
means of access is a ladder or steps, then (a) the ladder to the
pool or steps should be capable of being secured, locked or
removed to prevent access, or (b) the ladder or steps should be
surrounded by a barrier which meets Section I, Paragraphs 1
through 9. When the ladder or steps are secured, locked, or
removed, any opening created should not allow the passage of a
4-inch diameter sphere.
Section II: Barrier Locations
Barriers should be located so as to prohibit permanent structures,
equipment or similar objects from being used to climb the barriers.
1
