789/787B
ProcessMeter™
Users Manual
August 2002, Rev. 4, 1/17
© 2002-2017 Fluke Corporation. All rights reserved. Specifications are subject to change without notice.
All product names are trademarks of their respective companies.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ProcessMeter 787B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Fluke ProcessMeter 787B

Summary of Contents for Fluke ProcessMeter 787B

  • Page 1 Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176 - TestEquipmentDepot.com 789/787B ProcessMeter™ Users Manual August 2002, Rev. 4, 1/17 © 2002-2017 Fluke Corporation. All rights reserved. Specifications are subject to change without notice. All product names are trademarks of their respective companies.
  • Page 2 LIMITED WARRANTY AND LIMITATION OF LIABILITY This Fluke product will be free from defects in material and workmanship for three years from the date of purchase. This war- ranty does not cover fuses, disposable batteries, or damage from accident, neglect, misuse, alteration, contamination, or abnormal conditions of operation or handling.

  • Page 3: Table Of Contents

    Table of Contents Title Page Introduction ........................1 How to Contact Fluke ..................... 2 Safety Information ......................2 How to Get Started ......................6 Getting Acquainted with the Meter ................. 7 Measuring Electrical Parameters ..................18 Input Impedance ......................18 Ranges ........................
  • Page 4 789/787B Users Manual Power-Up Options ......................26 Loop Power Supply Mode (789 only) ................28 Battery Life ........................30 Maintenance ........................30 Calibration ......................... 31 Replacing the Batteries ..................... 31 Replacing a Fuse ...................... 33 If the Meter does not Work ..................34 Replacement Parts and Accessories ................

  • Page 5: Introduction

    ProcessMeter Introduction If the meter is damaged or something is missing, contact Warning the place of purchase immediately. Contact a Fluke Read “Safety Information” before using the distributor for information about DMM (digital multimeter) meter. accessories. To order replacement parts or spares, see Table 13 near the end of this manual.

  • Page 6: How To Contact Fluke

    789/787B Users Manual Safety Information A Warning identifies conditions and procedures that are dangerous to the user. A Caution identifies conditions and procedures that can cause damage to the Product or the equipment under test. International symbols used on the meter and in this manual are explained in Table 1.
  • Page 7 ProcessMeter™ Safety Information The battery door must be closed and locked Measure a known voltage first to make sure • • before you operate the Product. that the Product operates correctly. Replace the batteries when the low battery Use the correct terminals, function, and range •...
  • Page 8 789/787B Users Manual Keep fingers behind the finger guards on the Do not use test leads if they are damaged. • • probes. Examine the test leads for damaged insulation and measure a known voltage. Only use probes, test leads, and accessories •...
  • Page 9 ProcessMeter™ Safety Information Table 1. International Symbols Symbol Description Symbol Description WARNING. HAZARDOUS VOLTAGE. Risk   WARNING. RISK OF DANGER. of electric shock. Conforms to relevant South Korean EMC   Consult user documentation. Standards   Conforms to European Union directives Minimum fuse interrupt rating.

  • Page 10: How To Get Started

    789/787B Users Manual How to Get Started If familiar with the Fluke 80 Series DMM, read “Using the Current Output Functions,” review the tables and figures in Warning “Getting Acquainted with the Meter,” and begin using the To prevent possible electrical shock, fire, or meter.

  • Page 11: Getting Acquainted With The Meter

    ProcessMeter™ Getting Acquainted with the Meter Getting Acquainted with the Meter Table 2. 789/787B ProcessMeter To become familiar with the features and functions of the meter, study these tables: Table 3 describes the input/output jacks. • Table 4 describes the input functions of the first six •...
  • Page 12 789/787B Users Manual Table 3. Input/Output Jacks anw001f.eps Item Jack Measurement Functions Source Current Function Simulate Transmitter Function Input for current to 440 mA Output for dc current to 24 continuous. (1 A for up to mA. Output for loop power ...
  • Page 13 ProcessMeter™ Getting Acquainted with the Meter Table 4. Rotary Function Switch Positions for Measurements anw002f.eps Position Function(s) Pushbutton Actions Meter off  Default: Selects a MIN, MAX, or AVG action Measure ac V Selects a fixed range (hold 1 second for auto range) ...
  • Page 14 789/787B Users Manual Table 4. Rotary Function Switch Positions for Measurements (cont.) Position Function(s) Pushbutton Actions Default: Same as above Measure dc V  Frequency counter Default: Same as above (mV has only one range) Measure dc mV  Frequency counter Default: Measure Ω...
  • Page 15 ProcessMeter™ Getting Acquainted with the Meter Table 5. Rotary Function Switch Positions for mA Output anw008f.eps Position Default Function Pushbutton Actions % STEP X or W: Adjusts output up or down to the next 25 % step Test leads in SOURCE: COARSE X or W: Adjusts output up or down 0.1 mA OUTPUT...
  • Page 16 789/787B Users Manual Table 5. Rotary Function Switch Positions for mA Output (cont.) Position Default Function Pushbutton Actions Test leads in J (Blue) cycles through: SOURCE: Fast repeating 0 % -100 % - 0 % ramp (o on display) • Source repeating Slow repeating 0 % -100 % - 0 % ramp in 25 % steps (n on •...
  • Page 17 ProcessMeter™ Getting Acquainted with the Meter Table 6. Pushbuttons Pushbutton Function Set the backlight to low, high, and off  mA Output: Adjusts mA output to 0 % Span Check  value (4 mA or 0 mA)  mA Output: Sets mA output to 100 % ...
  • Page 18 789/787B Users Manual Table 6. Pushbuttons (cont.) Pushbutton Function Measuring: Toggles AutoHold, or in MIN MAX recording, suspends recording   mA Output: Adjusts output up 0.001 mA FINE FINE Measuring: Toggles between frequency counter and voltage measurement functions  mA Output: Adjusts output down 0.001 mA ...
  • Page 19 ProcessMeter™ Getting Acquainted with the Meter Table 7. Display anw004f.eps Element Meaning Shows the mA measured value or output level in %, in a 0-20 mA or 4-20 mA scale % (Percentage display)  (change scales with power-up option) Lights when mA output (source or simulate) is active OUTPUT ...
  • Page 20 789/787B Users Manual Table 7. Display (cont.) Meaning Element  Lights when dangerous voltage is detected  Lights when relative reading is on   Lights when the battery is low  Lights when the meter is transmitting or receiving over the IR port ...
  • Page 21 ProcessMeter™ Getting Acquainted with the Meter Table 7. Display (cont.) Meaning Element Range status indicators: Auto Range Auto Range - autoranging is on Manual Range Manual Range - the range is fixed  400100030 The number plus the unit and multiplier indicate the active range. One of these lights in mA ramping or step output (rotary function switch position mo np Ymo np):...

  • Page 22: Measuring Electrical Parameters

    789/787B Users Manual Measuring Electrical Parameters The meter normally selects the lowest range that will measure the applied input signal (Auto Range showing on The proper sequence for taking measurements is: the display). Press R to lock the range. Each time R is pressed, the meter selects the next higher range.

  • Page 23: Displaying Minimum, Maximum, And Average

    ProcessMeter™ Measuring Electrical Parameters Displaying Minimum, Maximum, and Average Using AutoHold MIN MAX recording stores the lowest and highest Note measurements, and maintains the average of all MIN MAX recording must be off to use AutoHold. measurements. ! Warning Press M to turn on MIN MAX recording. Readings are stored until the meter is turned off, switched to another To avoid possible electric shock, do not use measurement or source function, or MIN MAX is turned...

  • Page 24: Compensating For Test Lead Resistance

    789/787B Users Manual Compensating for Test Lead Resistance current in an externally powered current loop, or loop supply mode, where the meter powers an external device Use the relative reading feature (Q on the display) to set and measures the loop current. the present measurement as a relative zero.
  • Page 25 ProcessMeter™ Using the Current Output Functions PROCESSMETER 100% MIN MAX RANGE HOLD anw010f.eps Figure 1. Sourcing Current...

  • Page 26: Simulate Mode

    789/787B Users Manual Changing the Current Span Simulate Mode Simulate mode is so named because the meter simulates The meter’s current output span has two settings (with a current loop transmitter. Use simulate mode when an overrange to 24 mA): external dc voltage of 15 to 48 V is in series with the 4 mA = 0 %, 20 mA = 100 % (factory default) •...
  • Page 27 ProcessMeter™ Using the Current Output Functions dc V Power Supply PROCESSMETER +24V RANGE HOLD 100% MIN MAX anw011f.eps Figure 2. Simulating a Transmitter...

  • Page 28: Producing A Steady Ma Output

    789/787B Users Manual Table 8. mA Output Adjust Pushbuttons Producing a Steady mA Output When the rotary function switch is in the OUTPUT mA [ Pushbutton Adjustment position, and the OUTPUT jacks are connected to an Adjusts up 0.1 mA appropriate load, the meter produces a steady mA dc output.

  • Page 29: Manually Stepping The Ma Output

    ProcessMeter™ Using the Current Output Functions Manually Stepping the mA Output Table 9. mA Stepping Pushbuttons Pushbutton Adjustment When the rotary function switch is in the OUTPUT mA [ position, and the OUTPUT jacks are connected to an Adjusts up to the next higher 25 % appropriate load, the meter produces a steady mA dc step output.

  • Page 30: Auto Ramping The Ma Output

    789/787B Users Manual Auto Ramping the mA Output The ramp times are not adjustable. Press J (Blue) to cycle through the four waveforms. Auto ramping gives the ability to continuously apply a varying current stimulus from the meter to a transmitter, Note while hands remain free to test the response of the At any time during auto ramping, the ramp can...
  • Page 31 ProcessMeter™ Power-Up Options Table 11. Power-Up Options Switch Option Button Default Display Action Taken Position Toggles between 0-20 mA and  -  or  -  Current Span Retains setting 4-20 mA range Enables/Disables the auto-off   /   Backlight Timeout Retains setting on backlight after 2 minutes...

  • Page 32: Loop Power Supply Mode (789 Only)

    789/787B Users Manual Loop Power Supply Mode (789 only) The Loop Power Supply Mode can be used for powering up a process instrument (transmitter). While in Loop Power Mode, the meter acts like a battery. The process instrument regulates the current. At the same time, the meter measures the current that the process instrument is drawing.
  • Page 33 ProcessMeter™ Loop Power Supply Mode (789 only) PROCESSMETER 100% MIN MAX RANGE HOLD TEST DC PWR – + – – anw009f.eps Figure 4. Connections for Supplying Loop Power...

  • Page 34: Battery Life

    For maintenance procedures not described in this manual, replace the battery as soon as the battery contact a Fluke Service Center. indicator (b) appears. Periodically wipe the case with a damp cloth and Table 12 shows typical alkaline battery life. To preserve detergent;...

  • Page 35: Calibration

    Lift off the battery door. Calibrate the meter once a year to ensure that it performs Remove the meter's batteries. according to its specifications. Contact a Fluke Service Center for instructions. Replace with four new AA alkaline batteries. Replacing the Batteries Reinstall the battery door and tighten screws.
  • Page 36 789/787B Users Manual anw037.eps Figure 5. Replacing the Batteries and Fuses...

  • Page 37: Replacing A Fuse

    To avoid personal injury or damage to the meter, use only the specified replacement If a fuse is blown, replace it as follows. Refer to Figure 6 fuse, 440 mA 1000 V fast-blow, Fluke PN as necessary: 943121. Remove the test leads from the meter and turn the Both current input jacks are fused with separate 440 mA meter OFF.

  • Page 38: If The Meter Does Not Work

    • correct jacks and rotary function switch position. Note If the meter still does not work, contact a Fluke Service When servicing the meter, use only the Center. If the meter is under warranty, it will be repaired replacement parts specified here.
  • Page 39 ProcessMeter™ Replacement Parts and Accessories anw038.eps Figure 6. Replacement Parts...
  • Page 40 789/787B Users Manual Table 13. Replacement Parts Fluke PN Item Fluke PN Description Quantity for 787B Number for 789 Knob Assembly with o-ring 658440 4772670  Decal, Top Case 1623923 4772201  Keypad 1622951  Top Shield 4772681  Top Shield Contact 674853 ...
  • Page 41 ProcessMeter™ Replacement Parts and Accessories Table 13. Replacement Parts (cont.) Item Fluke PN Fluke PN Description Quantity Number for 789 for 787B Bottom Insulator 4811256  Bottom Shield 1675171  Shock Absorber 878983  IR Lens 658697  Bottom Case...

  • Page 42: Specifications

    789/787B Users Manual Specifications The standard specification interval is 1 year. All specifications apply from +18 °C to +28 °C unless Note stated otherwise. “Counts” refers to the number of increments or decrements of the least significant digit. All specifications assume a 5-minute warm-up period. DC Volts Measurement Range (V dc) Resolution...
  • Page 43 ProcessMeter™ Specifications DC Millivolts Measurement Range (mV dc) Resolution Accuracy, ±(% of Reading + Counts) 400.0 0.1 mV 0.1 % + 2 AC Volts Measurement Accuracy, ±(% of Reading + Counts) Range (ac) Resolution 50 Hz to 60 Hz 45 Hz to 200 Hz 200 Hz to 500 Hz 400.0 mV 0.1 mV...
  • Page 44 789/787B Users Manual AC Current Measurement Range Typical Burden Resolution Accuracy, ±(% of Reading + Counts) 45 Hz to 2 kHz Voltage 1.000 A (Note) 0.001 A 1 % + 2 1.5 V/A Note: 440 mA continuous, 1 A 30 seconds maximum Specifications are valid from 5 % to 100 % of amplitude range.
  • Page 45 ProcessMeter™ Specifications Ohms Measurement Range Resolution Measurement Current Accuracy, ±(% of Reading + Counts) 400.0 Ω 0.1 Ω 310 μA 0.2 % + 2 4.000 kΩ 0.001 kΩ 31 μA 0.2 % + 1 40.00 kΩ 0.01 kΩ 2.5 μA 0.2 % + 1 400.0 kΩ...
  • Page 46 789/787B Users Manual Frequency Counter Accuracy Range Resolution Accuracy, ±(% of Reading + Counts) 199.99 Hz 0.01 Hz 0.005 % + 1 1999.9 Hz 0.1 Hz 0.005 % + 1 19.999 kHz 0.001 kHz 0.005 % + 1 Display updates 3 times/second at > 10 Hz Frequency Counter Sensitivity Minimum Sensitivity (rms Sinewave) 5 Hz to 5 kHz*...
  • Page 47 ProcessMeter™ Specifications Diode Test and Continuity Test Diode test indication ........... Displays voltage drop across device, 2.0 V full scale. Nominal test current 0.3 mA at 0.6 V. Accuracy ±(2 % + 1 count). Continuity test indication ........Continuous audible tone for test resistance <100 Ω Open circuit voltage ..........
  • Page 48 789/787B Users Manual General Specifications Maximum Voltage between any Terminal and Earth Ground ......1000 V Fuse Protection for mA inputs ............... 0.44 A, 1000 V, IR 10 kA Power Battery Type ............IEC LR6 (AA Alkaline) Quantity ............... 4 Temperature Operating ............
  • Page 49 ProcessMeter™ Specifications Electromagnetic Compatibility (EMC) ....Accuracy for all ProcessMeter functions is not specified in RF field >3 V/m International ............IEC 61326-1: Portable Electromagnetic Environment; IEC 61326-2-2 CISPR 11: Group 1, Class A Group 1: Equipment has intentionally generated and/or uses conductively-coupled radio frequency energy that is necessary for the internal function of the equipment itself.
  • Page 50 789/787B Users Manual Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176 - TestEquipmentDepot.com...
