Washing Machine
•
Congratulations on your new Samsung washing machine. This manual contains important information on the
installation, use, and care of your appliance. Read this manual thoroughly before using the washing machine to
ensure that you know how to safely and efficiently operate the features and functions that your new washing
machine offers.
•
For detailed instructions on installation and cleaning of the washing machine, and ecodesign information
(according to (EU)2019/2023), visit the Samsung website (http://www.samsung.com), go to Support > Support
home, and then enter the model name. Or, download and install the SmartThings app on your mobile device, and
then open HomeCare Wizard in SmartThings for tips and guides.
•
To check the product's model name, see the label enclosed with the product or attached to the product.
What's included
01
02
03
04
05
06
07
08
Spanner
Bolt caps
NOTE
•
Spanner: For removing the shipping bolts and levelling the washing machine.
•
Bolt caps: For covering the holes after removing the shipping bolts. The provided number of bolt caps (3 to 6)
depends on the model.
•
Hose guide: For hanging the drain hose in the drainpipe or wash-basin.
•
Cold/Hot water hose: For supplying water to the washing machine. (Hot water hoses is for applicable models only.)
•
Liquid detergent guide: Insert it in the detergent compartment to use liquid detergent. (applicable models only)
B-PJT_WW5000B-MD_SG_DC68-04409H-01_EN.indd 1
09
10
11
12
Hose guide
Cold water
hose
Model: WW1*B*******
01 Release lever
02 Detergent drawer
03 Control panel
04 Door
05 Drum
06 Debris filter
07 Emergency drain tube
08 Filter cover
09 Worktop
10 Power plug
11
Drain hose
12 Levelling feet
Hot water
Liquid detergent
hose
guide
Check valve (only
supplied to some
models)
