By
OPERATING
INSTRUCTIONS
MODEL 123
READ CAREFULLY
BEFORE OPERATING YOUR
MACHINE
A Safety Note:
Your good manufacturing practices should insure that a written safety program is in place, which
includes the assessment of all processes that take place in house, for potential risks.
The employer response to this assessment is to establish specific instructions for the safe use of all
machines, safe use of certain chemicals, etc. in your work place.
For instance, any user of electrical machinery, SLICE® included, must be instructed that never,
under any circumstances, should a machine be left on while attempting to clear a jam, if it should
occur.
This written rule, along with other directives, should be translated into either a training document
that is signed or work instruction that is also signed and dated by all operators and that ideally
remains with the equipment as a reminder of safe operation.
SLICE® Cutting Machine Operating Instructions
Copyright 1998-2016 page 1 of 35
Advertisement
Table of Contents
Related Manuals for AMTI Products SLICE 123
Summary of Contents for AMTI Products SLICE 123
- Page 1 OPERATING INSTRUCTIONS MODEL 123 READ CAREFULLY BEFORE OPERATING YOUR MACHINE A Safety Note: Your good manufacturing practices should insure that a written safety program is in place, which includes the assessment of all processes that take place in house, for potential risks. The employer response to this assessment is to establish specific instructions for the safe use of all machines, safe use of certain chemicals, etc.
- Page 2 Published by: AMTI PRODUCTS Phone 847.588.7090 Email info@amtiproducts.com Website www.amtiproducts.com The reproduction of these instructions or parts thereof, in whatever form, is prohibited without the express, written permission of the publisher. AMTI reserves the right to make technical changes in the system depicted and indicated in these instructions if such changes are necessary to improve the machine.
-
Page 3: Table Of Contents
Index 1.0 Product Description....................page 4 2.0 Safety ........................page 6 3.0 The Operating Instructions..................page 7 4.0 Machine Overview ....................page 10 5.0 Set Up........................page 13 6.0 Cut Material To Length Without Using A Program ..........page 14 7.0 Cut Material To Length Using A Program (A Preprogrammed Batch).... -
Page 4: Product Description
1.1 Product Description The SLICE® 123 is an automatic cutting machine intended to cut various materials to length within the scope of the technical data. It is for industrial use. 1.2 System Description 1. Die size: 3” X 1/4” opening 2. - Page 5 1.3 FUNCTION AND OPERATION 1. Operates as other models in the SLICE® series 1.4 PERFORMANCE SPECIFICATIONS 1. Cuts up to 12 gauge standard wire and varieties of hollow tubing that fits within its input aperture of 3/16” height by 1” width 2.
-
Page 6: Safety
2.0 Safety Always observe the following safety rules: 1. These sets of documentation are integral parts of the machines and devices they were written for and must be heeded. 2. Always turn off power and disconnect the air lines before investigating jams or internal issues. -
Page 7: The Operating Instructions
Be careful not to mislay these sets of documentation when unpacking and setting up accessories. The operating instructions are an integral part of the SLICE 123 Keep them within reach so you have access to the information you need at all times. - Page 8 3.2 Machine Identification On the back of the machine you will find a nameplate with the following information: Company Contact Machine Type Machine Serial Number Voltage Version Power Input SLICE® Cutting Machine Operating Instructions Copyright 1998-2016 page 8 of 35...
- Page 9 3.3 Personal Qualifications And Training 3.3.1 Personnel Qualifications Machine Operator The machine operator must be sufficiently familiar with the machine to be able to operate it and its accessories and peripheral devices in production on his/her own without difficulty. This requires that the operator be educated in the technology involved and be knowledgeable of the software for operating the machine.
-
Page 10: Machine Overview
4.0 Machine Overview (front) 1. Function Buttons 2. Keypad 3. LCD Readout SLICE® Cutting Machine Operating Instructions Copyright 1998-2016 page 10 of 35... - Page 11 4. 1 Machine Overview (back) 1. Fuses 2. Power Cord Receptacle 3. On/Off Switch 4. Nameplate SLICE® Cutting Machine Operating Instructions Copyright 1998-2016 page 11 of 35...
- Page 12 4.2 Operations Control Unit 1. “PROGRAM” - This button is used to pull up an existing program or create new program. Press this button twice then press “ENTER” to reveal machine menu on LED readout. 2. “LOAD” - This button is used to load/index new material. 3.
-
Page 13: Set Up
5.1 Set Up Place your SLICE® machine on a clean, flat, sturdy work surface. Plug machine into a standard 110V outlet, unless your machine is designed for 220V; then act accordingly. Position the machine’s front edge even with the edge of the worktable on which it’s placed. Turn on the switch at the back of the unit. -
Page 14: Cut Material To Length Without Using A Program
2. Simply push the material into the opening in the back of the machine. Hold it firmly in place and push “LOAD”. “LOAD” With larger diameter wires and tubing it may be necessary to press firmly on the material. Make an angle cut at the end of these materials to facilitate easy loading. - Page 15 2. After entering the length desired, press “ENTER”. The unit will request the number of pieces to be cut (Count=). Enter the number of pieces required and press “ENTER”. Verify that what you have entered is correct. The material exits from the bottom portion of the front of the machine, so make certain that the machine sits on the edge of table to avoid jams.
-
Page 16: Cut Material To Length Using A Program (A Preprogrammed Batch)
7.0 Cut Product To Length Using A Program (A Preprogrammed Batch) Enter a program by pressing “PROGRAM”. Enter the desired program number (1-99). Press “ENTER”, then hit “RUN” to activate cutting cycle. “PROGRAM” “ENTER” “RUN” Note: when a program is on the LCD screen, it may be run repeatedly by simply pushing “RUN”. -
Page 17: How To Run An Existing Program
8.0 How To Run An Existing Program Press “PROGRAM”. Enter the program number (1-99) followed by “ENTER”. The data stored in that program will be displayed. If this is the correct program, accept it by pressing “ENTER” once more. Place a container under the chute and press “RUN” . If you choose a number that has already been programmed, the existing program’s length and count will be displayed. -
Page 18: Batch Sequence Pause Feature
10.0 Batch Sequence Pause Feature Since a batch sequence program may contain as many as ten (10) different batches, the machine will stop in between each batch. If the feature is not selected, the machine will run out all batches into the same container. - Page 19 Press the appropriate numerical key to transfer to the desired programming. Or if you do not wish to make a change, once you have pressed one of these numbers, simply press the “CLEAR” button. 11.1 Calibration (displays as no. 1) The unit comes calibrated from the factory.
- Page 20 11.1 Calibration Continued The issue of calibration is a complex one. Different insulating materials may have different slip rates. As such, a machine calibrated to run one type of wire and insulation may be calibrated for a different type of wire and insulation. Heat shrink tubing, and various types of flexible tubing are susceptible to stretching.
- Page 21 11.7 Exit (displays as no. 6) Exit the programming mode without changes by pressing this. 11.8 Notes Of Interest The machine has also been calibrated for length using standard flat ribbon cable. Some wear will occur overtime with the standard poly wheels and you may find it advisable to recalibrate the machine from time to time, depending on its use.
-
Page 22: Contact Information
12.0 Contact Information SLICE® was specifically designed for easy set-up and use. However, if you experience any difficulties with your machine that you cannot resolve using the information we have sent you, please contact us for assistance. If you have any suggestions for improvement or ease of operation, please contact our Service Department with your comments/suggestions. -
Page 23: Maintenance Section
13.0 Routine Maintenance Notes For The Slice Machines. Important! Be Sure To Turn Off And Unplug The Slice Unit Before Performing Any Maintenance or Inspections! Note: The Preventive Maintenance Program is based solely on the extent of use of the SLICE® machine. Typically, item 2 should be done on a weekly basis, however, if the SLICE®... - Page 24 13.1 Encoder Mounting and Assembly Maintenance SLICE® Cutting Machine Operating Instructions Copyright 1998-2016 page 24 of 35...
-
Page 25: Electrical Drawings
14.0 SLICE® 123 Wire Diagram SLICE® Cutting Machine Operating Instructions Copyright 1998-2016 page 25 of 35... - Page 26 14.1 SLICE® 123 Control Board - SA4116 SLICE® Cutting Machine Operating Instructions Copyright 1998-2016 page 26 of 35...
- Page 27 14.2 SLICE® 123 Power Board - SA3405 SLICE® Cutting Machine Operating Instructions Copyright 1998-2016 page 27 of 35...
-
Page 28: Spare Parts
SLICE 123 REPLACEMENT 15.0 PARTS QTY. ITEM DESCRIPTION AMTI PART NUMBER SPRINGS-IDLER SUP3583 ROLLER BEARING SUP1598 BLADE MFB4537 BLADE FLAG MFB3053 MFB3054 DIE ASSEMBLY SA3074 BALL PLUNGER SUP1986 STEEL IDLER WHEEL MFB3058 POLYURETHANE IDLER WHEEL MFB3312 STEEL DRIVE WHEEL MFB2050... -
Page 29: Trouble Shooting
16.0 SLICE® Trouble-Shooting Guide IMPORTANT Before opening up the SLICE® machine for inspection or for repairs/component replacement, be sure to turn the machine off, unplug the power cord from the ECONO- SLICE® machine completely! 16.1 Product Feeds But Does Not Cut A. - Page 30 4. Spin the wheels on the unit and on the scope the 2 lines should resemble the following: 5. If the lines do not resemble this the encoder is bad. 16.3 LCD Displays “Flag Not Set” A. Check Flag and Sensor alignment (see below). Side Elevation B.
- Page 31 C. Check Optic Sensor making sure that component is free from debris. D. Check functionality of optic sensor. 16.6 LCD Displays “Blade Not Moving” A. Check fuses. B. Check connections. C. Check for debris in both Blade and Die. 16.7 LCD displays “Black Squares”, No Text A.
- Page 32 16.9 Machine Not Able To Pull Material Through Cutter A. Check for jam or material obstructions in opening. B. Is the material feeding freely? Undue amount of tension on material? Check set C. Are you using a material appropriate for this model machine? 16.10 Machine Freezes Up During Load Cycle And is Sluggish A.
- Page 33 16.15 Blade Jams A. Is adhesive product being cut? B. Are Blade and Die routinely cleaned? C. Check for material stuck in die. D. Check if Ball Plunger(s) are too tight or damaged. 16.16 Solenoids Not Firing A. Check connections. B.
- Page 34 - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. Industrial Control Equipment 21 EM AMTI PRODUCTS © 1998-2016 Patents Pending SLICE® Cutting Machine Operating Instructions Copyright 1998-2016 page 34 of 35...
-
Page 35: Ce Declaration Of Conformity
SLICE® Cutting Machine Operating Instructions Copyright 1998-2016 page 35 of 35... - Page 36 SLICE® Cutting Machine Operating Instructions Copyright 1998-2016 page 36 of 35...
