135 QUICK S TAR T GUIDE
*SAFETY: ALWAYS TURN OFF POWER AND DISCONNECT THE AIR LINES BEFORE
INVESTIGATING JAMS OR INTERNALS ISSUES. NEVER PLACE FINGERS, HANDS,
OR TOOLS INTO THE MACHINE WHILE IT IS PLUGGED IN OR AIR CONNECTED.
1. CONNECT AIRLINE, SET AT 80 PSI.
3. LOAD THE REEL SO THAT THE MATERIAL
DE-REELS FROM THE BACK AND GOES
OVER THE TOP OF THE SPRING-LOADED
TENSIONER. MINIMUM/NO TENSION AT ALL
SHOULD BE USED FOR FLEXIBLE TUBING
THAT WILL STRETCH.
5. TO LOAD MATERIAL, PRESS "LOAD" BUTTON.
MATERIAL WILL INDEX AND COMPLETE ONE CUT
CYCLE.
2. TURN ON SWITCH LOC. IN REAR OF
MACHINE.
4. ADJUST TOP ROLLER GUIDE WITH
MATERIAL INSERTED. MATERIAL
MUST BE CENTERED.
6. TO RUN MATERIAL, PRESS "RUN" BUTTON.
Advertisement
Table of Contents
Related Manuals for AMTI Products SLICE 135
Summary of Contents for AMTI Products SLICE 135
- Page 1 135 QUICK S TAR T GUIDE *SAFETY: ALWAYS TURN OFF POWER AND DISCONNECT THE AIR LINES BEFORE INVESTIGATING JAMS OR INTERNALS ISSUES. NEVER PLACE FINGERS, HANDS, OR TOOLS INTO THE MACHINE WHILE IT IS PLUGGED IN OR AIR CONNECTED. 2. TURN ON SWITCH LOC. IN REAR OF 1.
- Page 2 7. LCD WILL SHOW “LENGTH”, ENTER LENGTH. 8. THEN PRESS “ENTER” BUTTON. 9. LCD WILL SHOW “COUNT” ENTER QTY. THEN 10. TO RUN, PRESS “RUN” KEY. MATERIAL WILL PRESS “ENTER” KEY (SEE PIC 8). THEN BEGIN DESIRED MEASURING AND CUTTING PROCESS.
