OPERATING
INSTRUCTIONS
MODEL 135
READ CAREFULLY
BEFORE OPERATING YOUR
MACHINE
A Safety Note:
Your good manufacturing practices should insure that a written safety program is in place, which
includes the assessment of all processes that take place in house, for potential risks.
The employer response to this assessment is to establish specific instructions for the safe use of all
machines, safe use of certain chemicals, etc. in your work place.
For instance, any user of electrical machinery, SLICE® included, must be instructed that never,
under any circumstances, should a machine be left on while attempting to clear a jam , if it should
occur.
This written rule, along with other directives, should be translated into either a training document
that is signed or work instruction that is also signed and dated by all operators and that ideally
remains with the equipment as a reminder of safe operation.
SLICE® Cutting Machine Operating Instructions
Copyright 1998-2016 page 1 of 35
R 3.1.19
Advertisement
Table of Contents
Related Manuals for AMTI Products SLICE 135
Summary of Contents for AMTI Products SLICE 135
- Page 1 OPERATING INSTRUCTIONS MODEL 135 READ CAREFULLY BEFORE OPERATING YOUR MACHINE A Safety Note: Your good manufacturing practices should insure that a written safety program is in place, which includes the assessment of all processes that take place in house, for potential risks. The employer response to this assessment is to establish specific instructions for the safe use of all machines, safe use of certain chemicals, etc.
- Page 2 Published by: AMTI PRODUCTS Phone 847.588.7090 Email info@amtiproducts.com Website www.amtiproducts.com The reproduction of these instructions or parts thereof, in whatever form, is prohibited without the express, written permission of the publisher. AMTI reserves the right to make technical changes in the system depicted and indicated in these instructions if such changes are necessary to improve the machine.
-
Page 3: Table Of Contents
Index 1.0 Product Description ....................page 4 2.0 Safety ........................page 6 3.0 The Operating Instructions ..................page 7 4.0 Machine Overview ....................page 10 5.0 Set Up ........................page 13 6.0 Cut Material To Length Without Using A Program ..........page 15 7.0 Cut Material To Length Using A Program (A Preprogrammed Batch) .... -
Page 4: Product Description
1.0 Product Description The SLICE® 135 is an automatic cutting machine intended to cut various materials to length within the scope of the technical data. It is for industrial use. 1.1 System Description 1. Die size: 1/4” X 3” opening 2. - Page 5 1.2 FUNCTION AND OPERATION 1. Operates as other models in the SLICE® series. 2. Cutting blade force supplied by air cylinder, yielding a 360 pound cutting force. 1.3 PERFORMANCE SPECIFICATIONS 1. Cuts up to 12 gauge standard wire and varieties of hollow tubing that fits within its input aperture of 1/4”...
-
Page 6: Safety
2.0 Safety Always observe the following safety rules: 1. These sets of documentation are integral parts of the machines and devices they were written for and must be heeded. 2. Always turn off power and disconnect the air lines before investigating jams or internal issues. -
Page 7: The Operating Instructions
3.0 The Operating Instructions These operating instructions are valid for the SLICE 135 and are available in English and Spanish. Other languages are available upon request. The instructions contain complete information on the controls, handling, maintenance, and setting procedures as well as all technical data. They also include a list of accessories. - Page 8 3.1 Machine Identification On the back of the machine you will find a nameplate with the following information: Company Contact Machine Type Machine Serial Number Voltage Version Power Input SLICE® Cutting Machine Operating Instructions Copyright 1998-2016 page 4 of 35 R 3.1.19...
- Page 9 3.2 Personal Qualifications And Training 3.2.1 Personnel Qualifications Machine Operator The machine operator must be sufficiently familiar with the machine to be able to operate it and its accessories and peripheral devices in production on his/her own without difficulty. This requires that the operator be educated in the technology involved and be knowledgeable of the software for operating the machine.
-
Page 10: Machine Overview
4.0 Machine Overview (front) 1. Reel Bar / Locking Collar 2. Tensioner Bar 3. Triple Roller Guide 4. Function Buttons 5. Keypad 6. LCD Readout SLICE® Operating Instructions-SUP4300-R71113 Copyright 1998-2013 page 10 of 44... - Page 11 4. 1 Machine Overview (back) 1. Fuses 2. Power Cord Receptacle 3. On/Off Switch 4. Nameplate SLICE® Operating Instructions-SUP4300-R71113 Copyright 1998-2013 page 11 of 44...
- Page 12 4.2 Operations Control Unit 1. “PROGRAM” - This button is used to pull up an existing program or create a new program. Press this button twice then press “ENTER” to reveal machine menu on LED readout. 2. “LOAD” - This button is used to load/index new material. 3.
-
Page 13: Set Up
5.0 Set Up Place your SLICE® machine on a clean, flat, sturdy work surface. Plug machine into a standard 110V outlet, unless your machine is designed for 220V; then act accordingly. Position the machine’s front edge even with the edge of the worktable on which it’s placed. - Page 14 5.1 Load The Product: Load the product you’re cutting by centering the spool on the reel-mounting bar. (See exploded view drawing if you need to familiarize yourself with the terms used.) Tensioner Spring Reel Mounting Bar Tensioner Bar 5.2 Loading Instructions: 1.
-
Page 15: Cut Material To Length Without Using A Program
3. Make sure the felt disc pads are placed on each side of the wire reel. 4. Adjust the triple roller guide to fit the material and then simply push the material into the opening in the top of the machine. Hold it firmly in place and push “LOAD”. “LOAD”... - Page 16 2. After entering the length desired, press “ENTER”. The unit will request the number of pieces to be cut (Count=). Enter the number of pieces required and press “ENTER”. Verify that what you have entered is correct. The material exits from the bottom portion of the front of the machine, so make certain that the machine sits on the edge of the table to avoid jams.
-
Page 17: Cut Material To Length Using A Program (A Preprogrammed Batch)
7.0 Cut Product To Length Using A Program (A Preprogrammed Batch) Enter a program by pressing “PROGRAM”. Enter the desired program number (1-99). Press “ENTER” then hit “RUN” to activate cutting cycle. “PROGRAM” “ENTER” “RUN” Note: when a program is on the LCD screen, it may be run repeatedly by simply pushing “RUN”. -
Page 18: How To Run An Existing Program
8.0 How To Run An Existing Program Press “PROGRAM”. Enter the program number (1-99) followed by “ENTER”. The data stored in that program will be displayed. If this is the correct program, accept it by pressing “ENTER” once more. Place a container under the chute and press “RUN” . If you choose a number that has already been programmed: the existing program’s length and count will be displayed. -
Page 19: Batch Sequence Pause Feature
10.0 Batch Sequence Pause Feature Since a batch sequence program may contain as many as ten (10) different batches, the machine will stop in between each batch. If the feature is not selected, the machine will run out all batches into the same container. - Page 20 Press the appropriate numerical key to transfer to the desired programming. Or if you do not wish to make a change, once you have pressed one of these numbers, simply press the “CLEAR” button. 11.1 Calibration (displays as no. 1) The unit comes calibrated from the factory.
- Page 21 11.1 Calibration Continued The issue of calibration is a complex one. Different insulating materials may have different slip rates. As such, a machine calibrated to run one type of wire and insulation may be calibrated for a different type of wire and insulation. Heat shrink tubing and various types of flexible tubing are susceptible to stretching.
- Page 22 11.6 No Wire Stop (displays as no. 5) The machine uses conduction between the stainless steel drive wheel and the stainless steel idler wheel to establish that there is no longer any material to cut. If the wheels are in contact with each other, the machine rightly assumes that there is nothing to cut and shuts down.
- Page 23 11.9 Notes Of Interest The machine has also been calibrated for length using standard flat ribbon cable. Some wear will occur overtime with the standard poly wheels and you may find it advisable to recalibrate the machine from time to time depending on its use. When calibrating the machine please run at least 25 pieces of your material at a determined length and run several lengths from 4”...
-
Page 24: Contact Information
12.0 Contact Information SLICE® was specifically designed for easy set-up and use. However, if you experience any difficulties with your machine that you cannot resolve using the information we have sent you, please contact us for assistance. If you have any suggestions for improvement or ease of operation, please contact our Engineering Department with your comments/suggestions. - Page 25 13.0 Routine Maintenance Notes For The Slice Machines. Important! Be Sure To Turn Off And Unplug Along With Disconnecting The Air Line From The Slice Unit Before Performing Any Maintenance or Inspections! Note: The Preventive Maintenance Program is based solely on the extent of use of the SLICE® machine.
-
Page 26: Maintenance Section
13.1 Maintenance Section Continued 4. Periodically it is wise to remove the cutting die and blade to be cleaned and oiled. Use only light weight high speed oil (such as 3 in 1 oil). Remove the front cover by removing the four screws that attach it to the frame. SLICE®... - Page 27 13.1 Maintenance Instructions For Replacing or Cleaning Blade Assembly SLICE® 135 1. Unplug unit. Disconnect the air line. 2. Using a 3/16” allen key remove [4] screws holding top cover on unit. 3. Unplug all connectors going to the circuit board in the top housing and remove top housing.
- Page 28 13.2 Encoder Mounting and Assembly Maintenance SLICE® Operating Instructions-SUP4300-R71113 Copyright 1998-2013 page 28 of 44...
-
Page 29: Expolded Assembly View
14.0 SLICE® 135 FIGURE 1: FA3887 FINAL ASSEMBLY EXPLODED SA4116 SA2191 SLICE® Operating Instructions-SUP4300-R71113 Copyright 1998-2013 page 29 of 44... - Page 30 14.1 SLICE® 135 FIGURE 2: SA3074 DIE ASSEMBLY EXPLODED MFB3488 SLICE® Operating Instructions-SUP4300-R71113 Copyright 1998-2013 page 30 of 44...
- Page 31 14.2 SLICE® 135 FIGURE 3: SA3082 CYLINDER PLATE ASSEMBLY EXPLODED QUICK RELEASE PIN SUP 3985 *See Air Schematic SLICE® Operating Instructions-SUP4300-R71113 Copyright 1998-2013 page 31 of 44...
- Page 32 14.3 SLICE® 135 FIGURE 4: SA3083 CUTTER HOUSING ASSEMBLY EXPLODED SA4119 MFB2050 MFB3245 *See Air Schematic SLICE® Operating Instructions-SUP4300-R71113 Copyright 1998-2013 page 32 of 44...
- Page 33 1. USE 3.15 AMP FUSE @ 250 VOLTS FOR 115 VAC OPERATION DIVISION OF 7 MILE SOLUTIONS 2. USE 2.0 AMP FUSE @ 250 VOLTS FOR 230 VAC OPERATION TITLE: SLICE 135 WIRING DIAGRAM SCALE: DRAWN BY: CHECKED BY: APP'D BY: DATE: REV.
- Page 34 14.5 SLICE® 135 Air Schematic SLICE® Operating Instructions-SUP4300-R71113 Copyright 1998-2013 page 34 of 44...
- Page 35 14.6 SLICE® 135 Control Board - SA4116 SLICE® Operating Instructions-SUP4300-R71113 Copyright 1998-2013 page 35 of 44...
- Page 37 MFB3245 SA2191 SA4116 SA4119 SLICE® Operating Instructions-SUP4300-R71113 Copyright 1998-2013 page 37 of 44...
-
Page 38: Trouble Shooting
15.0 SLICE® Trouble-Shooting Guide IMPORTANT Before opening up the SLICE® machine for inspection or for repairs/component replacement, be sure to turn the machine off, unplug the power cord and air from the SLICE® machine! 15.1 Product Feeds But Does Not Cut A. - Page 39 4. Spin the wheels on the unit and on the scope the 2 lines should resemble the following: SIDE VIEW BLADE RETRACTED 5. If the lines do not resemble this the encoder is bad. flag sensor SIDE VIEW blade 15.4 LCD Displays “Flag Not Set” A.
- Page 40 If you do not get 5V the sensor is bad. A.B. 15.5 LCD Displays “Flag Not Set” A. Check Flag and Sensor alignment. B. Check connection between sensor and board are intact. C. Check Optic Sensor making sure that component is free from debris. D.
- Page 41 15.9 Machine Not Able To Pull Material Through Cutter A. Check for jam or material obstructions in opening. B. Is the material feeding freely? Undue amount of tension on material? Check set up. C. Are you using a material appropriate for this model machine? 15.10 Machine Freezes Up During Load Cycle And is Sluggish A.
- Page 42 15.15 Blade Jams A. Is adhesive product being cut? B. Are Blade and Die routinely cleaned? C. Check for material stuck in die. D. Check if Ball Plunger(s) are too tight or damaged. E. Check Air Cylinder. 15.16 Solenoids Not Firing A.
-
Page 43: Fcc Statement
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. Industrial Control Equipment 21 EM AMTI PRODUCTS © 1998-2016 Patents Pending SLICE® Cutting Machine Operating Instructions Copyright 1998-2016 page 5 of 35... -
Page 44: Ce Declaration Of Conformity
SLICE® Cutting Machine Operating Instructions Copyright 1998-2016 page 6 of 35 R 3.1.19...
