141 QUICK S TAR T GUIDE
*SAFETY: ALWAYS TURN OFF POWER AND DISCONNECT THE AIR LINES BEFORE
INVESTIGATING JAMS OR INTERNALS ISSUES. NEVER PLACE FINGERS, HANDS,
OR TOOLS INTO THE MACHINE WHILE IT IS PLUGGED IN OR AIR CONNECTED.
1. CONNECT AIRLINE, SET AT 80 PSI.
3. ADJUST TOP INPUT GUIDE (141) WITH
MATERIAL INSERTED. MATERIAL
MUST BE CENTERED.
*BE SURE TO INSTALL TOP AND BOTTOM
CLEAR PLASTIC SAFETY SHIELDS.
5. BOTTOM GUIDE
BOTTOM SAFETY SHIELD
7. SLICE KEYPAD SAFETY SHIELD TO LEFT.
2. TURN ON SWITCH LOC. IN REAR OF
MACHINE.
4. CLOSE WHEELS W/ADJUSTABLE HAND CRANK.
TOO LOOSE: MATERIAL WILL NOT BE INDEXED
TOP SAFETY SHIELD
AND SLIP. TOO TIGHT: MATERIAL MAY BE
CRUSHED. MAKE NOTE OF WHEEL POSITION
INDICATOR FOR FUTURE REF.
6. ADJUST BOTTOM GUIDE WHEEL APPROX.
¼" ON EACH SIDE OF MATERIAL
8. HIT "LOAD" KEY AND SLIDE KEYPAD
SAFETY SHIELD BACK TO RIGHT.
Advertisement
Table of Contents
Related Manuals for AMTI Products Slice 141
Summary of Contents for AMTI Products Slice 141
- Page 1 141 QUICK S TAR T GUIDE *SAFETY: ALWAYS TURN OFF POWER AND DISCONNECT THE AIR LINES BEFORE INVESTIGATING JAMS OR INTERNALS ISSUES. NEVER PLACE FINGERS, HANDS, OR TOOLS INTO THE MACHINE WHILE IT IS PLUGGED IN OR AIR CONNECTED. 2. TURN ON SWITCH LOC. IN REAR OF 1.
- Page 2 9. PRESS LH & RH ACTIVATION BUTTONS. 10. SEE PIC 9. MATERIAL WILL ADVANCE FOR ONE CUT CYCLE FOR LOAD SEQUENCE. 11. TO RUN: SLIDE KEYPAD SAFETY SHIELD TO 12. LCD WILL SHOW “LENGTH”, ENTER LENGTH. TOO LOOSE: MATERIAL WILL NOT BE INDEXED LEFT.
