8. Install the charged 6 or 7 cell battery into the battery slot.
Re-install the battery strap onto the Evader BX. Note that
there is a channel in the chassis for the battery strap to
rest in. Re-install the body clip into the battery strap post.
9.The transmitter features a adjustable steering rate knob
labeled "D/R" on the top of the transmitter. Turning it fully
clockwise will give you the greatest amount of steering
travel. Turning it counterclockwise will reduce the amount of
FINISHING THE EVADER BX PRE-BUILT VERSION (DTXC0022)

PREPARING THE RADIO SYSTEM

steering travel. If you are just learning to drive R/C you may
want to use less steering travel at first.
Body Clips
10. Decal the body as desired and install on the chassis.
Install the wing into the holes in the rear shock tower. Note:
If the wing fits loosely, bend the end of the wires a bit.
11. Proceed to page 8 for Running and Maintenance Tips.
1. Install the "AA" batteries in the transmitter.
2. Install and extend the transmitter antenna.
3. Connect the steering servo and electronic speed control
to the receiver.
4. Uncoil and extend the receiver antenna.
5. Hook up the charged 6 or 7 cell battery to the electronic
speed control.
6. Adjust the servo trims of the transmitter to the
center (neutral) position.
7. Switch on the transmitter.
8.Switch on the electronic speed control.
9.Operate the steering and throttle control. Make sure the
steering servo arm and motor move in proportion to the
movement of the steering wheel and throttle trigger.
10.Switch off the receiver, then the transmitter.

CHARGE YOUR BATTERY

1.Charge the 6 or 7 cell battery (not included) on your charger
(not included). See Safety Precautions before charging.
5
