TABLE OF CONTENTS

INTRODUCTION ................................................................2
IMPORTANT SAFETY PRECAUTIONS ............................2
HELPFUL HINTS ...............................................................2
STRESS TECH PARTS GUARANTEE ..............................3
REPAIR SERVICE .............................................................3
SPECIFICATION & DESCRIPTION CHANGES ...............3
REQUIRED ITEMS FOR COMPLETION...........................3
TOOLS NEEDED FOR COMPLETION .............................3
TOOLS INCLUDED FOR MAINTENANCE .......................3
FINISHING THE RTR VERSION ........................................4
FINISHING THE PRE-BUILT VERSION ............................5
PREPARING THE RADIO SYSTEM ..................................5
CHARGE YOUR BATTERY................................................5
STEERING SERVO INSTALLATION.................................6
RECEIVER INSTALLATION ..............................................7
ELECTRONIC SPEED CONTROL SET-UP ......................8
MAINTENANCE TIPS ........................................................8
Before Each Run ........................................................8
After Each Run...........................................................8
After Every Ten Runs.................................................8
ASSEMBLY GUIDE ...........................................................9
Front Knuckle Arm, Hub Carrier, Axle .....................9
Steering Bellcrank Assembly ...................................9
Servo, Servo Plate, Upper Plate .............................10
Rear Shock Tower, Bulkhead, & Suspension Arm ....10
Front Shock Tower, Bulkhead, & Suspension Arm ...11
Ball Differential.........................................................11
Slipper Clutch...........................................................12
Rear Hub, Rear Axles ..............................................12
Gearbox ....................................................................13
Shocks ......................................................................14
TUNING GUIDE ...............................................................15
Caster........................................................................15
Camber......................................................................15
Front Toe-In and Toe-Out.........................................15
Wheelbase ................................................................15
Battery Placement ...................................................15
Ride Height ...............................................................15
Camber Link Placement ..........................................15
Slipper Adjustment ..................................Back Cover
Front Shock Adjustment .........................Back Cover
Rear Shock Adjustment ..........................Back Cover
Shock Oils & Shock Springs...................Back Cover

INTRODUCTION

Thank you for purchasing the DuraTrax Evader BX. This
manual contains the instructions you need to build, operate
and maintain your new electric R/C vehicle. Read over this
manual thoroughly before building or operating the Evader BX.
SAFETY PRECAUTIONS
When the safety precautions are followed, the Evader BX
will provide years of enjoyment. Use care and good sense at
all times when operating this radio controlled buggy. Failure
to use this vehicle in a safe, sensible manner can result in
injury or damage to property. You and you alone must insure
that the instructions are carefully followed and all safety
precautions are obeyed.
• Do not operate the Evader BX near people. Spectators
should be behind the driver or at a safe distance away
from the vehicle.
• Make sure to read the instructions with the battery and
charger before charging.
• Do not leave the charger unattended during charging. If
the battery or charger become hot at any time disconnect
the battery from the charger immediately! Failure to do
so may cause permanent damage to the charger and
battery and may cause bodily harm.
• Do not cover the air intake holes on the charger during
charging, this may cause the charger to overheat.
• Do not allow the electronic speed control (ESC) or radio
equipment to come into contact with moisture. Water can
cause the electronics to short out and can cause
permanent damage.
• Always turn on the transmitter before turning on the
electronic speed control.
• Before turning on your radio check to make sure that no
one else is running on the same frequency as your
Evader BX.

HELPFUL HINTS

• Avoid working over a deep pile carpet. If you drop a small
part or screw, it will be difficult to find.
• Place a mat or towel over your work surface.This will prevent
parts from rolling off and will protect the work surface.
• Avoid running the buggy in cold weather. The plastic and
metal parts can become brittle at low temperatures. In
addition, grease and oil become thick, causing
premature wear and poor performance.
• Test fit all parts before attaching them permanently.
2
